Eaton Definite Purpose Contactor, Two-Pole, Quick-Connect, Open Type with Metal Mounting Plate

Eaton Definite Purpose Contactor, Two-Pole, Quick-Connect, Open Type with Metal Mounting Plate

(No reviews yet) Write a Review

Model: C25BNB240B

In Stock (leaves warehouse same day if ordered before 3pm ET)

$384.27
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Definite Purpose Contactor, Two-Pole, Quick-Connect, Open Type with Metal Mounting Plate

The Eaton Definite Purpose Contactor is a compact, two-pole switching device built for motor control and HVAC-type loads that demand reliable cycling and a small footprint. It features binding head screw and quick-connect terminals arranged side-by-side, a 40A inductive full load rating with a 50A resistive load rating, and a 208-240 Vac, 50/60 Hz coil for dependable open-and-close operation. Housed in an open enclosure with a metal mounting plate and finished in a compact, two-pole frame size, this non-reversing contactor is CSA Certified and RoHS Compliant, making it a solid choice for professional electrical and mechanical control panels.

Key Features

  • Compact Frame Size: Two-pole construction measuring 1.97 in wide, 2.32 in deep, and 3.19 in high for space-efficient panel layouts.
  • Two-Pole Configuration: Non-reversing design suited for single-direction motor and load control applications.
  • Quick-Connect Terminals: Binding head screw and quick-connect terminals positioned side-by-side for flexible, fast field wiring.
  • Amperage Rating: 40A inductive full load and 50A resistive load rating for dependable switching performance.
  • Coil Rating: 208-240 Vac, 50/60 Hz coil for standard commercial control voltage compatibility.
  • Open Enclosure with Metal Mounting Plate: Open-type construction with a metal mounting plate for secure panel or enclosure installation.
  • Non-Reversing Operation: Engineered for single-direction load control in motor and equipment circuits.

Certifications & Compliance

  • CSA Certified
  • RoHS Compliant

Technical Specifications

  • Department: Electrical
  • Warranty: 1 year

Typical Applications

  • Motor Control Circuits
  • HVAC Equipment Control
  • Pump and Compressor Switching
  • Commercial and Industrial Control Panels
  • Lighting and Heating Load Control

Why Eaton?

Eaton's Definite Purpose Contactor combines a compact, open-type metal-mounted design with CSA Certified and RoHS Compliant construction, giving electrical professionals a dependable, code-conscious component for motor and load control applications. With quick-connect and binding head screw terminals plus a robust 40A/50A rating profile, this contactor is built to deliver consistent switching performance across commercial and industrial control panels.

Manufacturer Resources

Product Specs

Department:
Electrical
Connection:
Quick
Product Model:
Contactor
Configuration:
Two-Pole
Warranty:
1 year
Compliances:
RoHS Compliant
Product Type:
Contactor
Connection Type:
Quick Connect
Amperage Rating:
40A
Listing:
CSA Certified
Standards:
RoHS Compliant
Product Group:
Motor Control & Automation
Product Subgroup:
Contactors & Relays

Eaton C25BNB240B – Frequently Asked Questions

1) Will an Eaton C25BNB240B definite purpose contactor work with a 240V control circuit?
Yes. The C25BNB240B coil is rated 208-240 Vac, 50/60 Hz, so it drops straight onto a standard commercial 208V or 240V control voltage. If your thermostat or control transformer puts out 24V, this is the wrong coil and you need a 24V-coil version instead.
2) Is a 40A definite purpose contactor enough for my condenser or compressor motor?
The 40A figure is the inductive full load rating, which is the number that applies to motor, compressor, and pump loads. For resistive loads such as heat strips or incandescent lighting it carries 50A. Size against the inductive rating for anything with a motor in it.
3) How much panel space does the Eaton two-pole definite purpose contactor take up?
The two-pole frame measures 1.97 in wide, 2.32 in deep, and 3.19 in high. It ships open type on a metal mounting plate, so plan on mounting it inside an existing panel or enclosure rather than on an open wall.
4) Can I use spade terminals, or do I have to land ring lugs on this contactor?
Both work. The terminals are binding head screw plus quick-connect, arranged side by side, so you can push on a spade quick-connect for control wiring and screw down line and load conductors on the same device.
5) Can this Eaton contactor be used to reverse a motor?
No. It is a non-reversing two-pole contactor, built for single-direction load control. Reversing a three-phase motor takes a pair of mechanically interlocked contactors or a reversing starter, not this device.
6) Is the Eaton definite purpose contactor CSA certified and RoHS compliant for a spec job?
Yes on both. The contactor is CSA Certified and RoHS Compliant, which covers the two items most commonly called out on commercial and institutional control panel submittals.
7) What is the difference between the 40A and 300A Eaton definite purpose contactors?
Two amperage builds are offered: the 40A C25BNB240B compact two-pole unit, and the larger 300A C25FNF375C. Pick by the full load current of the equipment being switched; the 40A frame is the one sized for typical rooftop units, condensers, and small pump circuits.
8) Will a two-pole contactor switch a three-phase motor?
Not properly. Two poles break two legs only, so a three-phase load needs a three-pole device. Use this two-pole unit for single-phase motor, compressor, pump, heating, or lighting loads where breaking two legs is what the circuit calls for.
