Emtek Modern Designer Brass Leverset - Aston Lever, Passage Set

Emtek Modern Designer Brass Leverset - Aston Lever, Passage Set

(No reviews yet) Write a Review

Model: 5107.AST.RH.US19
From the Brass Collection
$240.00
$192.00
Selected Concealed Fastener (CF) Mechanism is
Selected Rosette is
Selected Finish is
Selected Handing is
Selected Backset is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$240.00
$192.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Emtek Modern Designer Brass Leverset - Aston Lever, Passage Set

  • Can be ordered with any Brass rosette
  • Sold as complete set. Includes Latch and Strike Plate
  • 28 Degree Latch (included when CF Mechanism is selected)
  • Fits any door between 1-3/8” to 2-1/4" thick with a 2-1/8" bore standard door prep*
  • Standard latch is for 2-3/8" backset. Specify 2-3/4" backset if required

* STRETTO rosette requires a 1-1/4” diameter bore hole and 2-hole door preparation for thumbturn privacy




Specifications:

  • Backset: Adjustable 2-3/8" or 2-3/4"
  • Cross Bore: 2-1/8"
  • Door Thickness: 1-3/8" to 1-3/4"
  • Latch Faceplate: Round or Square Corner
  • Material: Brass

Product Specs

Subcategory:
Leversets
Collection:
Brass
Product Type:
Leversets
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Commercial/Residential:
Residential
Handle Type:
Lever
Lock Type:
Tubular
Series:
Aston
Theme:
Contemporary
Electronic:
No
Keyed Function:
Non-Keyed
Keyed:
No
Lock Function:
Passage
Product Attribute:
Cylindrical Locks
MAP Policy:
Yes
Product Function:
Passage/Hall/Closet
Product Style:
Contemporary
Product Material:
Brass
Product Category:
Mechanical Locks
Product Substrate:
Brass
Department:
Door Hardware

