Eaton Meter Socket Instrument Rated 20A 13-Jaw Poly-Phase Factory Wired Test Switch 600V

Eaton Meter Socket Instrument Rated 20A 13-Jaw Poly-Phase Factory Wired Test Switch 600V

Professional Electrical Metering & Power Distribution Equipment

The Eaton Meter Socket Instrument Rated 20A 13-Jaw Poly-Phase Factory Wired Test Switch 600V delivers exceptional electrical metering and power distribution performance for commercial and industrial electrical systems. This 20 ampere 600 volt AC instrument-rated meter socket with 13-jaw configuration provides reliable electrical metering infrastructure designed for professional electricians, electrical contractors, and facility managers, offering the proven reliability and advanced technology that professionals trust from the global leader in intelligent power management.

Professional Features & Benefits

Electrical Metering Performance

• 20 Ampere Current Rating - Professional current capacity for commercial and light industrial electrical metering applications with reliable performance
• 600 Volt AC Rating - High voltage capability for three-phase commercial and industrial power distribution systems requiring precise metering
• 13-Jaw Configuration - Advanced jaw design ensures secure meter connection and reliable electrical contact for accurate power measurement
• Instrument Rated Design - Precision-engineered for accurate electrical measurement and monitoring in professional electrical installations

Installation & Protection Features

• Poly-Phase Configuration - Multi-phase electrical system compatibility for balanced power distribution and comprehensive electrical monitoring
• Factory Wired Test Switch - Pre-wired test switching capability enables safe meter testing and maintenance without service interruption
• Professional Construction - Durable materials and precision manufacturing ensure long-term reliability in demanding electrical environments

Technical Specifications

Current Rating: 20 Amperes, Voltage Rating: 600 Volts AC, Configuration: 13-Jaw Instrument Rated Socket, Phase: Poly-Phase, Test Switch: Factory Wired, Application: Electrical Metering and Power Distribution

Installation & Usage

1. Verify electrical system compatibility with 20A 600V AC poly-phase requirements and local electrical codes
2. Install meter socket in appropriate electrical enclosure following NEC guidelines and manufacturer specifications
3. Connect incoming power conductors to line terminals ensuring proper phase sequence and secure connections
4. Connect load conductors to load terminals maintaining proper electrical isolation and grounding requirements
5. Verify test switch operation and proper meter jaw alignment before energizing the electrical system
6. Install appropriate electrical meter and perform system testing to ensure accurate power measurement and safe operation

Professional Applications

Ideal for:

• Commercial Electrical Systems - Office buildings, retail facilities, and commercial properties requiring accurate power metering and monitoring
• Industrial Power Distribution - Manufacturing facilities, warehouses, and industrial plants with three-phase electrical systems
• Multi-Tenant Buildings - Apartment complexes, condominiums, and mixed-use developments requiring individual unit metering
• Utility Metering Applications - Electric utility installations requiring precision measurement and reliable electrical connections
• Electrical Service Upgrades - Modernization projects requiring advanced metering capabilities and test switching functionality
• Power Monitoring Systems - Facilities requiring detailed electrical usage tracking and energy management capabilities
• Electrical Maintenance Programs - Applications where safe meter testing and maintenance access is critical for system reliability
• Code Compliance Projects - Electrical installations requiring adherence to current NEC and local electrical code requirements

Instrument Rated Advantage

The instrument-rated design ensures exceptional accuracy and reliability for electrical metering applications, providing precise power measurement capabilities essential for commercial billing, energy management, and electrical system monitoring. The 13-jaw configuration delivers superior electrical contact integrity and long-term performance in demanding electrical environments.

Why Choose Eaton Quality?

With over a century of electrical power management innovation, Eaton delivers unmatched quality and reliability in electrical metering solutions. Our commitment to electrical safety, precision engineering, and professional performance makes Eaton the trusted choice for electricians, electrical contractors, and facility professionals worldwide who demand superior electrical infrastructure and dependable power management technology.
