Mersen UltraSafe Class CC Fuse...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$251.16
$201.16
Mersen UltraSafe Class CC Fuse Holder 600VAC/600VDC 30A 3-Pole DIN Rail Mount

Mersen UltraSafe Class CC Fuse Holder 600VAC/600VDC 30A 3-Pole DIN Rail Mount

(No reviews yet) Write a Review

Model: USCC3

In Stock (leaves warehouse same day if ordered before 3pm ET)

$251.16
$201.16
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Mersen UltraSafe Class CC Fuse Holder 600VAC/600VDC 30A 3-Pole DIN Rail Mount

Professional Class CC Fuse Protection with DIN Rail Mounting

The Mersen UltraSafe Class CC Fuse Holder delivers reliable circuit protection with dual voltage capability of 600VAC/600VDC and 30A rating. This 3-pole unit features DIN rail mounting for easy installation and glass filled polycarbonate construction for durability. The pressure plate design with clip-in fuse installation provides secure connections and professional performance in demanding electrical applications.

Professional Features & Benefits

  • 600VAC/600VDC Dual Voltage Rating: Versatile protection for both AC and DC applications with maximum flexibility.
  • 30A Current Rating: Handles substantial electrical loads while maintaining reliable circuit protection.
  • Class CC Fuse Compatibility: Accepts standard Class CC fuses for consistent, predictable protection characteristics.
  • DIN Rail Mounting: Quick, secure installation in standard electrical panels and enclosures.
  • 200 kA Short Circuit Current Rating: Exceptional fault current handling capability for high-demand applications.
  • Glass Filled Polycarbonate Construction: Superior insulation properties and mechanical strength for long-term reliability.
  • IP20 Protection Rating: Appropriate protection against solid objects for standard electrical environments.

Technical Specifications

  • Ac Or Dc: AC/DC
  • Ampere Rating: 30 A
  • Body Insulating Material: Glass Filled Polycarbonate
  • Frequency Hz : 50/60 Hz
  • Fuse Class: Class CC
  • Fuse Installation Method: Clip-in
  • Fuse Type Class: Class CC
  • Installation Mounting: DIN Rail
  • Max Fuse Rating: 30 A
  • Number Of Poles: 3-Pole
  • Product Height: 2.32 in
  • Product Length: 3.07 in
  • Product Weight: 0.43 lb
  • Product Width: 2.07 in
  • Rated Voltage Ac Ul: 600 V
  • Rated Voltage Dc Ul: 600 V
  • Rohs Compliant: Yes
  • Short Circuit Current Rating Sccr : 200 kA
  • Torque Rating: 15 lb-in
  • Wiring Range: Cu #6-14

Installation & Operation

  1. Mount the unit on DIN rail in a suitable location with appropriate clearance and access for connections and service.
  2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
  3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
  4. Configure any available load management or control features as supported by the provided specifications.
  5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
  6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

  • Industrial Control Panels
  • Commercial Electrical Distribution
  • Motor Control Centers
  • Power Distribution Equipment
  • Automation and Control Systems
  • Manufacturing Facilities
  • Process Control Applications

Why Choose Mersen Quality?

Mersen UltraSafe fuse holders provide dependable circuit protection with RoHS compliant construction and professional-grade materials. The glass filled polycarbonate body and 200 kA short circuit current rating ensure reliable performance in demanding electrical environments, backed by proven engineering and quality manufacturing standards.

Manufacturer Resources

Product Specs

Ac Or Dc:
AC/DC
Ampere Rating:
30 A
Body Insulating Material:
Glass Filled Polycarbonate
Frequency Hz :
50/60 Hz
Fuse Class:
Class CC
Fuse Installation Method:
Clip-in
Fuse Type Class:
Class CC
Installation Mounting:
DIN Rail
Max Fuse Rating:
30 A
Number Of Poles:
3-Pole
Product Height:
2.32 in
Product Length:
3.07 in
Product Weight:
0.43 lb
Product Width:
2.07 in
Rated Voltage Ac Ul:
600 V
Rated Voltage Dc Ul:
600 V
Rohs Compliant:
Yes
Short Circuit Current Rating Sccr :
200 kA
Torque Rating:
15 lb-in
Wiring Range:
Cu #6-14
