Eaton TR7735V-BOX Tamper-Resistant Combination LED Nightlight Receptacle, Ivory

Eaton TR7735V-BOX Tamper-Resistant Combination LED Nightlight Receptacle, Ivory

(No reviews yet) Write a Review

Model: TR7735V-BOX

In Stock (leaves warehouse same day if ordered before 3pm ET)

$20.09
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
"

Eaton TR7735V-BOX Tamper-Resistant Combination LED Nightlight Receptacle, Ivory

The Eaton TR7735V-BOX is a combination decorator-style device that pairs a built-in LED nightlight with a tamper-resistant 5-15R receptacle in a single flush-mount box. Rated 15A at 120/277V and built for #14-12 AWG conductors, this two-pole, three-wire grounding device is designed for both back and side wiring, giving electricians flexibility during rough-in and finish work. Constructed with brass contacts and finished in Ivory, the TR7735V-BOX delivers dependable everyday performance for residential and light commercial applications where convenient illumination and a standard grounding receptacle are needed in the same footprint.

Key Features

  • Combination Design: Integrates an LED nightlight with a standard 5-15R receptacle in one decorator-style device, eliminating the need for a separate nightlight fixture.
  • Tamper Resistant: Built-in tamper-resistant shutters help block foreign object insertion, supporting code-required child safety in occupied spaces.
  • Wire Compatibility: Accepts #14-12 AWG conductors for straightforward termination with common residential and commercial branch-circuit wiring.
  • 15A Rating: Rated for 15A at 120/277V, suitable for standard lighting and general-purpose receptacle circuits.
  • Flush Mount: Flush-mount configuration installs cleanly into a standard wall box for a low-profile, finished appearance.
  • Back and Side Wiring: Supports both back-wire and side-wire termination methods, giving installers flexibility to match job-site preferences.
  • Two-Pole, Three-Wire Grounding: Two-pole, three-wire grounding construction with a 5-15R configuration provides a properly grounded connection for connected equipment.
  • Brass Contacts, Ivory Finish: Brass contact construction paired with an Ivory decorator finish for reliable conductivity and a clean, neutral appearance that fits most interior color schemes.

Technical Specifications

  • Wire Range: #14-12 AWG
  • Amperage: 15A
  • Voltage: 120/277V
  • Mounting: Flush Mount
  • Wiring Method: Back and Side Wiring
  • Color: Ivory
  • Contact Material: Brass
  • Receptacle Configuration: 5-15R
  • Pole/Wire Configuration: Two-Pole, Three-Wire, Grounding
  • Style: Decorator
  • Tamper Resistance: Tamper Resistant

Typical Applications

  • Residential Bedrooms, Hallways, and Bathrooms
  • Kitchens and Living Areas Requiring Nightlight Convenience
  • Light Commercial Interior Wiring Projects
  • New Construction and Retrofit Electrical Upgrades
  • Locations Requiring Tamper-Resistant, Code-Compliant Receptacles

Why Eaton?

Eaton engineers wiring devices like the TR7735V-BOX with brass contacts and tamper-resistant construction to deliver dependable, safety-conscious performance for everyday electrical installations. The combination nightlight and grounding receptacle design reflects Eaton's focus on practical, space-saving solutions for electricians and homeowners alike. Choose Eaton for wiring devices built to perform reliably across residential and light commercial applications.

"

Manufacturer Resources

Product Specs

list_batch:
EAT-20260924
Product Type:
Receptacle/Night Light Combination
Amperage Rating:
15A
Voltage Rating:
120/277V
Configuration:
Two-Pole, Three-Wire, Grounding, 5-15R
Connection Type:
Back and Side Wiring
Department:
Electrical
Product Subgroup:
Combination Devices
Product Material:
Brass
Product Color:
Ivory
Product Group:
Wiring Devices
Product Width:
2 in
Product Length:
2 in
Product Height:
4.25 in
Product Weight:
0.239 lb

Eaton TR7735V-BOX – Frequently Asked Questions

1) Does the Eaton TR7735V-BOX nightlight receptacle need a separate switch or wiring for the LED light?
No separate switch leg is needed. The TR7735V-BOX puts the LED nightlight and a 5-15R tamper-resistant receptacle in one flush-mount device fed by the same branch circuit, terminated on #14-12 AWG conductors. You wire the box like a standard grounding receptacle (two-pole, three-wire, grounding) and the nightlight runs off that feed, so no extra conductor or switch box is required.
2) Will the TR7735V-BOX fit in a standard single-gang wall box on a retrofit?
It is a flush-mount decorator-style device built to install into a standard wall box, so it drops into a typical single-gang opening on a retrofit. It takes a decorator (rectangular opening) wall plate rather than a duplex plate, so plan on swapping the cover if the existing device is a standard duplex receptacle.
3) Is this Eaton nightlight receptacle tamper resistant for bedrooms and other dwelling-unit locations?
Yes. The TR7735V-BOX uses built-in tamper-resistant shutters that block foreign object insertion, which is what dwelling-unit receptacle locations call for. That makes it usable in bedrooms, hallways, bathrooms, kitchens and living areas where you also want the nightlight.
4) Can I use the TR7735V-BOX on a 277V circuit, or is it 120V only?
The device carries a 15A, 120/277V rating. The 5-15R receptacle face itself is a 125V configuration, so the cord-and-plug side stays on a 120V circuit; the 277V part of the rating covers the device's voltage withstand for the nightlight/lighting side. For a standard general-purpose or lighting branch circuit at 15A, 120V, it is the right device.
5) Can I back-wire these nightlight receptacles for a faster multi-unit rough-in?
Yes, back and side wiring are both supported, so you can pick whichever is faster on the job. For a run of apartments or hotel rooms, back-wiring the #14-12 AWG conductors keeps the device profile tight in the box; side screws are there if you prefer wrapping the terminals.
6) Should I install a combination nightlight receptacle or a plug-in nightlight plus a plain receptacle?
A combination device like the TR7735V-BOX is the better pick where you do not want a plug-in unit occupying one of the outlets. The LED light is integral to the device and the 5-15R opening stays free for use. If you only need the outlet and the room already has switched lighting, a plain tamper-resistant 15A 5-15R receptacle does the job and takes a standard duplex plate instead of a decorator plate.
7) What color and contact material is the Eaton TR7735V-BOX, and will it match existing ivory devices?
Ivory, in a decorator style, with brass contacts internally. If the other switches and receptacles on the floor are ivory decorator devices, this matches that scheme; it will not blend if the building is standardized on white or light almond.
8) What is the exact Eaton part number to order for the ivory tamper-resistant nightlight receptacle?
Order Eaton TR7735V-BOX. The TR prefix is the tamper-resistant designation and the V suffix is the ivory finish; it ships as a boxed single device rated 15A, 120/277V with a 5-15R face.
