Spec Sheet
Product Specs
- Amperage Rating:
- 45A
- Circuit Breaker Frame Type:
- Complete breaker
- Circuit Breaker Type:
- HFD
- Class:
- Vdc
- Frame Size:
- F-frame
- Interrupt Rating:
- 42 kAIC at 600 Vac
- Number Of Poles:
- Two-pole
- Terminals:
- Line and load
- Trip Type:
- Fixed thermal, fixed magnetic
- Voltage Rating:
- 600 Vac, 250 Vdc
- Department:
- Electrical
- Product Length:
- 3.38 IN
- Product Height:
- 6 IN
- Product Weight:
- 3 LB
- Product Width:
- 2.75 IN
- Certifications:
- UL 489
- Frame:
- F
B-LINE HFDDC2045L – Frequently Asked Questions
1) Can the HFDDC2045L be used on a 250 VDC solar array?
Yes. The HFDDC2045L is rated 600 Vac, 250 Vdc, and it is classed as a Vdc breaker for PV/solar service. On the DC side you are limited to 250 Vdc across the two poles, so confirm your array's maximum system voltage stays at or below that before you spec it.
2) Is the HFDDC2045L a complete breaker or just a trip unit I have to build up?
It ships as a complete molded case breaker with line and load terminals included, so there is no separate trip unit or terminal kit to order. The trip is fixed thermal, fixed magnetic, meaning nothing is adjustable in the field, you order the amperage you need.
3) What is the interrupting rating on this Eaton HFD 45 amp breaker?
42 kAIC at 600 Vac. That is the high-interrupt HFD frame, which is why it carries the HFD designation rather than the standard FD. If your available fault current at the panel exceeds 42 kA at 600 V, this breaker is not the right choice.
4) Why use a PV Guard DC breaker instead of a standard AC molded case breaker on the array side?
DC arcs do not self-extinguish the way an AC arc does at each zero crossing, so a breaker interrupting PV output needs a DC rating specifically. The HFDDC2045L carries a 250 Vdc rating alongside its 600 Vac rating and is built for PV/solar duty. A standard AC-only molded case breaker carries no DC rating and should not be used on the array conductors.
5) Will an F-frame breaker fit the space I have in my PV combiner or disconnect enclosure?
The HFDDC2045L is an F-frame two-pole breaker measuring 6 in by 3.38 in by 2.75 in and weighing 3 lb. Lay those three numbers against your enclosure's gutter space and mounting pan before you commit, F-frame is physically larger than the smaller single-pole frames often used in residential combiners.
6) Is the HFDDC2045L a 45 amp two-pole breaker, and do both poles have to be in the circuit?
45A, two-pole. Both poles are mechanically common in a molded case breaker, so the positive and negative (or both ungrounded AC conductors) open and close together. That is what you want on a PV circuit, you do not leave one conductor energized when the breaker is off.
7) Can I adjust the trip setting on the HFDDC2045L if the array is upsized later?
No. The trip is fixed thermal and fixed magnetic, so there is no adjustment dial. If the conductor ampacity or array output changes, you replace the breaker with a different amperage rating rather than re-setting this one. Adjustable electronic trip units are a different Eaton frame entirely.
