Emtek 3321 Cheyenne Sandcast Bronze Mortise Entrance Handleset - Entry Set

Emtek 3321 Cheyenne Sandcast Bronze Mortise Entrance Handleset - Entry Set

(No reviews yet) Write a Review

Model: F20-3321-75-RH-FB
From the Sandcast Bronze Collection
$1,197.00
$957.60
Selected Finish is
Selected Knob or Lever Style for Inside Trim is
Selected FREE KEYING Options is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,197.00
$957.60
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Emtek 3321 Cheyenne Sandcast Bronze Mortise Entrance Handleset - Entry Set

- Can be ordered with any Sandcast Bronze Knob or Lever for the inside trim
- Sold as complete set. Includes Latch and Strike Plate

- 2-1/2" or 2-3/4" Backsets
- Standard Mortise Door Prep ANSI A115.1
- UL Listed Mortise with ANSI F20 or F13 Function
- Schlage C Keyway
- Handing required for All Mortise Locks



Specifications:

  • Backset: 2-1/2" or 2-3/4"
  • Door Prep: Standard Mortise ANSI A115.1
  • UL Function: ANSI F20 or F13
  • Door Thickness: 1-3/4" standard (specify if thicker)
  • Keyway: Schlage C
  • Handing: Required – specify left or right
  • Fire Rating: UL 180 minute

Product Specs

Subcategory:
Mortise Entry Sets
Collection:
Sandcast Bronze
Product Type:
Handlesets
Product Group:
Mechanical Locks
Product Subgroup:
Mortise Locks and Trim
Commercial/Residential:
Residential
Lock Type:
Mortise
Lock Function:
Entry
Series:
Cheyenne
Theme:
Rustic Living
Electronic:
No
Keyed:
Yes
Handle Type:
Handleset
Keyed Function:
Single Cylinder
MAP Policy:
Yes
Product Model:
3321
Product Function:
Entry
Product Style:
Sandcast Bronze
Product Material:
Bronze
Product Category:
Mechanical Locks
Product Substrate:
Bronze
Department:
Door Hardware