Emtek 5107.AST.RH.US19 – Frequently Asked Questions

1) Will the Emtek Aston passage lever fit a standard 2-1/8 inch bored door?
Yes. The Aston passage leverset drops into a standard door prep with a 2-1/8 inch cross bore. One exception on the rosette side: the STRETTO rosette needs a 1-1/4 inch diameter bore and a 2-hole prep for thumbturn privacy, so it is not a plain standard prep.
2) What door thickness does the Emtek Aston lever work on?
The description gives two ranges for the Aston: the bullet list states it fits any door from 1-3/8 inch up to 2-1/4 inch thick on a 2-1/8 inch bore prep, while the spec block lists door thickness as 1-3/8 inch to 1-3/4 inch. Standard residential and commercial doors at 1-3/8 and 1-3/4 inch are covered either way. If your door is thicker than 1-3/4 inch, note the thickness in the Door Thickness field when ordering so the set is built for it.
3) Does the Emtek Aston passage set come with the latch and strike, or do I order those separately?
It ships complete. The Aston passage set includes the latch and the strike plate, so nothing else is needed to hang it on a prepped door. Latch faceplates come round corner or square corner to match the mortise your door already has.
4) I have 2-3/4 inch backset doors. Can I still use the Emtek Aston lever?
Yes. Backset is a required choice at order and the latch is adjustable for 2-3/8 inch or 2-3/4 inch. The standard latch ships set for 2-3/8 inch, so specify 2-3/4 inch if that is your bore-to-edge dimension. Those are the two common backsets on North American doors, and picking the wrong one leaves the lever misaligned to the strike.
5) Do I need to specify handing on the Emtek Aston passage lever?
Yes, handing is part of the order. The Aston is offered left hand or right hand, so you need to know which way the door swings and which side you are standing on before you buy. Some commercial passage levers, like the Falcon B101, are non-handed and reversible in the field; the Aston is not one of those.
6) What does passage function mean on the Emtek Aston, and is there a lock in it?
Passage means latch only, no lock at all. The Aston passage set is non-keyed and has no privacy turn, so both levers always retract the latch. It is for halls, closets, and pantry doors where you only want the door to stay shut. For a bedroom or bath you need a privacy set with a thumbturn instead.
7) What is a decorative passage lever equivalent to the Emtek Aston if I want a different design family?
The Baldwin Estate 5103 passage lever with the 5048 rose is the closest decorative counterpart. Both are non-keyed passage levers for hall and closet doors. The Emtek Aston is a brass leverset in a contemporary style and can be ordered with Disk, Modern, Modern Rectangular, Neos, Square, or Urban Modern rosettes in eight finishes, so the choice generally comes down to the rose shape and finish you want on the door rather than function.
8) I need a lever that locks for a bedroom or bath - what do I use instead of the Aston passage set?
The Aston passage set is non-keyed and does not latch-lock; it is a hall and closet function. For a bed or bath door, the Baldwin Estate 5103 privacy lever with the 5048 rose is a decorative privacy option, and the Kwikset 300BRNL RDT Breton is a Grade 3 privacy lever set for 1-3/8 to 1-3/4 inch doors. On the commercial side, the Hager 2540 is a Grade 2 cylindrical lock with the Withnell lever for 1-3/8 to 2 inch doors.
9) Is a dummy lever the same thing as the Emtek Aston passage set?
No. The Aston passage set is a working latch - it is sold complete with latch and strike plate and the lever retracts the latch. A dummy lever is surface-mounted trim with no latch at all, used on inactive or closet doors that are held by a ball catch or roller. Dummy options include the Baldwin Estate 5103 half dummy in left and right hand versions, the BEST 9K Series 1DT single dummy trim in Grade 1, the BEST 7KC Series single dummy trim in Grade 2, and the Callan Bentley Grade 2 dummy lever. If you need the door to latch, the passage set is the correct part.
10) My door is 2 inches thick - can I use the Emtek Aston passage set or should I pick something else?
The Aston passage set fits doors from 1-3/8 inch to 2-1/4 inch with a 2-1/8 inch bore standard prep, so a 2 inch door is within range. If you want alternatives at that thickness, the Falcon K101 Grade 1 passage lever covers 1-3/8 inch to 2-1/4 inch, the Arrow GL01 Grade 2 Sierra lever passage lock covers 1-3/4 inch to 2 inch, and the Hager 2510 Grade 2 Withnell passage lever covers 1-3/8 inch to 2 inch.
11) What is the CF mechanism option on the Emtek Aston lever and should I add it?
CF is the concealed fastener mechanism. Add it and the rosettes mount with no exposed screws on the face, which is the cleaner look most people want on a feature door. Choosing CF also brings a 28 degree rotation latch. There is also an option to take the 28 degree rotation latch on its own, or decline CF entirely and run the standard exposed-screw rosette.
12) Which rosette shapes can I get the Emtek Aston lever with?
Six rosettes pair with the Aston lever: Disk, Modern, Modern Rectangular, Neos, Square, and Urban Modern. Any brass rosette in the line can be ordered with it, so you can run round trim on one part of a house and square on another while keeping the same lever and finish.
