Mersen 30A 2-Pole Midget Fuse Block 600VAC/600VDC with Reinforced Pressure Plate Clip

Mersen 30A 2-Pole Midget Fuse Block 600VAC/600VDC with Reinforced Pressure Plate Clip

(No reviews yet) Write a Review

Model: 30322

In Stock (leaves warehouse same day if ordered before 3pm ET)

$89.13
$39.13
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Mersen 30A 2-Pole Midget Fuse Block 600VAC/600VDC with Reinforced Pressure Plate Clip

Professional Electrical Protection & Circuit Management

The Mersen 30A 2-Pole Midget Fuse Block delivers reliable circuit protection for both AC and DC applications up to 600V. Featuring glass filled polycarbonate construction and reinforced pressure plate clips, this dual-voltage fuse block provides secure midget fuse installation with flexible screw mount or DIN rail mounting options for professional electrical installations.

Professional Features & Benefits

  • 30A Ampere Rating: Handles substantial electrical loads while providing precise overcurrent protection for critical circuits.
  • 600VAC/600VDC Dual Voltage: Versatile compatibility with both alternating and direct current systems up to 600V for diverse applications.
  • 2-Pole Configuration: Provides simultaneous protection for both conductors, ensuring complete circuit isolation and enhanced safety.
  • Glass Filled Polycarbonate Body: Superior insulating material delivers excellent electrical properties and mechanical durability in demanding environments.
  • Reinforced Pressure Plate Clip: Secure clip-in fuse installation ensures reliable electrical contact and easy maintenance access.
  • Flexible Mounting Options: Accommodates both screw mount and DIN rail installation for versatile panel integration.
  • RoHS Compliant: Meets environmental standards for responsible electrical component manufacturing and installation.

Technical Specifications

  • Ac Or Dc: AC/DC
  • Ampere Rating: 30 A
  • Body Insulating Material: Glass Filled Polycarbonate
  • Frequency Hz : 50/60 Hz
  • Fuse Class: Midget
  • Fuse Installation Method: Clip-in
  • Fuse Type Class: Midget
  • Installation Mounting: Screw Mount or DIN Rail
  • Max Fuse Rating: 30 A
  • Number Of Poles: 2-Pole
  • Product Height: 1.31 in
  • Product Length: 3.04 in
  • Product Weight: 0.23 lb
  • Product Width: 1.6 in
  • Rated Voltage Ac Ul: 600 V
  • Rated Voltage Dc Ul: 600 V
  • Rohs Compliant: Yes
  • Short Circuit Current Rating Sccr : 10 to 100 (dependant on fuse rating) kA
  • Torque Rating: 20 lb-in

Installation & Operation

  1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
  2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
  3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
  4. Configure any available load management or control features as supported by the provided specifications.
  5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
  6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

  • Industrial Control Panels and Motor Control Centers
  • Commercial Electrical Distribution Systems
  • DC Power Systems and Battery Backup Applications
  • Manufacturing Equipment Protection
  • Process Control and Automation Systems
  • Renewable Energy System Protection
  • Professional Electrical Service and Maintenance

Why Choose Mersen Quality?

Mersen fuse blocks deliver proven reliability with glass filled polycarbonate construction and RoHS compliant manufacturing. The reinforced pressure plate design and dual-voltage capability provide professional-grade circuit protection with flexible installation options for demanding electrical applications.

Manufacturer Resources

Product Specs

Ac Or Dc:
AC/DC
Ampere Rating:
30 A
Body Insulating Material:
Glass Filled Polycarbonate
Frequency Hz :
50/60 Hz
Fuse Class:
Midget
Fuse Installation Method:
Clip-in
Fuse Type Class:
Midget
Installation Mounting:
Screw Mount or DIN Rail
Max Fuse Rating:
30 A
Number Of Poles:
2-Pole
Product Height:
1.31 in
Product Length:
3.04 in
Product Weight:
0.23 lb
Product Width:
1.6 in
Rated Voltage Ac Ul:
600 V
Rated Voltage Dc Ul:
600 V
Rohs Compliant:
Yes
Short Circuit Current Rating Sccr :
10 to 100 (dependant on fuse rating) kA
Torque Rating:
20 lb-in
