Eaton B Frame Screw-In Connector Accessory for Manual Motor Protectors

Eaton B Frame Screw-In Connector Accessory for Manual Motor Protectors

The Eaton B Frame Screw-In Connector is an accessory designed to join B frame manual motor protectors together, giving panel builders and electricians a fast, reliable way to gang multiple protectors in a control enclosure. Built with a compact footprint measuring 44.45 mm wide, 75 mm in length/depth, and 50 mm in height, this Screw In style connector is engineered to integrate cleanly with Eaton's B frame manual motor protector line. It carries a UL 508 certification, reflecting the safety and performance standards expected in industrial control equipment.

Key Features

• Compact Dimensions: Measures 44.45 mm (width) x 75 mm (length/depth) x 50 mm (height), sized to fit alongside B frame devices without adding bulk to the enclosure.
• Screw In Connection: Special feature Screw In design allows the connector to join adjacent B frame manual motor protectors quickly, without special tools.
• B Frame Compatibility: Purpose-built for the B frame family of Eaton manual motor protectors, ensuring a consistent, engineered fit.
• Accessory Function: Functions as a dedicated joining connector, simplifying multi-unit motor protector layouts in control panels and motor control centers.
• Certified Performance: Backed by UL 508 certification for use in industrial control equipment applications.

Certifications & Compliance

• UL 508 Certified
• Compliances: Contact Manufacturer for additional compliance details

Technical Specifications

• Warranty: Not Applicable
• Frame: B
• Product Type: Connector
• Product Width: 44.45 mm
• Product Length/Depth: 75 mm
• Product Height: 50 mm
• Special Features: Screw In
• Certifications: UL 508

Typical Applications

• Motor Control Centers and Control Panels
• Ganged B Frame Manual Motor Protector Assemblies
• Industrial Machine Control Wiring
• Commercial and Industrial Electrical Installations
• Renovation and New Construction Panel Builds

Why Eaton?

Eaton engineers its B frame accessories, including this Screw In connector, to work as a matched system with its manual motor protector line, helping ensure a secure fit and dependable operation in the panel. With UL 508 certification behind it, this connector supports code-compliant, professional-grade installations where reliable motor protection assemblies are essential.
