Mersen Class J Time-Delay Fuse 60A 600VAC/400VDC with SmartSpot Indication System

Mersen Class J Time-Delay Fuse 60A 600VAC/400VDC with SmartSpot Indication System

(No reviews yet) Write a Review

Model: AJT60

In Stock (leaves warehouse same day if ordered before 3pm ET)

$140.79
$90.79
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Mersen Class J Time-Delay Fuse 60A 600VAC/400VDC with SmartSpot Indication System

Professional Time-Delay Protection with Visual Indication Technology

The Mersen Class J Time-Delay Fuse delivers reliable overcurrent protection with 60A rating for both AC and DC applications. Featuring 600VAC/400VDC voltage capability and SmartSpot visual indication system, this ferrule-type fuse provides professional-grade protection with GMG insulating material and tin-plated copper terminals for superior connectivity and durability.

Professional Features & Benefits

  • 60A Current Rating: Provides precise overcurrent protection for medium-duty electrical circuits and equipment applications.
  • Class J Time-Delay Design: Allows temporary overloads while providing fast fault clearing for enhanced equipment protection and reduced nuisance tripping.
  • SmartSpot Indication System: Visual blown fuse indication enables quick identification of fuse status for faster troubleshooting and maintenance.
  • Dual Voltage Rating 600VAC/400VDC: Versatile protection for both AC and DC systems with high voltage capability for demanding applications.
  • 200 kA Breaking Capacity: High interrupting rating ensures reliable fault clearing even under severe short-circuit conditions.
  • Ferrule Terminal Design: Secure clip mounting with tin-plated copper terminals provides reliable electrical connections and easy installation.
  • GMG Insulating Material: Professional-grade body construction ensures reliable insulation and mechanical strength for long-term performance.

Technical Specifications

  • Ac Max I R Breaking Capacity I1: 200 kA
  • Ac Or Dc: AC/DC
  • Ampere Rating: 60 A
  • Body Insulating Material: GMG
  • Connection Terminal Material: Tin-Plated Copper
  • Connection Terminal Type: Ferrule
  • Frequency Hz : 50/60 Hz
  • Fuse Class: Class J
  • Indication System: Yes
  • Indication System Type: SmartSpot�
  • Mounting Method: Clip
  • Product Length: 2.38 in
  • Product Weight: 0.167 lb
  • Rated Voltage Ac Ul: 600 V
  • Rated Voltage Dc Ul: 400 V
  • Rohs Compliant: Yes
  • Speed Characteristic: Time Delay

Installation & Operation

  1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
  2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
  3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
  4. Configure any available load management or control features as supported by the provided specifications.
  5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
  6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

  • Industrial Motor Control Centers
  • Commercial Electrical Panels
  • HVAC Equipment Protection
  • Manufacturing Equipment
  • Power Distribution Systems
  • DC Power Supply Protection
  • Emergency Power Systems

Why Choose Mersen Quality?

Mersen fuses deliver proven reliability with RoHS compliant construction and professional-grade materials. The SmartSpot indication system and high 200 kA breaking capacity ensure dependable protection and easy maintenance for critical electrical systems.

Manufacturer Resources

Product Specs

Ac Max I R Breaking Capacity I1:
200 kA
Ac Or Dc:
AC/DC
Ampere Rating:
60 A
Body Insulating Material:
GMG
Connection Terminal Material:
Tin-Plated Copper
Connection Terminal Type:
Ferrule
Frequency Hz :
50/60 Hz
Fuse Class:
Class J
Indication System:
Yes
Indication System Type:
SmartSpot®
Mounting Method:
Clip
Product Length:
2.38 in
Product Weight:
0.167 lb
Rated Voltage Ac Ul:
600 V
Rated Voltage Dc Ul:
400 V
Rohs Compliant:
Yes
Speed Characteristic:
Time Delay
