Mersen Class L Time-Delay Fuse 600A 600VAC/500VDC Blade Terminal Amp-Trap 2000 Series

Mersen Class L Time-Delay Fuse 600A 600VAC/500VDC Blade Terminal Amp-Trap 2000 Series

Professional High-Interrupting Capacity Protection for Critical Power Systems

The Mersen Class L Time-Delay Fuse delivers reliable overcurrent protection with 600A rating and dual voltage capability of 600VAC/500VDC. Featuring blade terminal connections with silver-plated copper construction and GMG body insulating material, this Amp-Trap 2000 series fuse provides professional-grade protection with 200 kA interrupting capacity for demanding electrical applications.

Professional Features & Benefits

• 600A Ampere Rating: Handles high-current applications with reliable overcurrent protection for heavy-duty electrical systems.
• Dual Voltage Capability (600VAC/500VDC): Versatile protection for both AC and DC circuits, supporting diverse power system configurations.
• 200 kA Interrupting Capacity: Exceptional fault current interruption capability ensures safe system protection under extreme conditions.
• Time-Delay Characteristic: Allows temporary overloads while providing fast response to fault conditions, ideal for motor and transformer applications.
• Silver-Plated Copper Terminals: Superior conductivity and corrosion resistance ensure reliable electrical connections and long-term performance.
• Class L Design: Meets stringent safety standards for high-capacity fuse applications with bolted mounting for secure installation.
• RoHS Compliant Construction: Environmentally responsible design meets current regulatory requirements for electrical components.

Technical Specifications

• Ac Max I R Breaking Capacity I1: 200 kA
• Ac Or Dc: AC/DC
• Ampere Rating: 600 A
• Body Insulating Material: GMG
• Connection Terminal Material: Silver-Plated Copper
• Connection Terminal Type: Blade
• Frequency Hz : 50/60 Hz
• Fuse Class: Class L
• Mounting Method: Bolted
• Product Length: 8.63 in
• Product Weight: 2.44 lb
• Rated Voltage Ac Ul: 600 V
• Rated Voltage Dc Ul: 500 V
• Rohs Compliant: Yes
• Speed Characteristic: Time Delay

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Industrial Motor Protection Systems
• Commercial Power Distribution Panels
• Heavy-Duty Transformer Protection
• Manufacturing Equipment Overcurrent Protection
• Data Center Power Infrastructure
• Hospital and Critical Facility Electrical Systems
• Large HVAC System Protection

Why Choose Mersen Quality?

Mersen delivers proven reliability through RoHS compliant construction and Class L safety standards. The silver-plated copper terminals and GMG insulating material ensure long-term durability and consistent performance in demanding electrical environments, backed by professional-grade engineering and quality manufacturing standards.
