Eaton SPD Type 1 CHSP Service Entrance Surge Protection UL 1449 3rd Edition Nominal Discharge Current 20kA NEMA 4

Eaton Type 1 Service Entrance Surge Protection Device 20kA NEMA 4 Enclosure UL 1449 Certified

(No reviews yet) Write a Review

Model: CHSPT1-208Y

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,086.08
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Type 1 Service Entrance Surge Protection Device 20kA NEMA 4 Enclosure UL 1449 Certified

Professional Service Entrance Surge Protection for Critical Power Systems

The Eaton Type 1 Service Entrance Surge Protection Device delivers comprehensive electrical system protection with 20kA nominal discharge current capacity and NEMA 4 weatherproof enclosure. This UL 1449 3rd Edition certified surge protector provides reliable defense against power surges at the service entrance level, featuring 200kA short circuit current rating and permanent mounting design for professional installations requiring maximum surge protection performance.

Professional Features & Benefits

  • 20kA Nominal Discharge Current: Provides substantial surge handling capacity to protect against high-energy electrical transients and lightning-induced surges.
  • NEMA 4 Enclosure: Weatherproof construction ensures reliable operation in outdoor and harsh environmental conditions with protection against dust and water ingress.
  • 200kA Short Circuit Rating: Delivers exceptional fault current withstand capability for safe operation in high-capacity electrical systems.
  • UL 1449 3rd Edition Certification: Meets the latest industry safety and performance standards for surge protective devices, ensuring code compliance and reliable protection.
  • Type 1 Service Entrance Design: Engineered specifically for installation at the main electrical service entrance to provide whole-facility surge protection.
  • Permanent Mounting Method: Secure installation design ensures long-term reliability and proper electrical connections in professional applications.
  • 300V L-L Operating Voltage: Compatible with standard commercial and residential electrical systems for versatile installation applications.

Technical Specifications

  • Certifications: UL 1449
  • Enclosure: NEMA 4
  • Interrupt Rating: 200 kAIC
  • Maximum Continuous Operating Voltage: 150 V L-N, 300 V L-L
  • Mounting Method: Permanent
  • Nominal Discharge Current 8x20us In: 20 kA
  • Operating Voltage: L-L 300, L-N 150
  • Product Details: Type 1
  • Product Weight: .93 lb
  • Short Circuit Current Rating: 200 kA
  • Surge Current: 50kA
  • Voltage Protection Rating: 1000 V L-L, 600 V L-N

Professional Applications

  • Commercial Facilities requiring comprehensive surge protection at the main service entrance
  • Industrial Plants with sensitive electronic equipment and control systems
  • Healthcare Facilities needing reliable power quality protection for critical systems
  • Data Centers and Telecommunications facilities with high-value electronic infrastructure
  • Educational Institutions protecting computer labs and electronic learning systems
  • Residential Properties with whole-house surge protection requirements
  • Government Buildings and Emergency Services facilities requiring uninterrupted power quality

Why Choose Eaton Quality?

Eaton surge protection devices deliver proven reliability through rigorous UL 1449 3rd Edition certification and robust NEMA 4 enclosure construction. With 200kA short circuit current rating and permanent mounting design, this Type 1 surge protector provides the professional-grade protection and durability required for critical electrical system applications.

Manufacturer Resources

Product Specs

Certifications:
UL 1449
Configuration:
NEMA 4
Interrupt Rating:
200 kAIC
Maximum Continuous Operating Voltage:
150 V L-N, 300 V L-L
Mounting Method:
Permanent
Nominal Discharge Current 8x20us In:
20 kA
Operating Voltage:
L-L 300, L-N 150
Product Details:
Type 1
Product Weight:
.93 lb
Short Circuit Current Rating:
200 kA
Surge Current:
50kA
Voltage Protection Rating:
1000 V L-L, 600 V L-N
Department:
Electrical
Product Group:
Surge Protectors
Product Type:
Surge Protector

