Eaton FD3200A10S22D01 Series C...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$7,138.14
$7,088.14
Eaton FD3200A10S22D01 Series C complete molded case circuit breaker, F-frame, FD, Fixed thermal and magnetic trips, Three-pole, 200A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, 48-127 Vac or 48-60 Vdc rear w/ right pigtail

Eaton FD3200A10S22D01 Series C complete molded case circuit breaker, F-frame, FD, Fixed thermal and magnetic trips, Three-pole, 200A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, 48-127 Vac or 48-60 Vdc rear w/ right pigtail

(No reviews yet) Write a Review

Model: FD3200A10S22D01
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$7,138.14
$7,088.14
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton FD2200WS21 Series C complete molded case circuit breaker, F-frame, FD, Fixed thermal and magnetic trips, Two-pole, 200A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, No term., 48-127 Vac or 48-60 Vdc same side w/ right pigtail

Eaton FD2200WS21 Series C complete molded case circuit breaker, F-frame, FD, Fixed thermal and magnetic trips, Two-pole, 200A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, No term., 48-127 Vac or 48-60 Vdc same side w/ right pigtail

Model: EAT-FD2200WS21

Eaton Series C complete molded case circuit breaker, F-frame, FD, Fixed thermal and magnetic trips, Two-pole, 200A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, No term., 48-127 Vac or...

Eaton

$5,349.29
$5,299.29
Eaton FD3200LA06N02 Series C complete molded case circuit breaker, F-frame, FD, Fixed thermal and magnetic trips, Three-pole, 200A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, 1A-1B rear w/right pigtail, 24 Vdc rear w/ left pigtail

Eaton FD3200LA06N02 Series C complete molded case circuit breaker, F-frame, FD, Fixed thermal and magnetic trips, Three-pole, 200A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, 1A-1B rear w/right pigtail, 24 Vdc rear w/ left pigtail

Model: EAT-FD3200LA06N02

Eaton Series C complete molded case circuit breaker, F-frame, FD, Fixed thermal and magnetic trips, Three-pole, 200A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, 1A-1B rear w/right...

Eaton

$6,386.71
$6,336.71
Eaton Series C complete molded case circuit breaker, F-frame, FD, Fixed thermal and magnetic trips, Three-pole, 200A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, 48-127 Vac or 48-60 Vdc rear w/ right pigtail

Manufacturer Resources

Product Specs

Amperage Rating:
200A
Auxiliary Switch:
2A-2B rear with left pigtail
Circuit Breaker Frame Type:
Complete breaker
Circuit Breaker Type:
FD
Compliances:
Contact Manufacturer
Frame:
F-frame
Frequency Rating:
50-60 Hz
Interrupt Rating:
65 kAIC at 240 Vac, 35 kAIC at 480 Vac
Mounting Hardware:
Imperial
Number Of Poles:
Three-pole
Product Height:
4.13 IN
Product Length Depth:
3.38 IN
Product Weight:
4.5 LB
Product Width:
4.13 IN
Series:
Series C
Shunt Trip:
48-127 Vac or 48-60 Vdc right pigtail rear
Terminals:
Line and load end caps
Trip Type:
Fixed thermal, fixed magnetic
Voltage Rating:
600 Vac, 250 Vdc
Product Group:
Electrical
!
