Eaton GHB Series C Two-Pole Molded Case Circuit Breaker 277/480 VAC Thermal Magnetic Protection

(No reviews yet) Write a Review

Model: GHB2040

In Stock (leaves warehouse same day if ordered before 3pm ET)

$268.17
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton GHB Series C Two-Pole Molded Case Circuit Breaker 277/480 VAC Thermal Magnetic Protection

Professional electrical protection with fixed thermal and magnetic trip technology

The Eaton GHB Series C molded case circuit breaker delivers reliable two-pole electrical protection for commercial and industrial applications. This complete breaker unit features 277/480 VAC and 125/250 VDC voltage ratings with fixed thermal and magnetic trip protection, housed in a compact G-frame design measuring 2.63" x 2" for versatile installation requirements.

Professional Features & Benefits

  • Two-Pole Configuration: Provides simultaneous protection for both conductors with coordinated trip operation for enhanced safety.
  • 277/480 VAC Rating: Compatible with standard commercial voltage systems including 480Y/277 configurations for broad application flexibility.
  • Fixed Thermal/Magnetic Trip: Delivers precise overcurrent protection with thermal response for overloads and magnetic response for short circuits.
  • UL Listed Certification: Meets rigorous safety and performance standards for reliable operation in critical electrical systems.
  • Compact G-Frame Design: 2.63" x 2" dimensions enable installation in space-constrained panels while maintaining full protection capability.
  • 50/60 Hz Frequency Rating: Universal frequency compatibility ensures proper operation across diverse electrical systems and international applications.
  • Federal Specification Compliance: Meets W-C375B classification requirements for government and institutional installations.

Technical Specifications

  • Certifications: UL Listed
  • Circuit Breaker Frame Type: Complete breaker
  • Circuit Breaker Type: GHB
  • Compliances: Federal Specifications Classification W-C375B
  • Frame: G
  • Frequency Rating: 50/60 Hz
  • Number Of Poles: Two-pole
  • Product Details: Molded case circuit breaker
  • Product Length Depth: 2.63 in
  • Product Width: 2 in
  • Series: Series C
  • Trip Type: Fixed thermal, fixed magnetic
  • Voltage Rating: 480Y/277 Vac, 125/250 Vdc

Installation & Operation

  1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
  2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
  3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
  4. Configure any available load management or control features as supported by the provided specifications.
  5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
  6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

  • Commercial Building Electrical Distribution
  • Industrial Control Panel Protection
  • Motor Control Center Applications
  • Switchboard and Panelboard Installation
  • Government and Institutional Facilities
  • Manufacturing Equipment Protection
  • HVAC System Electrical Protection

Why Choose Eaton Quality?

Eaton GHB Series C circuit breakers combine proven molded case technology with UL Listed reliability and federal specification compliance. The fixed thermal and magnetic trip design ensures consistent protection performance, while the compact G-frame construction provides installation flexibility without compromising electrical protection capability.

Manufacturer Resources

Product Specs

Certifications:
UL Listed
Circuit Breaker Frame Type:
Complete breaker
Circuit Breaker Type:
GHB
Compliances:
Federal Specifications Classification W-C375B
Frame:
G
Frequency Rating:
50/60 Hz
Number Of Poles:
Two-pole
Product Details:
Molded case circuit breaker
Product Length Depth:
2.63 in
Product Width:
2 in
Series:
Series C
Trip Type:
Fixed thermal, fixed magnetic
Voltage Rating:
480Y/277 Vac, 125/250 Vdc
Department:
Electrical
Product Group:
Circuit Breakers
Product Type:
Circuit Breaker
