B-Line GHB1035 Eaton Series C complete molded case circuit breaker

B-LINE Series C Molded Case Circuit Breaker 35A Single-Pole G-Frame with Fixed Thermal-Magnetic Trip

(No reviews yet) Write a Review

Model: GHB1035
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$260.23
$101.20
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

B-LINE Series C Molded Case Circuit Breaker 35A Single-Pole G-Frame with Fixed Thermal-Magnetic Trip

Professional Circuit Protection with Fixed Thermal-Magnetic Trip Technology

The B-LINE Series C molded case circuit breaker delivers reliable electrical protection with 35A capacity and single-pole configuration. This G-frame complete breaker features fixed thermal and fixed magnetic trip technology, providing dependable overcurrent protection for 277 Vac and 125 Vdc applications with 14 kAIC interrupt rating at 277 Vac.

Professional Features & Benefits

  • 35A Amperage Rating: Provides optimal current capacity for medium-load electrical circuits and equipment protection.
  • Fixed Thermal-Magnetic Trip: Delivers precise overcurrent protection with reliable thermal overload and magnetic short-circuit response.
  • 14 kAIC Interrupt Rating: Ensures safe fault current interruption capability at 277 Vac for enhanced system protection.
  • G-Frame Design: Compact 4" height and 1" width construction optimizes panel space utilization.
  • Dual Voltage Rating: Compatible with both 277 Vac and 125 Vdc systems for versatile installation applications.
  • Complete Breaker Assembly: Ready-to-install molded case design reduces installation time and ensures proper component integration.

Technical Specifications

  • Amperage Rating: 35A
  • Circuit Breaker Frame Type: Complete breaker
  • Circuit Breaker Type: GHB
  • Department: Electrical
  • Frame Size: G-frame
  • Frequency Rating: 50/60 Hz
  • Height: 4 IN
  • Interrupt Rating: 14 kAIC at 277 Vac
  • Number Of Poles: Single-pole
  • Product Details: Molded case circuit breaker
  • Product Group: Electrical Components
  • Product Length: 2.63 IN
  • Product Subgroup: Circuit Breakers
  • Product Type: Molded case circuit breaker
  • Series: Series C
  • Trip Type: Fixed thermal, fixed magnetic
  • Voltage Rating: 277 Vac, 125 Vdc
  • Weight: .65 LB
  • Width: 1 IN

Professional Applications

  • Commercial Electrical Panels
  • Industrial Control Systems
  • Lighting Circuit Protection
  • Motor Control Centers
  • HVAC Equipment Protection
  • Distribution Panel Applications
  • Electrical Maintenance and Retrofit

Why Choose B-LINE Quality?

B-LINE Series C circuit breakers provide dependable electrical protection with proven molded case construction and fixed thermal-magnetic trip technology. The compact G-frame design and dual voltage compatibility ensure reliable performance across diverse commercial and industrial applications.

Manufacturer Resources

Spec Sheet

Product Specs

Amperage Rating:
35A
Circuit Breaker Frame Type:
Complete breaker
Circuit Breaker Type:
GHB
Frame Size:
G-frame
Frequency Rating:
50/60 Hz
Interrupt Rating:
14 kAIC at 277 Vac
Number Of Poles:
Single-pole
Series:
Series C
Trip Type:
Fixed thermal, fixed magnetic
Voltage Rating:
277 Vac, 125 Vdc
Department:
Electrical
Product Group:
Electrical Components
Product Subgroup:
Circuit Breakers
Product Type:
Molded case circuit breaker
Product Length:
2.63 IN
Product Details:
Molded case circuit breaker
Product Height:
4 IN
Product Weight:
.65 LB
Product Width:
1 IN

B-LINE GHB1035 – Frequently Asked Questions

1) Will a GHB1035 breaker work on a 277V lighting circuit?
Yes. The GHB1035 is rated 277 Vac and 125 Vdc, so it suits 277V lighting branch circuits as well as 125 Vdc control work. At 277 Vac it carries a 14 kAIC interrupt rating, so the available fault current at the panel needs to sit at or below that figure.
2) Is the GHB1035 a single-pole or two-pole breaker, and what amperage?
Single-pole, 35 amps. One pole occupies one space, so a 240V or two-wire load needs a two-pole device instead of this one.
3) Can the trip setting on this GHB breaker be adjusted in the field?
No. The GHB1035 uses fixed thermal and fixed magnetic trip elements, so both the overload and the instantaneous pickup are factory set. If you need an adjustable instantaneous setting for motor inrush, this is not the device.
4) I have a GHB breaker in my panel now. Is GHB1035 the right replacement?
If the breaker you are pulling is a GHB type in a G-frame and the circuit is single-pole 35A, yes, the GHB1035 matches on type, frame and pole count. Match the amperage stamped on the old handle first, since GHB runs across a range of trip ratings and only the 35A version is this part number.
5) Is 14 kAIC enough for my panel?
That depends on the calculated available fault current at the point of installation. The GHB1035 interrupts 14 kAIC at 277 Vac. Where an engineer's short-circuit study shows more than 14 kA at that bus, you need a higher interrupting device or a series-rated combination, not this breaker.
6) Do I need to order a separate trip unit or mounting kit with the GHB1035?
No. It ships as a complete breaker, a molded case assembly with the trip unit already built in, so nothing further is required beyond the panel interior it mounts to.
7) Will this breaker run on a 50 Hz system overseas?
Yes, it carries a 50/60 Hz frequency rating, so it works on both 60 Hz North American and 50 Hz systems within its 277 Vac rating.
