Eaton M22 Front Mount Contact Module, Eight-Pole, No LED

Eaton M22 Front Mount Contact Module, Eight-Pole, No LED

(No reviews yet) Write a Review

Model: M22-SWD-K11

In Stock (leaves warehouse same day if ordered before 3pm ET)

$55.26
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton M22 Front Mount Contact Module, Eight-Pole, No LED

The Eaton M22 Front Mount Contact Module is a compact switching element built for M22 pushbutton and selector switch assemblies used throughout industrial control panels. This front-mounting module ships without LEDs and carries 1 contact on an eight-pole terminal arrangement, giving panel builders a simple, reliable switching stage that installs directly into the front of an M22 operator housing. Compact in profile at .47 in wide, 1.54 in deep, and 1.65 in tall, it is UL Listed and CE Marked for use in professional control-panel wiring.

Key Features

  • Compact Footprint: Measures .47 in wide x 1.54 in deep x 1.65 in tall, fitting easily behind M22 operator stations in space-constrained enclosures.
  • Front Mounting Design: Installs from the front of the M22 pushbutton or selector switch housing for straightforward assembly and servicing.
  • Eight-Pole Configuration: Provides an eight-pole terminal layout to support multi-circuit switching within a single module.
  • 1-Contact Switching: Configured with 1 contact for dedicated on/off or interlock signaling in control circuits.
  • No LED Indicator: Supplied without LEDs, keeping the module dedicated to pure contact switching without integrated illumination.
  • Industrial-Grade Build: Engineered as part of the Eaton M22 platform for dependable performance in demanding panel environments.

Certifications & Compliance

  • UL Listed
  • CE Marked

Technical Specifications

  • Number of contacts: 1
  • Product Type: Electrical Component
  • Department: Electrical

Typical Applications

  • Pushbutton and Selector Switch Assemblies
  • Industrial Control Panels
  • Machine Control Interfaces
  • Panel-Mount Operator Stations
  • OEM Equipment Manufacturing
  • Commercial and Industrial Electrical Installations

Why Eaton?

Eaton engineers the M22 contact module family to deliver consistent, code-compliant switching performance for control-panel builders. With UL Listed and CE Marked compliance, the compact 1-contact, eight-pole, front-mount design gives electrical professionals a dependable building block for pushbutton and selector switch circuits. Choosing Eaton means specifying components built for reliable, long-term operation in industrial control environments.

Manufacturer Resources

Product Specs

Product Width:
.47 in
Light Color:
Green
Catalog Notes:
M22 contact module without LED, front mount
Number of contacts:
1
Product Length/Depth:
1.54 in
Compliances:
CE Marked
Product Height:
1.65 in
Number Of Poles:
Eight-pole
Certifications:
UL Listed
Product Type:
Contact Block
Department:
Electrical
Configuration:
Eight-Pole
Listing:
UL Listed
Standards:
CE Marked
Product Group:
Motor Control & Automation
Product Subgroup:
Push Buttons & Pilot Devices
Product Weight:
0.022 lb
Product Length:
1.54 in

Eaton M22-SWD-K11 – Frequently Asked Questions

1) What is the Eaton M22-SWD-K11 contact module and where does it mount?
The M22-SWD-K11 is a front mount contact module for Eaton M22 pushbutton and selector switch assemblies. It installs from the front of the M22 operator housing rather than clipping on from behind, so panel builders can assemble and service it without pulling the operator out of the enclosure. It carries 1 contact on an eight-pole terminal arrangement and ships with no LED, so it is a pure switching element with no built-in illumination.
2) Will the Eaton M22-SWD-K11 fit behind an operator station in a shallow enclosure?
Its footprint is .47 in wide, 1.54 in deep and 1.65 in tall, so the depth behind the panel face is the number to check against your enclosure. At under half an inch wide it also stacks tightly where several modules sit side by side behind a row of M22 operators.
3) Is the Eaton M22 contact module UL Listed for control panel work?
UL Listed and CE Marked. That covers the usual specification requirement for industrial control panel components in North America and for equipment being built for export.
4) Does the Eaton M22-SWD-K11 contact module include an indicator light?
No. This one is supplied without an LED, so if the operator station needs illumination you will have to order an M22 LED element separately. Keep that in mind when the drawing calls for a lighted pushbutton, because this module handles the contact only.
5) How many circuits can I switch with one M22-SWD-K11 module?
One contact per module, on an eight-pole terminal layout. If your control scheme needs more than a single switched circuit off the same operator, you add contact modules to the stack rather than expecting this one part to cover it.
6) What is the exact part number to order this Eaton M22 front mount contact module?
Order Eaton M22-SWD-K11. That is the front mount, no-LED, eight-pole version with 1 contact. The M22 family uses close suffixes for LED and rear mount variants, so match the full designation when you specify it.
7) What kinds of jobs is the Eaton M22 contact module used on?
It is a building block for pushbutton and selector switch stations in industrial control panels, machine control interfaces and OEM equipment builds. Typical use is start/stop, on/off or interlock signaling wired into a control circuit behind a panel-mounted operator.
