Mersen Class RK1 Time-Delay Fuse 15A 600VAC/600VDC with SmartSpot Indication System

Mersen Class RK1 Time-Delay Fuse 15A 600VAC/600VDC with SmartSpot Indication System

Professional Circuit Protection with Advanced Indication Technology

The Mersen Class RK1 Time-Delay Fuse delivers reliable circuit protection for demanding electrical applications. This 15A dual-rated fuse operates at both 600VAC and 600VDC with exceptional 200kA breaking capacity. Featuring SmartSpot indication technology and ferrule terminals with tin-plated copper construction, this Amp-Trap 2000 series fuse provides professional-grade protection with clear operational status visibility.

Professional Features & Benefits

• 15A Current Rating: Provides precise overcurrent protection for medium-load circuits while maintaining reliable operation under normal conditions.
• 600VAC/600VDC Dual Rating: Versatile voltage compatibility enables use in both AC and DC applications, reducing inventory requirements and installation complexity.
• 200kA Breaking Capacity: Exceptional fault current interruption capability ensures safe circuit protection even under severe short-circuit conditions.
• Class RK1 Performance: Superior current-limiting characteristics minimize let-through energy and reduce downstream equipment stress during fault conditions.
• SmartSpot Indication System: Visual indication technology provides immediate fuse status confirmation, reducing troubleshooting time and improving maintenance efficiency.
• Time-Delay Characteristics: Allows temporary overloads while providing fast protection against short circuits, ideal for motor and inductive load applications.
• Ferrule Terminal Design: Tin-plated copper terminals ensure reliable connections and resist corrosion for long-term performance.

Technical Specifications

• Ac Max I R Breaking Capacity I1: 200 kA
• Ac Or Dc: AC/DC
• Ampere Rating: 15 A
• Body Insulating Material: PolyTube
• Connection Terminal Material: Tin-Plated Copper
• Connection Terminal Type: Ferrule
• Frequency Hz : 50/60 Hz
• Fuse Class: Class RK1
• Indication System: Yes
• Indication System Type: SmartSpot�
• Mounting Method: Clip
• Product Length: 5 in
• Product Weight: 0.146 lb
• Rated Voltage Ac Ul: 600 V
• Rated Voltage Dc Ul: 600 V
• Speed Characteristic: Time Delay

Installation & Operation

1. Mount the fuse in a suitable fuse holder or disconnect with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Motor Control Centers and Industrial Equipment Protection
• Commercial HVAC and Lighting Systems
• Power Distribution Panels and Switchgear
• DC Power Systems and Battery Backup Applications
• Manufacturing and Process Control Equipment
• Emergency Power and UPS Systems
• Renewable Energy and Solar Installations

Why Choose Mersen Quality?

Mersen fuses deliver proven reliability through advanced PolyTube insulating materials and precision-engineered current-limiting technology. The SmartSpot indication system and robust tin-plated copper terminals ensure long-term performance and simplified maintenance in demanding electrical environments.
