Eaton Heavy duty single-throw non-fused safety switch, Single-throw, 600A, NEMA 12, Painted galvanized steel, Non-fusible, Three-pole, Three-wire, 200 at 240 Vac TD 3 Ph, 400 at 480 Vac TD 3 Ph, 500 at 600 Vac TD 3 Ph
Manufacturer Resources
Product Specs
- Amperage Rating:
- 600A
- Catalog Notes:
- Suitable for service entrance use with a neutral or ground lug kit installed. For 2-pole applications; use outside poles of 3-pole switch
- Certifications:
- UL Listed
- Enclosure:
- NEMA 12
- Enclosure Material:
- Painted galvanized steel
- Fuse Configuration:
- Non-fusible
- Hp Rating Max:
- 200 at 240 Vac TD 3 Ph, 400 at 480 Vac TD 3 Ph, 500 at 600 Vac TD 3 Ph
- Number Of Poles:
- Three-pole
- Number Of Wires:
- 3
- Product Category:
- Heavy Duty, Non-Fusible
- Product Height:
- 12 in
- Product Length Depth:
- 58 in
- Product Weight:
- 130 lb
- Product Width:
- 27.5 in
- Special Features:
- Upper viewing window
- Type:
- Single-throw
- Voltage Rating:
- 600 V
- Product Group:
- Electrical
