Emtek 3021 Cheyenne Sandcast Bronze Mortise Entrance Handleset - Dummy

Yes, handing is required. The Cheyenne 3021 is ordered left hand or right hand, and it applies to all Emtek mortise sets. Stand outside the door: if the hinges are on your left it is left hand, on your right it is right hand. Get it wrong and the thumbpiece and trim orientation will be backwards on the door.

It goes into a standard mortise pocket cut to ANSI A115.1, with a 2-1/2 inch or 2-3/4 inch backset. That is a routed pocket in the door edge, not the two round bores a tubular handleset uses, so a door prepped for a tubular set will not take it without re-prepping.

It ships as a complete set, and you pick the inside trim when you order. Any Emtek Sandcast Bronze knob or lever can be paired with it, including levers like Durango, Teton, Cimarron, Yuma and Montrose, and knobs like Butte, Winchester, Egg and Round. The inside style is a required selection, so the set is not complete until you choose one.

The Emtek 3021 Cheyenne is non-keyed dummy trim, so it will not secure an active entry door. For a keyed entry handleset, the Schlage Residential F60 Addison single cylinder keyed entry handleset with Accent lever is a Grade 2 F Series set for doors 1-3/8 inch to 1-3/4 inch thick, and the Weslock 1411 Traditionale Colonial handleset with Eleganti knob is a single cylinder set for doors 1-3/4 inch to 2-1/4 inch. If the opening is a mortise prep rather than tubular, the Baldwin Estates 6542 Tremont single cylinder entry mortise trim is an entrance-function mortise trim for 1-3/4 inch doors.

The Emtek 3021 Cheyenne is a dummy-function handleset in sandcast bronze, so it has no latch or lock mechanism and simply pulls on a fixed or inactive door. Two other dummy handlesets to consider are the Weslock 6695 Belmont dummy handleset with Impresa knob, in the Elegance Series and fitting doors 1-3/8 inch to 2 inch thick, and the Weslock 2815 Hillcrest dummy handleset with New Heaven lever, in the Premiere Essentials Series, also for 1-3/8 inch to 2 inch doors. The Weslock pair covers a wider door thickness range out of the box, while the Cheyenne is a mortise-prep sandcast bronze set that matches Emtek's Sandcast Bronze collection.

Three: Flat Black Bronze (FB), Medium Bronze (MB) and Tumbled White Bronze (TWB). These are living sandcast bronze finishes, so if you are matching other openings in the same house, stay within the same finish code across the sets.

That is exactly the usual use. On a pair of doors the active leaf takes a keyed mortise entrance set and the inactive leaf takes a dummy like the Cheyenne 3021, so both leaves look identical from the street while only one operates. Order both in the same finish, and remember the dummy still needs handing called out.

The Cheyenne 3021 is a mortise-style dummy in sandcast bronze, prepped for an ANSI A115.1 mortise pocket and ordered handed. The Weslock 2815 Hillcrest with New Heaven lever is a tubular dummy handleset covering 1-3/8 to 2 inch doors, and the Weslock 6695 Belmont with Impresa knob is another dummy option in that family. If the door is already bored for tubular hardware, the Weslock route saves you re-prepping the leaf; if you want the weight and look of cast bronze and a mortise pocket, the Emtek is the one.

They both serve mortise-prepped doors, but the functions differ. The Emtek 3021 Cheyenne is a dummy handleset with no key cylinder, while the Baldwin Estates 6542 Tremont is entrance function and comes in a single cylinder version and a double cylinder version, both listed for 1-3/4 inch doors. Use the Baldwin trim where the door must lock; use the Cheyenne on the inactive leaf of a pair or on a fixed door where you only need matching appearance and a pull.

The Emtek 3021 Cheyenne is built for 1-3/4 inch doors as standard, with thicker doors specified at time of order. If you would rather use a set that publishes a thicker range as standard, the Weslock 1411 Traditionale Colonial handleset covers 1-3/4 inch to 2-1/4 inch, and the Yale Real Living BYRD226NRRX Assure Lock standalone touchscreen deadbolt with Ridgefield handleset also covers 1-3/4 inch to 2-1/4 inch if an electronic deadbolt suits the opening.

The Emtek 3021 Cheyenne requires a standard mortise ANSI A115.1 door prep. If the door is bored for a tubular handleset instead, the Sure-Loc Alta tubular handleset has an adjustable backset, and the Sure-Loc Aspen single cylinder keyed entry handleset and Sure-Loc Madison keyed entry handleset also offer adjustable backsets. Those avoid cutting a mortise pocket, though they do not carry the Cheyenne's sandcast bronze construction.

The Emtek 3021 Cheyenne is a non-electronic dummy handleset. For an electronic opening, the Kwikset 815SCEHFL-CP913CNT San Clemente handleset pairs a Halifax lever interior trim with a contemporary SmartCode keypad electronic deadbolt on 1-3/4 inch doors, and the Yale Real Living BYRD226CBARX Assure Lock adds Wi-Fi and Bluetooth with a Ridgefield handleset for doors 1-3/4 inch to 2-1/4 inch.

No. The Schlage Residential JE285 Barcelona with Seville lever is a Grade 2 J Series handleset with an entrance function that latches without a key, for doors 1-3/8 inch to 1-3/4 inch. The Emtek 3021 Cheyenne is a true dummy - it has no latch at all and mounts as fixed trim. Choose the Schlage if the door needs to latch closed; choose the Cheyenne for an inactive leaf or a door held by a separate catch.

The Emtek 3021 Cheyenne ships as a complete set, with the inside knob or lever style chosen from the Sandcast Bronze range at order. If you only need the outside half because the interior trim is staying, the Kwikset 687AMD SMT Amador single cylinder handleset and the Kwikset 687BW SMT Belleview single cylinder handleset are both exterior-only Grade 3 entrance sets for 1-3/4 inch doors, with the Amador also offered in an SC1 keyway SmartKey version.

It is a residential product, from Emtek's Sandcast Bronze collection in the rustic styling family. For a commercial opening with cycle and grade requirements, look at Grade 1 or Grade 2 hardware instead of this one.

The Emtek 3021 Cheyenne is cast bronze and offered in Flat Black Bronze, Medium Bronze, and Tumbled White Bronze. For a solid brass set instead, Deltana offers the 803871B Hanover, 815871 St. Ann, and 825871 Kingston handlesets, all entry function in solid brass, plus the Deltana 810871 Montego handleset for doors 1-3/8 inch to 2 inch. The Deltana sets are entry function rather than dummy, so confirm the door needs a working latch before substituting.

The Emtek 3021 Cheyenne is a residential sandcast bronze dummy set. If the submittal asks for a graded handleset, the Master Lock HDLBA0615/4D single cylinder deadbolt handleset in the HDLB Series is Grade 2, the Schlage Residential F60 Addison and JE285 Barcelona sets are Grade 2, and the Kwikset 687AMD and 687BW exterior handlesets are Grade 3.
