Glynn-Johnson 70 Series Heavy Duty Surface Overhead Door Holders and Stops with 85° to 110° Hold-Open Range

Glynn-Johnson 70 Series Heavy Duty Surface Overhead Door Holders and Stops with 85° to 110° Hold-Open Range

(1 review) Write a Review

Model: 702H-US26D
$366.00
$246.07
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$366.00
$246.07
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Glynn-Johnson 70 Series Heavy Duty Surface Overhead Door Holders and Stops with 85° to 110° Hold-Open Range

The Glynn-Johnson 70 Series and 79 Series surface-mounted overhead door holders and stops are engineered to meet the rigorous demands of high-traffic industrial and commercial applications. These heavy-duty units offer a hold-open and stop angle range of 85° to 110°, providing flexible door control for a wide variety of openings. Compatible with various door closers, the 70 Series features surface-applied door and jamb brackets that require minimal door and frame preparation, and include templates designed for installation on nearly all door types — including those with conventional butt-type hinges or specialty hinges. Available in heavy gauge brass, 300 Series stainless steel, and steel, the 70 Series delivers the broadest range of finishes in the industry to complement any design aesthetic.

Key Features

  • Wide Hold-Open/Stop Angle Range: Adjustable from 85° to 110° to accommodate a variety of door control requirements in commercial and industrial settings.
  • Non-Handed Design: Simplifies installation and stocking by eliminating the need to specify handing, reducing inventory complexity.
  • Improved Door Closer Compatibility: Enhanced compatibility with door closers provides better door control and reduces wear and tear on all door hardware components.
  • Heavy Gauge Material Options: Available in heavy gauge brass, 300 Series stainless steel, and steel, offering the broadest range of finishes in the industry to complement any design.
  • Superior Corrosion Resistance: Brass and stainless steel construction offer the highest resistance to corrosion for longer-lasting performance across a variety of weather conditions.
  • Surface-Applied Brackets: Door and jamb brackets are surface-mounted, providing reliable door control while requiring minimal door and frame preparation.
  • Template-Assisted Installation: Includes templates designed for installation in almost all door types, including doors with conventional butt-type hinges or specialty hinges, enabling many mounting positions.
  • Two Model Configurations: Available as the 70H Series hold-open model (heavy-duty) or the 70S Series stop-only model (heavy-duty) to suit specific application needs.

Technical Specifications

  • Duty Level: Heavy Duty
  • Product Group: Door Controls
  • Product Subgroup: Overhead Stops and Holders
  • Product Type: Overhead Stops and Holders - Concealed Mount
  • Subcategory: Stops and Holders
  • Commercial/Residential: Commercial
  • Product Category: Door Controls

Typical Applications

  • High-Traffic Industrial Facilities
  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Government and Municipal Buildings
  • Multi-Tenant Residential Properties

Why Glynn-Johnson 70 Series?

Glynn-Johnson 70 Series overhead door holders and stops are built to deliver professional-grade reliability with heavy gauge brass, 300 Series stainless steel, and steel construction that resists corrosion and withstands the demands of high-traffic commercial environments. Engineered for versatility with a non-handed design, broad finish selection, and template-assisted installation, the 70 Series is the trusted choice for contractors and facility managers who require dependable door control performance across a wide range of commercial applications.

Product Specs

Series:
70 Series
Duty Level:
Heavy Duty
Product Group:
Door Controls
Product Subgroup:
Overhead Stops and Holders
Product Type:
Overhead Stops and Holders - Concealed Mount
Subcategory:
Stops and Holders
Commercial/Residential:
Commercial
Product Category:
Door Controls
Department:
Door Hardware

