Eaton 10250T Series Logic Level Contact Block, 2 NO, Pressure Terminals

Eaton 10250T Series Logic Level Contact Block, 2 NO, Pressure Terminals

(No reviews yet) Write a Review

Model: 10250T53C

In Stock (leaves warehouse same day if ordered before 3pm ET)

$31.86
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton 10250T Series Logic Level Contact Block, 2 NO, Pressure Terminals

The Eaton 10250T Series Logic Level Contact Block is a 30.5 mm, Heavy-Duty rated contact block built for use with Eaton's pushbutton and pilot device operators. It carries a 2 NO (standard) contact configuration with Pressure-style terminals for secure, low-voltage logic-level switching, and it is protected by a fingerproof shroud for added operator safety. The block is CE Marked and CSA Certified, making it suitable for demanding commercial and industrial control panel applications.

Key Features

  • Type: 30.5 mm, Heavy-Duty contact block design for reliable performance in control panel applications.
  • Contact Configuration: 2 NO (standard) contacts for logic-level circuit switching.
  • Terminals: Pressure-style terminals for a secure, low-voltage wiring connection.
  • Special Features: Fingerproof shroud helps protect against accidental contact during wiring and maintenance.
  • Stackable Design: Stack up to 6 blocks (12 circuits) unless otherwise noted, allowing flexible circuit expansion on a single operator.
  • Compact Dimensions: Product Width 1.3 in, Product Length/Depth 1.9 in, and Product Height 2.2 in for space-conscious panel layouts.
  • Series: Part of Eaton's 10250T Series of Logic Level Contact Blocks.

Certifications & Compliance

  • CE Marked
  • CSA Certified

Technical Specifications

  • Warranty: 1 year
  • Department: Electrical

Typical Applications

  • Industrial Control Panels
  • Machine Control and Automation Systems
  • Pushbutton and Pilot Device Assemblies
  • Logic-Level Signal and Interlock Circuits
  • Commercial and Industrial Electrical Installations

Why Eaton?

Eaton's 10250T Series contact blocks combine a Heavy-Duty 30.5 mm design with a fingerproof shroud for safer installation and maintenance. Backed by CE Marking, CSA Certification, and a 1 year warranty, this contact block delivers dependable, code-compliant performance for professional control panel builders and electrical contractors.

Manufacturer Resources

Product Specs

Warranty:
1 year
Series:
10250T
Department:
Electrical
Compliances:
CE Marked
Product Type:
Contact Block
Configuration:
2 NO
Connection Type:
Pressure
Standards:
CE Marked
Listing:
CSA Certified
Product Group:
Motor Control & Automation
Product Subgroup:
Push Buttons & Pilot Devices

Eaton 10250T53C – Frequently Asked Questions

1) What is the difference between the logic level and standard contact blocks in the Eaton 10250T series?
The choice comes down to the circuit you are switching. Logic level blocks (10250T2E for 2 NO, 10250T3E for 2 NC, 10250T53E for 1 NO) are built for low-voltage logic-level switching feeding PLC inputs and signal circuits. The standard versions (10250T2P for 2 NO, 10250T52 for 1 NC, 10250T53C for 1 NO) are the general-purpose contacts for conventional control voltage. Pick logic level when the contact drives an electronic input, standard when it carries normal control-circuit current.
2) How many Eaton 10250T contact blocks can I stack on one pushbutton operator?
Up to 6 blocks, which gives you 12 circuits on a single 30.5 mm operator, unless a particular block notes otherwise. That is what lets you expand a single pushbutton or selector into a multi-circuit interlock without adding another device hole in the panel door.
3) I need a normally closed contact instead of normally open. What Eaton 10250T part do I order?
For a single NC standard contact, order 10250T52. For two NC contacts at logic level, order 10250T3E. The 2 NO logic level block is 10250T2E, so ordering by the E suffix alone will not get you the right contact state.
4) What kind of terminals does the Eaton 10250T logic level block use, and do I need ring lugs?
Pressure-style terminals. You land stripped conductors directly under the pressure clamp, so no ring or spade lugs are required. A fingerproof shroud covers the terminals, so live parts stay protected while you are wiring or troubleshooting.
5) How much space does an Eaton 10250T contact block take up behind the panel?
Each block measures 1.3 in wide, 1.9 in in length/depth and 2.2 in high. Multiply the depth figure out when you stack blocks so you know the operator assembly clears wireway and door-mounted components behind the panel face.
6) Is the Eaton 10250T contact block approved for use in a Canadian control panel?
It is CSA Certified and CE Marked, which covers Canadian panel work and European-destined machinery builds. Those are the two approvals carried on the block.
7) What are the special function 10250T blocks for, like the 10250T47 and 10250T57?
Those two cover sequenced switching rather than plain NO or NC. The 10250T47 is a 1 ECNO-1NC arrangement and the 10250T57 is 1 LONC-1 ECNO. Use them where the make and break order matters, such as early-close or late-open interlock logic on a single operator. For straightforward start/stop wiring the standard or logic level NO and NC blocks are what you want.
8) Can I mix contact blocks on the same 10250T operator?
Yes. All eight configurations mount to the same 30.5 mm heavy-duty operator, so you can combine, for example, a 1 NO standard (10250T53C) with a 1 NC standard (10250T52) on one pushbutton, up to the 6-block, 12-circuit stack limit.