13) Can I match the Emtek Aston lever to the rest of the hardware in the house?
Eight finishes are offered: Flat Black (US19), French Antique (US7), Oil Rubbed Bronze (US10B), Polished Chrome (US26), Polished Nickel Lifetime (US14), Satin Brass (US4), Satin Nickel (US15), and Unlacquered Brass (US3NL). There is also a split finish field at order if you want a different finish inside than out on a given door.
14) Is the Emtek Aston lever suitable for a commercial building or an apartment turn?
The Aston is a solid brass residential leverset, tubular type, and it carries no commercial grade rating. For a rental turn or a light office it is fine on interior hall and closet doors. For corridor and stairwell traffic in a commercial building, look at a graded passage lever instead, such as the Falcon K101 (Grade 1, heavy duty) or the Accentra 5301LN Augusta (Grade 2).
15) What are the alternatives to the Emtek Aston passage lever if I want a similar decorative look?
For a comparable decorative brass-family passage lever, the Baldwin Estate 5103 passage lever with 5048 rose is the closest peer. If the budget is the driver on interior doors, the Bravura Atlanta or Orlando passage leversets with round trim are Grade 2, and the Kwikset 200BRNL Breton passage lever is Grade 3 and rated for 1-3/8 to 1-3/4 inch doors. None of those offer the concealed fastener rosette the Aston does.
16) Which passage lever should I standardize on for a school or healthcare corridor rather than the Emtek Aston?
For institutional corridors, the Falcon K101 Grade 1 passage lock is heavy duty, fire rated, and non-handed for 1-3/8 to 2-1/4 inch doors, and the Corbin Russwin CL3110 Grade 1 passage lever is vandal resistant and fire rated for 1-3/4 to 2 inch doors. The Dexter C1000 Grade 1 passage lever is clutching and non-keyed for 1-3/8 to 1-3/4 inch doors, and the Design Hardware X75 is a Grade 1 passage lever for 1-3/4 inch doors. The Emtek Aston is a residential brass leverset chosen for its finish and rosette styling.
17) What is a simpler passage leverset than the Emtek Aston for a rental turn?
The Kwikset 200BRNL RDT Breton is a Grade 3 passage lever set for 1-3/8 to 1-3/4 inch doors, and the Callan Asheville is a Grade 3 passage leverset in satin nickel. The Bravura Atlanta, Orlando, and Miramar are Grade 2 passage leversets with round trim, with the Tampa offering square trim. The Emtek Aston differs in being a brass leverset offered across eight finishes with six rosette choices and an optional concealed fastener mechanism that leaves no exposed screws on the rosettes.
18) The Emtek Aston passage set is handed - what passage lever can I order without specifying hand?
The Aston passage set is ordered in Left Hand or Right Hand. If you want to avoid handing on a purchase order, the Falcon B101 is a Grade 2 cylindrical passage lever with a non-handed design and the Falcon K101 is a Grade 1 passage lock with non-handed levers. That matters most when you are stocking spares for a building and do not want two part numbers on the shelf.
19) I need a keyed entry lever in the same door prep as the Emtek Aston passage set - what are my options?
The Aston passage set is non-keyed, so for a keyed opening you need a different lockset. Decorative entry levers include the Deltana 6201 Manchester, 6411 Morant, and 6431 Linstead, all entry function for 1-3/8 inch to 2 inch doors, and the Deltana 5851 Claremont entry lever. On the commercial side, the Cal-Royal AG00 is a Grade 2 entrance lever with a 6-pin Schlage C keyway keyed different on a 2-3/8 inch backset for 1-3/8 to 1-3/4 inch doors, and the Hager 2525 is a Grade 2 entry lever for 1-3/8 inch to 2 inch doors.
20) What Grade 2 commercial passage lever comes closest to the Emtek Aston in door prep terms?
The Accentra 5301LN Augusta is a Grade 2 passage cylindrical lever in the 5300 Series, and the Accentra 4601LN is a Grade 2 passage lever with Augusta trim in the 4600 Series. The Design Hardware J75 is a Grade 2 passage lever with a flat lever for 1-3/4 inch doors. All are passage function like the Aston, which is a tubular, non-keyed lever set with an adjustable 2-3/8 inch or 2-3/4 inch backset and a 2-1/8 inch cross bore.
21) I need matching hardware on a bedroom door and a closet door. Can I mix Emtek Aston functions?
Yes, that is the normal way these are specified. The Aston lever, rosette, and finish stay the same across the house while the function changes per door: passage for hall and closet doors, and a privacy version where you need a thumbturn. Order the same rosette style and finish code on each so the openings read identically.
22) Can I get a keyless pushbutton lever with passage function instead of the Emtek Aston?
Yes. The Lockey 2835 is a mechanical pushbutton keyless lever lock with passage function and ADA compliance for doors 1-3/16 inch to 2 inch thick, and the 2835DC is the double combination version. The Lockey 1150 is a heavy duty mechanical keypad lever set with passage function for 1-1/8 inch to 2 inch doors, with the 1150S offering an adjustable backset. The Emtek Aston passage set is a non-electronic, non-keyed brass leverset with no code entry.
