Hager 282D Manual Flush Bolt with 12" Rod Length and Brass Faceplate

Hager 282D Manual Flush Bolt with 12" Rod Length and Brass Faceplate

Professional Fire-Rated Door Hardware Solution

The Hager 282D Manual Flush Bolt delivers reliable door securing performance with a 12" rod length and 1" x 6-3/4" brass faceplate. Engineered for hollow metal and fire-rated doors, this non-handed flush bolt features a 3/4" bolt height with 3/4" backset and brass faceplate with steel components. The unit meets ANSI 156.16 standards and provides three-hour fire rating for metal doors up to 4' wide by 10' tall.

Professional Features & Benefits

• Fire-Rated Performance: Three-hour fire rating for metal doors up to 4' wide by 10' tall ensures code compliance in critical applications.
• Precision Dimensions: 12" rod length from center of face to corner of door with 1" x 6-3/4" brass faceplate for reliable door securing.
• Adjustable Bolt Design: Bolt heads are field-adjustable for precise alignment and optimal door fit across various installations.
• Heavy-Duty Construction: Brass faceplate with steel components provides exceptional durability for commercial door applications.
• Universal Installation: Non-handed design simplifies installation and inventory management for various door configurations.
• ANSI Compliance: Meets ANSI 156.16 for L04251 ensuring professional-grade performance standards.
• Complete Fastener Package: Includes eight #8 x 3/4" and eight #8 x 1-1/2" combo screws for secure mounting.
• Compatible Accessories: Optional 282S strike plate bag and 282P bolt head available for extended configurations.

Technical Specifications

• ANSI/BHMA: Three-hour fire rating for metal doors up to 4' wide by 10' tall Meets ANSI 156.16 for L04251
• Bolt: Backset: 3/4" (19 mm)
• Bolt Height: 3/4" (19 mm)
• Commercial/Residential: Commercial
• Faceplate: 1" x 6-3/4" (25 mm x 171 mm)
• Fasteners: Eight #8 x 3/4" combo screws, Eight #8 x 1-1/2" combo screws
• Finishes: US 3, US10B, US15, US19, US 26,US26D
• Material: Brass faceplate with steel components
• Notes: 282Sstrike plate bag and 282Pbolt head available
• Rod Length: 12" (305 mm) from center of face to corner of door
• Subcategory: Flush Bolt

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including door thickness and material compatibility for hollow metal or fire-rated door applications.
2. Use manufacturer-provided templates to mark mounting hole locations accurately on door surfaces, ensuring proper alignment with the 1" x 6-3/4" faceplate dimensions.
3. Prepare door by drilling required holes and routing as specified in manufacturer instructions, maintaining 3/4" backset requirements.
4. Install mounting hardware using provided #8 x 3/4" and #8 x 1-1/2" combo screws and secure the flush bolt per manufacturer torque specifications.
5. Adjust bolt heads for proper alignment and smooth operation throughout the full 12" rod length travel.
6. Test flush bolt operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Commercial Office Buildings
• Educational Facilities
• Healthcare Institutions
• Government and Municipal Buildings
• Industrial and Warehouse Facilities
• Fire-Rated Door Assemblies
• Multi-Tenant Residential Properties

Why Choose Hager Quality?

Hager flush bolt products deliver professional-grade reliability with brass faceplate and steel component construction rated for three-hour fire performance on metal doors up to 4' wide by 10' tall. ANSI 156.16 compliance ensures dependable operation in demanding commercial applications. Engineered for fire-rated door assemblies where code compliance and reliable securing performance are essential.
