Mersen Class CC Time-Delay Fuse 0.8A 600VAC/300VDC Ferrule Terminal Amp-Trap 2000 Series

Mersen Class CC Time-Delay Fuse 0.8A 600VAC/300VDC Ferrule Terminal Amp-Trap 2000 Series

Professional Circuit Protection with Superior Breaking Capacity

The Mersen Class CC Time-Delay Fuse delivers reliable circuit protection with 0.8A rating and dual voltage capability of 600VAC/300VDC. This professional-grade fuse features ferrule terminals with tin-plated copper construction and GMG body insulating material for dependable performance in demanding electrical applications. Part of the trusted Amp-Trap 2000 series, this time-delay fuse provides enhanced protection against temporary overloads while responding quickly to short circuits.

Professional Features & Benefits

• 0.8A Current Rating: Precise amperage protection for sensitive circuits and equipment requiring accurate overcurrent protection.
• Class CC Design: Compact form factor with rejection feature prevents installation of higher-rated fuses, ensuring proper circuit protection coordination.
• Time-Delay Characteristic: Allows temporary overloads while providing fast response to short circuits, reducing nuisance tripping in motor and inductive load applications.
• 200 kA Breaking Capacity: Exceptional fault current interruption capability provides superior protection in high-fault current environments.
• Dual Voltage Rating: 600VAC/300VDC capability offers versatility for both AC and DC applications with 50/60 Hz frequency compatibility.
• Ferrule Terminal Design: Tin-plated copper terminals ensure reliable connections and corrosion resistance for long-term performance.
• RoHS Compliant: Environmentally responsible construction meets regulatory requirements for hazardous substance restrictions.

Technical Specifications

• Ac Max I R Breaking Capacity I1: 200 kA
• Ac Or Dc: AC/DC
• Ampere Rating: 0.8 A
• Body Insulating Material: GMG
• Connection Terminal Material: Tin-Plated Copper
• Connection Terminal Type: Ferrule
• Frequency Hz : 50/60 Hz
• Fuse Class: Class CC
• Mounting Method: Clip
• Product Length: 1.5 in
• Product Weight: 0.017 lb
• Rated Voltage Ac Ul: 600 V
• Rated Voltage Dc Ul: 300 V
• Rohs Compliant: Yes
• Speed Characteristic: Time Delay

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Control Circuit Protection in Industrial Equipment
• Motor Control Centers and Switchgear Applications
• Electronic Equipment and Instrumentation Protection
• Commercial Building Electrical Systems
• Process Control and Automation Systems
• Power Distribution Panels and Load Centers
• Renewable Energy System Protection

Why Choose Mersen Quality?

Mersen delivers proven reliability through advanced GMG insulating materials, precision-engineered ferrule terminals, and RoHS compliant construction. The compact 1.5-inch length and lightweight 0.017 lb design combined with clip mounting method ensures easy installation while maintaining the exceptional 200 kA breaking capacity that professionals demand for critical circuit protection applications.
