Eaton FDPW Fusible Panelboard Switch, Twin Horizontal, Three-Pole, 600V
The Eaton FDPW Fusible Panelboard Switch is a twin, horizontal-configuration switch built for branch-circuit connection in commercial and industrial panelboards. Rated three-pole at 600V with a 200 kAIC interrupt rating and Class J fuse provision, this Eaton FDPW switch is engineered to deliver dependable overcurrent protection and code-compliant performance in demanding electrical distribution applications. Wire size accommodation of #14-1/0 AWG and horsepower ratings up to 20 hp at 600 Vac make it suitable for a wide range of branch and motor-load circuits.
Key Features
- Poles: Three-pole configuration for balanced branch-circuit switching.
- Voltage Rating: 600V rated for use in higher-voltage distribution systems.
- Switch Type: FDPW twin, horizontal configuration for compact panelboard mounting.
- Fuse Class Provision: Accepts Class J fuses for coordinated overcurrent protection.
- Interrupt Rating: 200 kAIC for high fault-current withstand capability.
- Wire Size: Accommodates #14-1/0 AWG conductors for flexible field wiring.
- Dimensions: 8" wide x 22" deep x 10" high footprint for panelboard enclosures.
- HP Rating: Rated 7.5 hp at 240 Vac, 15 hp at 480 Vac, and 20 hp at 600 Vac.
Technical Specifications
- Voltage Rating: 600V
- Number Of Poles: Three-pole
- Type: Fusible panelboard switch
- Switch Type: FDPW, twin, horizontal
- Connection: Branch
- Amperage Rating: Unit 1: 30A, Unit 2: 30A
- Fuse Class Provision: Class J fuses
- Interrupt Rating: 200 kAIC
- Wire Size: #14-1/0 AWG
- HP Rating - Max: 7.5 hp at 240 Vac, 15 hp at 480 Vac, 20 hp at 600 Vac
- Product Width: 8"
- Product Length/Depth: 22"
- Product Height: 10"
Typical Applications
- Commercial and Industrial Electrical Distribution
- Panelboard and Branch Circuit Switching
- Motor Circuit Disconnect and Overcurrent Protection
- Fused Load Center Installations
- Renovation and New Construction Electrical Work
Why Eaton?
Eaton engineers the FDPW Series for reliable, code-compliant performance in demanding panelboard applications, backed by a 200 kAIC interrupt rating and Class J fuse coordination for robust overcurrent protection. The twin, horizontal switch configuration and broad wire size range give installers flexibility for branch and motor circuits alike. Choose Eaton FDPW panelboard switches for dependable, professional-grade electrical distribution equipment.
Manufacturer Resources
Product Specs
- Number Of Poles:
- Three-pole
- Product Width:
- 8 in
- Connection:
- Branch
- Voltage Rating:
- 600V
- Amperage Rating:
- Unit 1: 30A, Unit 2: 30A
- Product Length/Depth:
- 22 in
- Product Height:
- 10 in
- Product Type:
- Panelboard Switch
- HP rating - max:
- 7.5 hp at 240 Vac, 15 hp at 480 Vac, 20 hp at 600 Vac
- Fuse class provision:
- Class J fuses
- Switch Classification:
- FDPW, twin, horizontal
- Interrupt rating:
- 200 kAIC
- Product Size:
- #14-1/0 AWG
- Department:
- Electrical
- Configuration:
- Twin Horizontal
- Connection Type:
- Branch
- Product Group:
- Wiring Devices