Glynn-Johnson 702H-US26D – Frequently Asked Questions

1) What size Glynn-Johnson 70 Series overhead stop do I need for a 36 inch door?
Size by the width of the door leaf. On doors hung on butt hinges or offset pivots, the 70 Series comes in five bands: 23-1/16 to 27 inches, 27-1/16 to 33, 33-1/16 to 39, 39-1/16 to 45, and 45-1/16 to 54 inches. A 36 inch leaf lands in the 33-1/16 to 39 inch unit. Measure the actual leaf, not the nominal opening size, since a 3-0 opening frequently carries a leaf slightly under or over 36 inches once the frame is accounted for.
2) What is the difference between the 70H and the 70S Glynn-Johnson overhead unit?
Function is the split. The 70H holds the door open at the angle you set it to and keeps it there until someone pulls it shut. The 70S is stop only, so it limits how far the door can swing and then releases immediately. Order the hold-open where people need the door parked open, such as a loading corridor, a move-in door, or a room being aired out. Order stop only where the opening has to self close every time and nothing should be able to catch it open. Both are the heavy duty build.
3) Should I use a surface mounted overhead stop like the Glynn-Johnson 70 Series or a concealed one?
Surface mount is the retrofit answer. The 70 Series uses door and jamb brackets applied to the face of the door and frame, so it goes on with minimal door and frame preparation and does not require an opening that was machined for a stop when it was built. A concealed unit sits in a pocket cut into the top edge of the door and the frame soffit, which is tidier to look at but means routing the door. If the spec calls for concealed, ZenSupply stocks the ABH 1000 Series, the Sargent 690, and the Norton Rixson 1 Series Checkmate on the heavy duty side. If you want surface mount from another brand, the Norton Rixson 10 Series Checkmate is a surface applied stop and holder.
4) My doors are 2-1/2 inches thick. Can the 70 Series door bracket still be through bolted?
Yes. Specify the SNB-2 option, which is the sex bolt set for doors from 2 to 3 inches thick. For anything up to 2 inches, SNB-1 is the correct set. Sex bolts clamp the door bracket through the leaf from both faces instead of relying on screws biting into one face, which is the way to go on a door that has already had hardware in it or on any opening taking real abuse. If you do not add either option, the bracket goes on with the standard fasteners.
5) What is the closest cross-brand equivalent to a Glynn-Johnson 70 Series surface overhead holder?
The Glynn-Johnson 70 Series is a heavy duty surface-mounted overhead holder and stop with an 85 to 110 degree hold-open and stop range, ordered as a hold-open or a stop-only unit, with door and jamb brackets that mount to the face of the door and frame. The nearest surface-mounted peers are the Norton Rixson 10 Series Checkmate units: the 10-236 surface door stop and holder with adjustable hold-open feature and the 10-346 Checkmate surface stop and holder, both carried at medium duty. The DORMA 900 Series is a heavy duty stops and holders line. When the match has to hold on both mounting style and duty level at once, the 70 Series is surface-applied and heavy duty; the Rixson 10 Series units are surface-applied at medium duty.
6) Can I add a 70 Series overhead stop to doors that are already hung, without pulling them out of the frame?
That is what this unit is built for. Both brackets are surface applied to the door and the frame, so installation needs only minimal preparation rather than machining a pocket into the door. Templates cover nearly every door type, including doors on conventional butt hinges and doors on specialty hinges, and they allow a number of mounting positions so you can work around a closer arm or a transom condition that is already there. Practically, this is the overhead stop you put on an existing building rather than one you specify at construction.
7) What do I have to specify when ordering a Glynn-Johnson 70 Series overhead stop?
Four decisions and no handing. Pick the function, hold-open or stop only. Pick the size band off the door leaf width, using the butt hinge and offset pivot column or the center hung column depending on how the door swings. Pick the finish. Then decide the device option: None for the standard bracket set, J for an angle jamb bracket, SNB-1 for sex bolts on doors up to 2 inches, SNB-2 for sex bolts on doors 2 to 3 inches, or SOC for pin in socket security screws.
8) Do I have to order a left hand or right hand overhead stop for the Glynn-Johnson 70 Series?
No handing to call out. The 70 Series is non-handed, so one unit serves either swing. For anyone stocking spares across a building or a portfolio, that cuts the shelf in half: you carry one part per size, function and finish rather than a left and a right of each.
9) Will a 70 Series overhead stop work on a door that already has a door closer on it?