Eaton CHSPT1-208Y – Frequently Asked Questions

1) Can an Eaton CHSPT1 Type 1 surge protective device be installed on the line side of the main breaker?
Yes. The CHSPT1 series is a Type 1 device, which is what allows installation at the service entrance on either side of the service disconnect, unlike a Type 2 that must go on the load side. It mounts permanently, so it is a hard-wired install at the panel or meter socket, not a plug-in unit. Its 200 kA short circuit current rating lets it sit on high-capacity commercial services without exceeding the available fault current at the service.
2) Which Eaton CHSPT1 model do I order for a 208Y three-phase service versus a single-phase house panel?
Three orderable models cover the two service types. The CHSPT1-208Y is the three-phase wye version, rated 50 kA surge current. For single-phase, the CHSPT1MAX is the 45 kA option and the CHSPT1ULTRA is the 50 kA option. Phase configuration is the first thing to get right, so match the model to the service before comparing surge ratings.
3) Will an Eaton CHSPT1 surge protector work on a 120/240V single-phase or 120/208V three-phase system?
The maximum continuous operating voltage is 150 V line-to-neutral and 300 V line-to-line. That covers 120/208V wye three-phase and 120/240V single-phase service. It does not cover 277/480V systems, where the 277 V line-to-neutral exceeds the 150 V MCOV, so a 480V service needs a different device entirely.
4) Can an Eaton CHSPT1 surge protector be mounted outdoors next to the meter?
The enclosure is NEMA 4, which is rated against dust and water ingress, so outdoor mounting at the meter or on an exterior wall is within its rating. It ships as a permanently mounted device, so plan for conduit and a hard-wired connection rather than a cord.
5) Does the Eaton CHSPT1 meet UL 1449 for a service entrance surge device on a healthcare or school project spec?
UL 1449 certification is carried on the CHSPT1 series, to the 3rd Edition, as a Type 1 SPD. The values a spec reviewer normally asks for are on record: 20 kA nominal discharge current (In) at the 8x20us waveform, a voltage protection rating of 1000 V L-L and 600 V L-N, and a 200 kAIC interrupt rating.
6) What is the difference between the Eaton CHSPT1MAX and the CHSPT1ULTRA?
Both are single-phase Type 1 service entrance devices. The difference on record is surge current capacity: the CHSPT1MAX is 45 kA and the CHSPT1ULTRA is 50 kA. Everything else in the shared spec set, including the 20 kA nominal discharge current and NEMA 4 enclosure, is common to the family. For a home or small commercial service the MAX is the lower-capacity choice, the ULTRA the higher.
7) What does the 1000V voltage protection rating on the Eaton CHSPT1 mean for the equipment downstream?
Voltage protection rating is the let-through voltage the device clamps to during a surge: 1000 V line-to-line and 600 V line-to-neutral on the CHSPT1. That is the number to compare against the withstand rating of what you are protecting. A service entrance device like this handles the big lightning-driven transients; sensitive electronics on branch circuits are usually given a second, lower-VPR Type 2 or point-of-use device downstream rather than relying on the service entrance unit alone.
8) Is the Eaton CHSPT1 surge protector rated for a panel with high available fault current?
It carries a 200 kA short circuit current rating, listed as 200 kAIC. That covers service equipment well above what most commercial and all residential services see, so available fault current is rarely the limiting factor on this device. Confirm the SCCR you need from the utility fault study and compare against the 200 kA figure.
9) Should I put in a Type 1 service entrance SPD or a Type 2 panel surge protector?
A Type 1 device like the Eaton CHSPT1 is built to go at the service entrance and can be installed on the line side of the main disconnect, which is where whole-facility protection against lightning-driven and utility-side transients belongs. A Type 2 device has to be installed on the load side of the main and is what you use at a downstream distribution panel. Many facilities install both: the Type 1 at the service to take the large hit, a Type 2 or point-of-use device nearer the sensitive equipment. Note that this Eaton unit tops out at 150 V L-N, so it suits 120/240V and 120/208V services only.
10) How heavy is the Eaton CHSPT1 surge protector, and will it hang off a panel enclosure?
Product weight is .93 lb, so it is light enough to hang from a knockout on the side of a load center or meter socket without additional support. Mounting is permanent, so the fasteners and conduit connection carry it.
