Eaton Series C Through-the-Door Rotary Handle Mechanism, F-Frame J-K

Eaton Series C Through-the-Door Handle Mechanism

The Eaton Series C Through-the-Door Handle Mechanism is an aftermarket accessory handle designed for molded case circuit breakers, allowing operators to switch breakers on and off from outside a closed enclosure. This through-the-door handle mechanism is offered in a range of models to suit different breaker configurations, making it a practical retrofit accessory for Eaton Series C breaker installations. Built to Eaton specifications, it delivers safe, reliable external operation for panels that require operators to keep the enclosure door closed during switching.

Key Features

• Through-the-Door Design: A through-the-door handle mechanism lets personnel operate the breaker without opening the panel door.
• Positive Manual Operation: Provides smooth, positive manual operation for on, off, and trip-reset functions.
• Series C Compatibility: Used with molded case breakers within the Eaton Series C line for straightforward aftermarket installation.
• Retrofit Ready: Configured to match standard Series C breaker wiring arrangements for dependable field installation.
• Accurate Alignment: Shaft is sized for accurate alignment through the enclosure door.
• Predictable Panel Fit: Dimensioned for predictable fit within commercial and industrial panels.

Technical Specifications

• Series: Series C
• Type: Through-the-door handle mechanism
• Compatibility: Eaton Series C molded case circuit breakers
• Warranty: Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.

Typical Applications

• Commercial and Industrial Electrical Panelboards
• Molded Case Circuit Breaker Retrofits and Upgrades
• Enclosures Requiring External Breaker Operation Without Opening the Door
• Aftermarket Accessory Installations on Eaton Series C Breakers
• Panel Maintenance and Electrical Safety Upgrades

Why Eaton?

Eaton Series C molded case circuit breaker accessories are engineered to fit precisely with Series C breakers, giving electrical contractors and facility teams a dependable way to upgrade existing panels for safer, more convenient operation. This through-the-door handle mechanism is built to Eaton's manufacturing standards and backed by the Eaton Selling Policy 25-000 warranty, supporting long-term, code-conscious performance in demanding commercial and industrial electrical systems.