Yes. The 70 Series is built to run alongside door closers, and the two do different jobs: the closer controls the door coming back, the overhead stop puts a hard limit on how far it opens, anywhere from 85 to 110 degrees. Pairing them keeps the closer arm from taking the shock of a door thrown wide open, which is where closer arms and hinge screws usually die on a high traffic opening. Templates allow several mounting positions, so there is room to place the unit clear of the closer arm already on the door.
10) Will this stop keep an exterior door from being blown open into the wall?
That is the job of the stop-only 70S, which limits the swing at whatever angle you set between 85 and 110 degrees so the leaf never reaches the wall or the adjacent hardware. On an exterior opening the material choice matters as much as the function. The 70 Series is made in heavy gauge brass, 300 Series stainless steel, and steel, with the brass and stainless offering the highest corrosion resistance across weather exposure. For a coastal or wet opening, go stainless or brass rather than steel.
11) This is a light-use interior office door. Is there a lighter overhead stop than a heavy duty Glynn-Johnson 70 Series?
Yes. The Glynn-Johnson 70 Series is heavy duty, built for high-traffic industrial and commercial openings. For an opening that does not see that cycle count, the lower-duty peers are the Don-Jo 3023 concealed overhead stop for 30 inch doors and the Don-Jo 3024 for 36 inch doors, both standard duty; the DORMA 711F standard duty concealed friction stop for a 21 to 27 inch opening; and the Norton Rixson 10-336 standard duty overhead stop with adjustable opening control. A step between the two is the Sargent 1530 concealed mount stop and holder at medium duty, or the Norton Rixson 10-236 and 10-346 Checkmate surface units, also medium duty. Note that the standard duty Don-Jo and DORMA units listed here are stops, so if the office door also has to stand open, stay with a holder such as the 70 Series hold-open, the Sargent 1530, or the Rixson 10-236.
12) I want the door stopped before it hits the wall but I do not want it staying open. What are the stop-only choices?
The Glynn-Johnson 70 Series is ordered in a stop-only function as well as hold-open, so the same surface-mounted heavy duty unit and the same bracket set covers a stop-only opening. Stop-function peers include the ABH 1000 Series heavy duty concealed mount overhead door stop, the Don-Jo 3023 and 3024 concealed overhead door stops in satin stainless steel, the DORMA 711F standard duty concealed friction stop, and the Norton Rixson 10-336 standard duty overhead stop with adjustable opening control. The 70 Series stop-only is the surface-mounted, heavy duty member of that group; the rest of the list is concealed mount, and the 711F is specified as a friction stop.
13) Is a Don-Jo 3024 a drop-in replacement for a Glynn-Johnson 70 Series holder on a 36 inch door?
They are not interchangeable, even though both suit a 36 inch leaf. The Don-Jo 3024 is a concealed overhead door stop for 36 inch doors, finished in satin stainless steel and carried at standard duty, and it is a stop. The Glynn-Johnson 70 Series covers a 36 inch leaf with its 33 1/16 to 39 inch butt and offset pivot band, is heavy duty, is ordered in either hold-open or stop-only function, and mounts with surface-applied door and jamb brackets rather than concealed in the top of the door. Swapping one for the other changes both the door preparation and whether the opening gets a hold-open.
14) What is the difference between a Glynn-Johnson 70 Series hold-open and an overhead unit with adjustable opening control?
The Glynn-Johnson 70 Series sets its hold-open and stop angle anywhere in an 85 to 110 degree range, so the opening angle is dialed in on the unit at install. Peers described with an opening control feature are the ABH 1000A Series with field-adjustable opening control and the ABH 1000RA and 1000SA Series with adjustable opening control, plus the Norton Rixson 10-336 standard duty overhead stop with adjustable opening control and the 10-236 Checkmate with adjustable hold-open. Two peers state a fixed figure instead: the Norton Rixson 1 Series Checkmate at 110 degree opening and the Sargent 1530 concealed mount stop and holder at 110 degree opening. If the job needs the door caught short of 110 degrees, the 70 Series range and the adjustable-control units both address it; a unit specified at 110 degrees is stating a single opening figure.
15) Which overhead stops and holders are carried at heavy duty for a high-traffic entrance?
Four in this class carry a heavy duty rating. The Glynn-Johnson 70 Series is heavy duty and surface mounted, built in heavy gauge brass, 300 Series stainless steel, and steel. The Sargent 690 is a heavy duty overhead concealed door stop and holder, the Norton Rixson 1 Series Checkmate is heavy duty and concealed with a 110 degree opening, and the DORMA 900 Series is a heavy duty stops and holders line. The remaining units sit lower on duty: the Sargent 1530 and the Norton Rixson 10-236 and 10-346 are medium duty, and the Don-Jo 3023, Don-Jo 3024, DORMA 711F, and Norton Rixson 10-336 are standard duty. For a main entrance that cycles all day, the heavy duty four are the shortlist, and the 70 Series is the surface-mounted one among them.