Emtek F20-3321-75-RH-FB – Frequently Asked Questions

1) Do I have to specify handing when ordering the Emtek Cheyenne 3321 mortise handleset?
Yes, handing is required on every Emtek mortise lock. The Cheyenne 3321 is built as LH, RH, LHR or RHR, and the two reverse options are for out-swing doors. Stand outside the opening: if the hinges are on your left and the door swings away from you, that is LHR. Get this wrong and the lever or knob will be upside down and the latch bevel will face the wrong way.
2) What backset and door prep does the Emtek 3321 Cheyenne mortise entry set need?
It is available in 2-1/2 inch or 2-3/4 inch backset and uses standard mortise door prep to ANSI A115.1. If the door is already prepped for a commercial mortise lock body, measure from the door edge to the center of the cylinder hole to pick the right backset. Door thickness is 1-3/4 inch standard; thicker doors can be built, but the thickness has to be stated on the order.
3) What is the difference between the F20 and F13 function on this Emtek Cheyenne handleset?
F20 is the entrance function: key retracts the latch from outside, inside trim always gives free egress. F13 is a dormitory/hotel style function, which is the tighter of the two for units where you do not want the outside trim left in an unlocked state. Both are offered on the Cheyenne 3321, and both use a single cylinder, so there is no interior keyed side.
4) Is the Emtek 3321 Cheyenne handleset fire rated?
The mortise lock body is UL Listed with a UL 180 minute fire rating, using the ANSI F20 or F13 function. That covers it for a rated opening where the door and frame assembly are also rated.
5) Can I key this Emtek handleset into my existing Schlage master key system?
The cylinder is Schlage C keyway, so it works within an existing SC system. On the order you choose keyed different or keyed alike across multiple sets, and you can supply a key code to have them cut to an existing key. Only one cylinder per set, on the exterior.
6) My door is thicker than 1-3/4 inches. Can I still use this Emtek mortise entry set?
Yes. 1-3/4 inch is the standard build, and thicker doors are accommodated if you state the actual door thickness when you order. Measure the slab, not the frame. If you are comparing options for an oversize slab, the Weslock 1411 Traditionale handleset covers 1-3/4 to 2-1/4 inch as a tubular alternative.
7) What is the closest alternative to the Emtek 3321 Cheyenne handleset for a door already prepped for a mortise lock?
The Emtek 3321 Cheyenne is a mortise entrance handleset using standard mortise door prep to ANSI A115.1, so a replacement has to be mortise trim rather than a tubular set. The Baldwin Estates 6542 Tremont entry mortise trim is the mortise-prep peer, offered as a single cylinder version and a double cylinder version, both listed for 1-3/4 inch doors. The Emtek 3321 is also built for 1-3/4 inch doors as standard, with thicker doors specified at order.
8) What should be used instead of the Emtek 3321 Cheyenne if keypad or app access is wanted at the entry?
The Emtek 3321 Cheyenne is a mechanical, non-electronic mortise entry set keyed to Schlage C. For electronic access, the Kwikset 815SCEHFL San Clemente handleset pairs a Halifax lever with a contemporary SmartCode keypad deadbolt for 1-3/4 inch doors, and the Yale Assure Lock touchscreen deadbolts with Ridgefield handleset are offered standalone as BYRD226NRRX or with Wi-Fi and Bluetooth as BYRD226CBARX, both covering 1-3/4 inch to 2-1/4 inch doors.
9) If the door is only bored for a tubular handleset, what should be used instead of the Emtek 3321 Cheyenne?
The Emtek 3321 Cheyenne requires a standard mortise pocket prep per ANSI A115.1, so it will not drop into a bored tubular door. For tubular prep, the Sure-Loc Alta tubular handleset has an adjustable backset, and the Sure-Loc Aspen and Madison keyed entry handlesets are also adjustable-backset handlesets. The Schlage Residential F60 Addison handleset with Accent lever is a Grade 2 entrance set covering 1-3/8 inch to 1-3/4 inch doors.
10) Which handlesets look like substitutes for the Emtek 3321 Cheyenne but will not work as a keyed entry replacement?
The Emtek 3321 Cheyenne is a keyed single cylinder entry set available in F20 entrance and F13 dormitory functions. Several similar-looking handlesets are not keyed entry: the Weslock 6695 Belmont with Impresa knob and the Weslock 2815 Hillcrest with New Heaven lever are dummy function, the Schlage JE285 Barcelona with Seville lever is non-keyed, and the Schlage JI18/19 with Torino lever is a passage lock with a separate keyed deadbolt.
11) What comes in the box with the Emtek Cheyenne 3321 entry set?
It ships as a complete set: exterior handleset plate and grip, the mortise latch, the strike plate, and the interior knob or lever you select. Nothing separate to order for the lock itself. You do still pick the inside trim, since it is a required selection rather than a default.
12) What interior knobs and levers can I pair with the Cheyenne handleset?
Any Emtek Sandcast Bronze knob or lever works as the inside trim. The choices run ten levers (Aurora, Bryce, Cimarron, Cody, Durango, Lariat, Mariposa, Montrose, Teton, Yuma) and fifteen knobs (Butte, Egg, Round, Winchester, Bristol, Hampton, Lowell, Windsor, Astoria, Diamond, Georgetown, Modern Disc, Modern Square, Old Town, Providence). If you want ADA-friendly operation on the inside, go with a lever.
13) Should I use a mortise handleset like this or a tubular one?
A mortise set like the Cheyenne 3321 needs a pocket machined into the door edge to ANSI A115.1 prep, and in return you get one heavier lock body doing latch and lock together. If your door is only bored for a standard tubular handleset, retrofitting to mortise means new door machining. In that case a tubular handleset with adjustable backset, such as the Sure-Loc Alta or Sure-Loc Aspen, drops into existing bores instead.
14) Is the Emtek 3321 Cheyenne handleset meant for commercial openings?
Emtek classes the Cheyenne sandcast bronze line as residential hardware, so it suits high-end homes, custom builds, and multi-family or hospitality entrances where the look matters. The lock body itself is UL Listed with a 180 minute fire rating and uses commercial ANSI A115.1 mortise prep, but if your spec calls for an ANSI/BHMA Grade 1 commercial mortise lockset, specify a commercial mortise lock line instead.
15) What is a simpler keyed entry handleset than the Emtek 3321 Cheyenne for a rental unit front door?
The Emtek 3321 Cheyenne is a sandcast bronze mortise entrance set on a Schlage C keyway with handing specified at order. If a simpler bored set suits, the Kwikset 687AMD Amador and 687BW Belleview single cylinder handlesets are Grade 3 entrance sets for 1-3/4 inch doors, with the 687AMD SMC on the SC1 keyway. The Master Lock HDLB series single cylinder deadbolt handleset is a Grade 2 entrance set.
16) What solid brass handleset alternatives exist if sandcast bronze is not the look wanted over the Emtek 3321 Cheyenne?
The Emtek 3321 Cheyenne is a sandcast bronze entry handleset offered in Flat Black Bronze, Medium Bronze and Tumbled White Bronze. For a solid brass entry handleset instead, Deltana offers the 803871B Hanover, 815871 St. Ann and 825871 Kingston, all solid brass entry handlesets. The Pamex FS7P31 Lexington is a single cylinder entry handleset in satin nickel for 1-3/8 inch to 1-3/4 inch doors.
17) How does the Emtek 3321 Cheyenne compare with the Baldwin Wesley handleset for an entrance door?
Both are entrance-function handlesets. The Emtek 3321 Cheyenne is a sandcast bronze mortise set on a Schlage C keyway, requires handing specified as left or right, and is UL listed with a 180 minute fire rating. The Baldwin Wesley handleset is offered with interior knob choices including the Alcott knob and the Carnaby knob.
18) What finishes does the Emtek Cheyenne sandcast bronze handleset come in?
Three: Flat Black Bronze, Medium Bronze, and Tumbled White Bronze. These are solid sandcast bronze, so the surface shows casting texture and the living finishes will deepen with handling, which is the point of the Rustic Living look. Order all openings in one finish and one production run if you need them to match closely.
