Sta-Kon RC704 EXP INSNYL RING TERM, No12-10, 5/16

The RC704 is sized for 12-10 AWG stranded copper wire. The yellow nylon insulation is the standard color code for that gauge range, so a yellow barrel tells you at a glance it is the 12-10 terminal and not the blue 16-14 or red 22-18. Running it on 14 AWG leaves the barrel oversized and the crimp unreliable.

Use the ring style, like the RC704. A ring tongue is closed, so it cannot back off a loosening screw the way a spade or fork tongue can, which is why ring terminals are the choice on motors, transformers and anything that vibrates. A fork terminal only earns its place where you need to slip the lug out without fully removing the screw, typically dense terminal blocks on service work.

The barrel is copper, so it is for copper conductors only. Terminating aluminum wire needs an AL9CU or AL-rated connector with the proper inhibitor compound; crimping aluminum into a copper barrel sets up galvanic corrosion at the joint.

Yellow 12-10 insulated terminals like the RC704 need the matching 12-10 nest on an insulated-terminal crimper. The tool is not included with the terminals. Using the smaller 16-14 or 22-18 die will split the nylon sleeve or under-form the barrel, and pliers will not produce a holding crimp.

The RC704 uses nylon insulation rather than vinyl. Nylon takes more abuse during pull-through and flexing, resists cut-through and holds its shape better at elevated temperature, which is why spec jobs and panel builds often call out nylon insulated terminals specifically. The sleeve also supports the wire behind the crimp to cut strand flexing.

Country of origin on the RC704 ring terminal is the United States, which is the detail institutional and government procurement usually needs on record. The part number to reference is RC704.
