Mersen Class J High-Speed Fuse 60A 600VAC/500VDC Ferrule Terminal Amp-Trap

Mersen Class J High-Speed Fuse 60A 600VAC/500VDC Ferrule Terminal Amp-Trap

Professional High-Speed Circuit Protection with 200kA Breaking Capacity

The Mersen Class J High-Speed Fuse delivers reliable circuit protection with 60A ampere rating and dual voltage capability of 600VAC/500VDC. Featuring ferrule terminal connections with tin-plated copper construction and GMG body insulating material, this Amp-Trap fuse provides professional-grade protection with 200kA AC breaking capacity and high-speed characteristics for demanding electrical applications.

Professional Features & Benefits

• 60A Ampere Rating: Provides precise overcurrent protection for medium-duty electrical circuits and equipment loads.
• Dual Voltage Capability (600VAC/500VDC): Offers versatile protection for both AC and DC applications with professional voltage ratings.
• 200kA Breaking Capacity: Delivers exceptional fault current interruption capability for high-demand electrical systems.
• Class J High-Speed Design: Ensures rapid fault clearing to minimize equipment damage and system downtime.
• Ferrule Terminal Construction: Features tin-plated copper terminals for reliable connections and corrosion resistance.
• GMG Body Material: Provides durable insulation and mechanical protection in professional installations.
• RoHS Compliant: Meets environmental standards for responsible electrical component manufacturing.

Technical Specifications

• Ac Max I R Breaking Capacity I1: 200 kA
• Ac Or Dc: AC/DC
• Ampere Rating: 60 A
• Body Insulating Material: GMG
• Connection Terminal Material: Tin-Plated Copper
• Connection Terminal Type: Ferrule
• Frequency Hz : 50/60 Hz
• Fuse Class: Class J
• Mounting Method: Clip
• Product Length: 2.38 in
• Product Weight: 0.157 lb
• Rated Voltage Ac Ul: 600 V
• Rated Voltage Dc Ul: 500 V
• Rohs Compliant: Yes
• Speed Characteristic: High Speed

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Industrial Motor Control Centers
• Commercial Electrical Panels
• HVAC Equipment Protection
• Manufacturing Facility Power Distribution
• Data Center Electrical Systems
• Professional Building Services
• Emergency Power Systems

Why Choose Mersen Quality?

Mersen delivers professional-grade fuse protection with RoHS compliant manufacturing and proven Class J high-speed performance. The compact 2.38-inch length and lightweight 0.157 lb design provide reliable circuit protection with clip mounting convenience for professional electrical installations.
