Eaton M22 Modular Pushbutton USB Socket, IP67/IP69K Rated
The Eaton M22 Modular Pushbutton USB Socket is a 22.5 mm panel-mount USB 2.0 Type A interface built into Eaton's M22 modular pushbutton platform. Rated IP67 and IP69K, it is engineered to hold up to washdown, dust, and high-pressure spray environments while providing a reliable USB 2.0 connection point at the operator interface. With NEMA 4X and NEMA 21 environmental ratings and CE marking, this M22 series component is built for demanding industrial control panel and HMI applications.
Key Features
- Trade Size: 22.5 mm mounting diameter for standard M22 series pushbutton cutouts.
- USB 2.0 Connectivity: Complete with a 2-ft-long USB cable and 2.0 Type A plug for panel-to-device data connections.
- Environmental Rating: IP67 and IP69K rated, plus NEMA 4X and NEMA 21, for protection against dust, water jets, and washdown conditions.
- Compact Footprint: Product height of 2.06 in and product diameter of 1.17 in for space-conscious panel layouts.
- M22 Series Modular Design: Integrates with Eaton's M22 pushbutton and operator interface family for consistent panel aesthetics and mounting.
- CE Marked: Compliant with CE marking requirements for use in applicable installations.
Certifications & Compliance
- CE Marked
- CSA Certified
- IP67 and IP69K Rated
- NEMA 4X and NEMA 21 Rated
- USB interface is not UL Listed or CSA approved
Technical Specifications
- Series: M22
- Type: M22
- Size: 22.5 mm
- Special Features: USB 2.0 Socket
- Product Height: 2.06 in
- Product Diameter: 1.17 in
- Environmental Rating: IP67, IP69K, NEMA 4X, NEMA 21
- Compliances: CE Marked
- Certifications: CSA Certified
- Catalog Notes: Used for USB connection, 2.0 Type A plug, complete with 2-ft-long USB cable.
Typical Applications
- Industrial Control Panels and Operator Interfaces
- Machine Builder HMI Stations
- Washdown and Wet-Location Manufacturing Environments
- Food and Beverage Processing Equipment Panels
- Panel-Mount Data Transfer and Programming Access Points
Why Eaton?
Eaton's M22 modular pushbutton platform is built for consistent fit, finish, and function across an entire control panel, and this USB socket extends that platform with a rugged, IP67/IP69K-rated data connection point. Backed by CE marking and CSA certification, it delivers dependable performance for demanding industrial and washdown environments where code-compliant, reliable panel hardware is essential.
Manufacturer Resources
Product Specs
- Series:
- M22
- Product Size:
- 22.5 mm
- Special features:
- USB 2.0 Socket
- Compliances:
- CE Marked
- Product Height:
- 2.06 in
- Product Type:
- Pushbutton
- Product Diameter:
- 1.17 in
- Environmental rating:
- IP67, IP69K, NEMA 4X, NEMA 21
- Certifications:
- CSA Certified
- Department:
- Electrical
- Listing:
- CSA Certified
- Standards:
- CE Marked
- Product Group:
- Motor Control & Automation
- Product Subgroup:
- Push Buttons & Pilot Devices
Eaton M22-USB-SA – Frequently Asked Questions
1) What size panel cutout does the Eaton M22-USB-SA USB socket need?
It drops into a standard 22.5 mm M22 cutout, the same hole used for Eaton's M22 pushbuttons and selector switches. So if your panel is already punched for M22 operators, no new hole size is needed. Behind the panel, allow for a body height of 2.06 in and a diameter of 1.17 in.
2) Can the M22 USB socket handle washdown on a food processing line?
Yes. The M22-USB-SA carries IP67 and IP69K plus NEMA 4X and NEMA 21, which covers dust, temporary immersion and high pressure, high temperature spray, so it holds up in food and beverage washdown panels. IP69K is the rating that matters for hose-down cleaning.
3) Is the USB port on the Eaton M22-USB-SA UL Listed?
The USB interface itself is not UL Listed or CSA approved, even though the part is CSA certified and CE marked as a device. If your panel spec demands a UL Listed data port, this is not the part that satisfies it.
4) Do I need to buy a separate cable to wire the M22 USB socket to my PLC or HMI?
No separate cable is needed for the panel-side run. The socket ships complete with a 2-ft USB cable terminating in a USB 2.0 Type A plug, so you land the plug directly at your controller, HMI, or panel PC. If your device sits more than two feet from the cutout, plan on an extension.
5) What USB standard and connector type is the Eaton M22 panel socket?
It is a USB 2.0 Type A socket on the operator face, with the internal tail ending in a USB 2.0 Type A plug. It is a pass-through data and power connection point, not a hub or a converter, so throughput is whatever USB 2.0 supports on your host device.
6) What is the exact part number to order for the Eaton M22 USB panel socket?
Order Eaton M22-USB-SA. That single catalog number covers the complete assembly: the 22.5 mm USB 2.0 Type A socket and the 2-ft internal cable with its Type A plug.
7) How deep behind the door does the M22 USB socket sit?
Overall body height is 2.06 in, with a 1.17 in diameter, so it needs a little over two inches of clear depth behind the panel face plus room to route the 2-ft cable without a sharp bend. Worth checking against door-mounted devices and wire duct on shallow enclosures.
