Blackburn FB2XD18 FLEX BRAID 9/16 2H 1.25 X 18 INCH

It's a flexible bonding jumper: a flat, braided tin-plated copper strap with a two-hole lug pad at each end. You use it where two pieces of metal have to stay electrically bonded but still move or vibrate relative to each other, or where a rigid conductor would crack. Common spots are across equipment enclosure doors, on busway and switchgear sections, generator and transformer connections, and across expansion joints in raceway or structural steel.

The pad is drilled 9/16 inch, which takes a 1/2 inch bolt with clearance. Both ends are two-hole, so it bolts to a drilled equipment pad or ground bar rather than relying on a single fastener that can rotate. Bolts, nuts and washers are not part of the braid itself, so add hardware in the correct material for your connection.

Yes, it's UL and CSA Listed, so it can be used on both US and Canadian installations where an inspector wants a listed bonding jumper rather than a field-fabricated strap. It's also made in the United States, which matters if the job carries a domestic-content requirement.

Stranded cable resists bending and work-hardens at the termination, so on a hinged door or a vibrating machine base it eventually fatigues and opens the bond. A flat braid flexes across its width through thousands of cycles and keeps a low-impedance path. Use stranded wire for static runs between fixed points, and the braid wherever the two bonded parts move, hinge, or shake. The braid is flat and flexible by construction, which is also why it tucks behind a door hinge where a cable loop would not.

The braid is tin-plated copper, and the tin is there to slow oxidation on the copper and to give a cleaner interface where the pad meets aluminum or galvanized surfaces. That makes it a reasonable choice for damp locations and outdoor enclosures. Bare copper bolted straight to aluminum is the connection that gives trouble; the plating on this braid is what keeps that joint from degrading. Use an antioxidant compound on aluminum landings as usual.

It's sold each, one braid per unit, so if you're bonding a run of enclosure doors or several busway joints, order one per connection point. For a facility standardizing on one jumper, buying the same part number across all openings keeps the spare parts crib simple.
