Eaton Type BW Main Breaker – Two-Pole 120/240 V

Eaton Type BW Main Circuit Breaker 200A Two-Pole 120/240V 10kAIC

(No reviews yet) Write a Review

Model: BW2200

In Stock (leaves warehouse same day if ordered before 3pm ET)

$272.26
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Type BW Main Circuit Breaker 200A Two-Pole 120/240V 10kAIC

Professional Main Breaker Protection for Electrical Panel Systems

The Eaton Type BW Main Circuit Breaker delivers reliable electrical protection with 200A capacity and 120/240V rating. This two-pole main breaker features plug-on connection design and 10kAIC interrupt rating for dependable service in residential and commercial electrical panel applications. UL 489 certified for professional installation standards.

Professional Features & Benefits

  • 200A Amperage Rating: Provides substantial electrical capacity for main panel protection and load distribution requirements.
  • 120/240V Voltage Rating: Compatible with standard residential and light commercial electrical systems for versatile applications.
  • 10kAIC Interrupt Rating: Delivers reliable fault current interruption capability for enhanced electrical safety protection.
  • Two-Pole Configuration: Enables proper line-to-line voltage protection and neutral switching for complete circuit control.
  • Plug-on Connection: Simplifies installation with secure mechanical and electrical connection to compatible panel bus systems.
  • UL 489 Certification: Meets rigorous safety and performance standards for professional electrical installations.
  • Type BW Frame Design: Engineered for compatibility with Type ECB Unit Enclosures and related Eaton electrical components.

Technical Specifications

  • Amperage Rating: 200 A
  • Catalog Notes: Series combination rating with Types BD, BR, BQ, BQC and GFCB is 22,000 AIC with BRH main and 25,00
  • Certifications: UL 489
  • Circuit Breaker Frame Type: BW
  • Connection: Plug-on
  • Interrupt Rating: 10 kAIC
  • Main Circuit Breaker: BR
  • Number Of Poles: Two-pole
  • Product Height: 5 in
  • Product Length Depth: 6.25 in
  • Product Width: 5.25 in
  • Used With: Type ECB Unit Enclosures
  • Voltage Rating: 120/240 V
  • Wire Size: #2 AWG-300 kcmil Cu/Al

Professional Applications

  • Residential Main Panel Protection
  • Commercial Electrical Distribution
  • Multi-Unit Housing Properties
  • Professional Office Buildings
  • Retail and Light Industrial Facilities
  • Service Entrance Applications
  • Electrical Panel Upgrades

Why Choose Eaton Quality?

Eaton Type BW Main Circuit Breakers provide dependable electrical protection with UL 489 certification and proven plug-on connection technology. The compact 5 x 5.25 x 6.25 inch design accommodates #2 AWG-300 kcmil Cu/Al wire sizes while maintaining compatibility with Type ECB Unit Enclosures for professional installation flexibility and long-term reliability.

Manufacturer Resources

Product Specs

Amperage Rating:
200 A
Certifications:
UL 489
Circuit Breaker Frame Type:
BW
Connection:
Plug-on
Interrupt Rating:
10 kAIC
Main Circuit Breaker:
BR
Number Of Poles:
Two-pole
Product Height:
5 in
Product Length Depth:
6.25 in
Product Width:
5.25 in
Used With:
Type ECB Unit Enclosures
Voltage Rating:
120/240 V
Wire Size:
#2 AWG-300 kcmil Cu/Al
Department:
Electrical
Product Group:
Circuit Protection
Product Type:
Circuit Breaker
Product Subgroup:
Circuit Breakers

Eaton BW2200 – Frequently Asked Questions

1) What wire size can I land on a 200 amp Eaton BW main breaker?
The lugs take #2 AWG through 300 kcmil, copper or aluminum. That covers the usual 200A service entrance conductors, including 4/0 aluminum SER and 2/0 copper. No separate lug kit is needed.
2) What is the difference between the Eaton BW2200 and BW2200W?
Both are the same 200A two-pole 120/240V BW main. BW2200 is the plug-on breaker by itself; BW2200W is supplied as a kit main breaker, which is how you order it when you are converting or fitting out an enclosure rather than replacing a bare breaker. If you are swapping a failed main in an existing panel, the plug-on breaker is what you want.
3) Can I use this Eaton 200A breaker on a 208Y/120 three-phase panel?
No. It is a two-pole breaker rated 120/240V only, built for single-phase line-to-line service. For a three-phase 208Y/120 distribution panel you need a three-pole main rated for that system.
4) Will a BW 200A main fit in the space my old main occupied?
The breaker measures 5 x 5.25 x 6.25 inches. Check that footprint against the main breaker pocket in your panel, particularly the 6.25 inch depth, since that plus wire bending space determines whether the deadfront closes over the lugs.
5) Is this Eaton main breaker listed for service entrance use in a commercial building?
It is UL 489 listed, the standard for molded case circuit breakers, and it is applied as a main in residential and light commercial panels including multi-family, office, and retail service entrance work. The controlling factors for your job are the 200A rating, the 120/240V single-phase system, and available fault current against the 10 kAIC rating.
6) Does a plug-on main breaker need mounting hardware or a hold-down kit?
The BW main uses a plug-on connection, so it makes its mechanical and electrical connection directly to the panel bus with no bolting to the bus required. Some enclosures still use a retaining strap or screw supplied with the panel; reuse what came off the old main.