16) The overhead holder has to match oil rubbed bronze hardware already on the doors. Which one comes in that finish?
The Glynn-Johnson 70 Series is the one to reach for on a finish match. It comes in US10B oil rubbed bronze, along with US3 polished brass, US4 satin brass, US10 satin bronze, US26 polished chrome, and US26D satin chrome, plus powder coats in SP4 brass, SP10 bronze, SP28 aluminum, SP313 dark bronze, and SPBLK black. Material follows the finish, with heavy gauge brass, 300 Series stainless steel, and steel bodies. By comparison, the Don-Jo 3023 and 3024 concealed overhead stops are specified in satin stainless steel. If the rest of the opening is oil rubbed bronze, the 70 Series US10B carries that finish through the overhead unit.
17) Corridor doors in a school keep getting the overhead stop pulled off. What holds up better?
There are two ways to answer an abuse problem on an overhead unit. The Glynn-Johnson 70 Series is heavy duty and can be ordered with the fastening that resists removal: SOC pin-in-socket security screws, or SNB-1 sex bolts for the door bracket on doors up to 2 inches and SNB-2 for doors from 2 to 3 inches, which pull the bracket through the door rather than into the face alone. The J angle jamb bracket is available where the jamb condition needs it. The other approach is to take the arm off the face entirely with a concealed heavy duty unit, either the Norton Rixson 1 Series Checkmate concealed stop and holder or the Sargent 690 overhead concealed stop and holder. Both are heavy duty and mount concealed instead of surface applied.
18) Glynn-Johnson 70 Series or Sargent 690 for a heavy duty stop and holder?
Both are heavy duty stop and holder units, and the deciding factor is the door preparation. The Sargent 690 is an overhead concealed door stop and holder, so the arm and track live in the top of the door. The Glynn-Johnson 70 Series mounts on the surface with door and jamb brackets and needs only minimal door and frame preparation, which is what makes it workable on doors already hung and on frames that were never prepped for a concealed unit. The 70 Series is also non-handed, so the same unit works on either hand of an opening, it adjusts across an 85 to 110 degree hold-open and stop range, and it is ordered as hold-open or stop-only. On a retrofit the 70 Series avoids mortising the door top; on new work where the prep is being done anyway, the concealed 690 keeps the hardware out of sight.
19) What finishes do Glynn-Johnson 70 Series overhead holders come in, and will one match the rest of my door hardware?
Eleven finishes, split between plated and powder coat. Plated: US3 polished brass, US4 satin brass, US10 satin bronze, US10B oil rubbed bronze, US26 polished chrome, US26D satin chrome. Powder coat: SP4 brass, SP10 bronze, SP313 dark bronze, SP28 aluminum, SPBLK black. US26D satin chrome is the usual commercial default and is what most levers, closers and hinges in an office or school building are already finished in, so it is the safe match when you are adding stops to an existing standard. Dark bronze and black come in powder coat only.
20) Is there a tamper resistant fastener option for overhead door stops in a school or detention area?
Specify the SOC option on the 70 Series and the unit ships with pin in socket security screws, which need a pinned driver rather than a standard hex key to back out. Worth pairing with the SNB-1 or SNB-2 sex bolts if the doors are up to 2 inches or 2 to 3 inches thick respectively, since through bolting the door bracket removes the other easy way to pull the hardware off the door.
How fast can I get the Glynn-Johnson 702H-US26D delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Glynn-Johnson 702H-US26D come with a warranty?
Absolutely. The Glynn-Johnson 702H-US26D is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Glynn-Johnson 702H-US26D?
You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us
Why buy the Glynn-Johnson 702H-US26D from ZenSupply?
ZenSupply makes it easy to get the commercial door hardware you need—fast shipping, expert support, and rewards on every order. Our team is always ready to help you choose the right product for your project.

Product Reviews

  • 5
    Reliable and durable door holders and stops for smooth functionality.

    Posted by Olivia on Jul 13th 2023

    Hey everyone! I recently got my hands on the Glynn Johnson 70 Series Heavy Duty Surface Overhead Door Holders/Stops from ZenSupply, and they're awesome. The build quality is top-notch, providing excellent durability. One standout feature is the smooth operation, allowing doors to stay securely open without any issues. However, keep in mind that the installation process might require some additional tools and expertise. Overall, these door holders and stops are reliable and deliver smooth functionality for any heavy-duty doors.

!
