Mersen ATQ2 Midget Time-Delay Fuse 500VAC 2A with Ferrule Terminals

Mersen ATQ2 Midget Time-Delay Fuse 500VAC 2A with Ferrule Terminals

Professional Time-Delay Protection for Electrical Systems

The Mersen ATQ2 Midget Time-Delay Fuse delivers reliable overcurrent protection with 500VAC rating and 2A capacity. This professional-grade fuse features ferrule terminals with tin-plated copper construction and GMG body insulating material for dependable performance in demanding electrical applications. Designed for clip mounting with 10 kA breaking capacity at 50/60 Hz frequency operation.

Professional Features & Benefits

• 500VAC Rating: Provides robust voltage handling capability for commercial and industrial electrical systems requiring reliable overcurrent protection.
• 2A Current Rating: Delivers precise amperage protection for sensitive circuits and equipment requiring accurate current limiting.
• Time-Delay Characteristic: Allows temporary overcurrent conditions while providing protection against sustained faults, ideal for motor and inductive load applications.
• 10 kA Breaking Capacity: Offers high fault current interruption capability for enhanced system protection and safety in demanding environments.
• Ferrule Terminal Design: Ensures secure electrical connections with tin-plated copper construction for optimal conductivity and corrosion resistance.
• Midget Class Construction: Compact 1.5-inch length design maximizes space efficiency while maintaining professional performance standards.
• GMG Body Material: Provides superior insulation properties and mechanical strength for reliable long-term operation.

Technical Specifications

• Ac Max I R Breaking Capacity I1: 10 kA
• Ac Or Dc: AC
• Ampere Rating: 2:00 AM
• Body Insulating Material: GMG
• Connection Terminal Material: Tin-Plated Copper
• Connection Terminal Type: Ferrule
• Frequency Hz : 50/60 Hz
• Fuse Class: Midget
• Mounting Method: Clip
• Product Length: 1.5 in
• Product Weight: 0.014 lb
• Rated Voltage Ac Ul: 500 V
• Speed Characteristic: Time Delay

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Motor Control Centers and Starter Panels
• Industrial Control Systems
• Commercial HVAC Equipment
• Lighting Control Circuits
• Instrumentation and Control Panels
• Power Distribution Equipment
• Electronic Equipment Protection

Why Choose Mersen Quality?

Mersen delivers proven reliability through precision engineering and quality construction. The ATQ2 fuse combines time-delay protection characteristics with robust 10 kA breaking capacity and professional-grade materials, ensuring dependable overcurrent protection for critical electrical systems and equipment.
