Product Specs
- Series:
- Series C
- Special Features:
- Used with K-frame
- Used With:
- K-frame
- Department:
- Electrical
- Product Group:
- Enclosures & Boxes
- Product Subgroup:
- Locks & Handles
- Product Type:
- Variable Depth Handle Mechanism
- Product Length:
- 9.3 IN
- Product Details:
- Variable Depth Handle Mechanism
- Product Height:
- 3.6 IN
- Product Weight:
- 1.8 LB
- Product Width:
- 6.1 IN
B-LINE 5092A62G01 – Frequently Asked Questions
1) Which Eaton breaker frame does the 5092A62G01 handle mechanism work with?
The Series C variable depth handle mechanism, part 5092A62G01, is built for K-frame molded case circuit breakers. If the breaker in your enclosure is a different frame size, this operating handle is not the right mechanism for it.
2) What does a variable depth handle mechanism actually do on a breaker enclosure?
It is the external operating handle assembly that lets you switch a molded case breaker on and off through the enclosure door without opening it. The variable depth part means the shaft assembly adjusts to suit how far the K-frame breaker sits behind the door, so the same mechanism covers a range of enclosure depths rather than one fixed dimension.
3) How much room do I need inside the panel for the 5092A62G01 handle mechanism?
The assembly measures 9.3 x 6.1 x 3.6 inches and weighs 1.8 lb. Use those figures to check clearance against the breaker footprint and the inside face of your door before you cut the panel.
4) Is 5092A62G01 an Eaton part or a B-Line part?
Both names belong to the same company. B-Line is Eaton's enclosure and support systems line, and 5092A62G01 is the Series C molded case circuit breaker handle mechanism. Order by that number and you get the correct part regardless of which brand name appears on your drawing.
5) Where can I get the dimensional drawing for the 5092A62G01 handle mechanism?
Eaton publishes a spec sheet for 5092A62G01, and it is linked directly from the product information. That is where you will find the mounting and cutout detail you need for the door prep.
