Eaton D3PR5T1 General Purpose ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$140.86
$90.86
Eaton D3PR5T1 General Purpose Plug-In Relay, D3PR, Standard relay, Test button, 24 Vdc, DPDT latching (D3PR only), 11 pin, 350 ohms

Eaton D3PR5T1 General Purpose Plug-In Relay, D3PR, Standard relay, Test button, 24 Vdc, DPDT latching (D3PR only), 11 pin, 350 ohms

(No reviews yet) Write a Review

Model: D3PR5T1
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$140.86
$90.86
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
General Purpose Plug-In Relay, D3PR, Standard relay, Test button, 24 Vdc, DPDT latching (D3PR only), 11 pin, 350 ohms

Manufacturer Resources

Product Specs

Actuator:
Test button
Certifications:
cRUus
Coil Voltage:
24 Vdc
Compliances:
CE Marked
Contact Configuration:
DPDT latching (D3PR only)
Number Of Pins:
11
Resistance:
350 Ω
Series:
D3PR
Product Group:
Electrical
Department:
Electrical
Product Details:
Standard relay

Eaton D3PR5T1 – Frequently Asked Questions

1) What is this D3PR relay used for?
This general purpose DPDT relay switches two separate circuits simultaneously. Common applications include HVAC controls, lighting systems, motor controls, and industrial automation. The latching design maintains position until reset.
2) What does DPDT latching mean?
DPDT means Double Pole Double Throw - two independent switches that operate together. Latching means the relay stays in position after activation until manually reset or power cycled. Each pole can handle separate circuits.
3) How do I wire the 11-pin configuration?
The 11-pin layout includes coil terminals, two sets of common/NO/NC contacts, and test button connections. Always verify pin assignments on the relay base or manufacturer diagram before wiring. Use proper wire gauge for your load current.
4) What voltage and current can this relay handle?
The coil operates at 24 VDC with 350 ohm resistance. Contact ratings vary by model - check manufacturer specifications for maximum switching voltage and current. Never exceed rated values as this can cause contact welding or failure.
5) How does the test button work?
The test button manually operates the relay without applying coil voltage. Press to verify contact operation and wiring connections. This feature helps troubleshoot circuits and test functionality during installation or maintenance.
6) What type of relay socket do I need?
This relay requires an 11-pin socket that matches the pin configuration. Verify socket mounting style (panel mount, DIN rail, or PCB mount) matches your application. Socket must be rated for your circuit voltage and current.
7) Can I use this relay in wet or outdoor locations?
Check the relay enclosure rating before outdoor use. Most general purpose relays need protection from moisture and temperature extremes. Use appropriate enclosures rated for your environmental conditions.
8) How do I reset a latching relay?
Reset methods depend on the specific latching design. Some require reverse polarity pulse, others need a separate reset coil activation. Check manufacturer documentation for proper reset procedure for your model.
9) What is the coil power consumption?
At 24 VDC with 350 ohm coil resistance, power consumption is approximately 1.6 watts during activation. Latching relays only consume power during switching - not while holding position.
10) How do I troubleshoot relay problems?
Check coil voltage first - should read 24 VDC when activated. Use test button to verify contact operation. Measure continuity across contacts in both positions. Replace if contacts are welded or coil resistance is incorrect.
11) Are there similar relay models available?
Similar general purpose relays are available in different coil voltages, contact configurations, and mounting styles. Consider momentary versions if latching is not required. Check our relay selection for alternatives.
