Hager RC1541 Solid Brass or Stainless 1/4” Radius Round Corner Full Mortise Residential Weight Plain Bearing with Screws

Hager RC1541 Round Corner Full Mortise Plain Bearing Residential Hinge with 1/4" Radius

(No reviews yet) Write a Review

Model: RC1541-3.5X3.5-26D
$19.58
Selected Finish is
Selected Package Option is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$19.58
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Hager RC1541 Round Corner Full Mortise Plain Bearing Residential Hinge with 1/4" Radius

Professional Residential Door Hinge Solution

The Hager RC1541 is a 5-knuckle round corner full mortise plain bearing hinge designed for residential applications. Available in 3-1/2" x 3-1/2" and 4" x 4" sizes with 1/4" radius round corners, this medium-duty hinge features solid brass or stainless steel construction with matching pins. The reversible design with removable pin provides installation flexibility, while ANSI A2134 (brass) and ANSI A5134 (stainless steel) certifications ensure quality standards compliance.

Professional Features & Benefits

  • Dual Size Options: Available in 3-1/2" x 3-1/2" and 4" x 4" dimensions to accommodate various residential door applications.
  • Round Corner Design: 1/4" (6mm) radius round corners provide smooth installation and professional appearance.
  • Premium Materials: Solid brass with brass pin or stainless steel with stainless steel pin construction for long-lasting durability.
  • Reversible Installation: Reversible design with removable pin allows flexible installation for left or right-hand doors.
  • 5-Knuckle Configuration: Five-knuckle design with .085" gauge and .234" pin diameter provides stable door support.
  • ANSI Certified: Meets ANSI A2134 (brass) and ANSI A5134 (stainless steel) standards for residential weight requirements.
  • Complete Hardware Package: Includes 3/4" x 9" flat head wood screws for immediate installation.
  • Multiple Finish Options: Available in US3, US15A/AN, US26, US26D, US32D, and 10R finishes to match door hardware.

Technical Specifications

  • ANSI/BHMA: ANSI A5134
  • Commercial/Residential: Residential
  • Corner Style: Round
  • Duty Level: Medium Duty
  • Features: Full Mortise, Spring Hinge, 5/8" Round Corner Radius, Standard Weight
  • Knuckles: 5
  • Subcategory: Full Mortise Hinges

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness, stile width, and handing as applicable to this product.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and frame surfaces.
  3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
  4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
  5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
  6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Residential Entry Doors
  • Interior Passage Doors
  • Bedroom and Bathroom Doors
  • Closet and Utility Room Doors
  • Multi-Family Housing Units
  • Residential Renovation Projects
  • Custom Home Construction

Why Choose Hager Quality?

Hager RC1541 hinges deliver professional-grade reliability with solid brass or stainless steel construction meeting ANSI certification standards. The 5-knuckle design with .085" gauge provides dependable performance for residential applications. Engineered for demanding residential use where consistent door operation and long-term durability are essential.

Product Specs

Knuckles:
5
Subcategory:
Full Mortise Hinges
Product Subgroup:
Full Mortise Hinges
Features:
Full Mortise, Spring Hinge, 5/8" Round Corner Radius, Standard Weight
ANSI/BHMA:
ANSI A5134
Duty Level:
Medium Duty
Product Group:
Door Hinges and Pivots
Product Type:
Full Mortise Hinges
Commercial/Residential:
Residential
Corner Style:
1/4" Radius Corners
Product Model:
RC1541
Product Function:
Plain Bearing
Product Substrate:
Steel
Product Category:
Door Hinges and Pivots
Department:
Door Hardware

Hager RC1541-3.5X3.5-26D – Frequently Asked Questions

1) Will the Hager RC1541 hinge fit my door if the mortise pockets have rounded corners?
The RC1541 is a round corner hinge with a 1/4 inch corner radius, so it drops into a router-cut pocket made with a 1/4 inch radius bit. That is the common radius on residential doors and frames cut with a hinge template. If your existing pockets are square cut (chiseled corners), a square corner hinge is the right part instead; a round corner leaf will leave a gap at each corner.
2) What sizes does the Hager RC1541 come in, and which one do I need?
Two leaf sizes: 3-1/2 x 3-1/2 inches and 4 x 4 inches. Match whatever is already in the door, since the pocket is cut for a specific leaf. As a rule of thumb, 3-1/2 inch hinges carry standard 1-3/8 inch interior doors and 4 inch hinges are used on 1-3/4 inch entry and heavier doors. If your openings need 4-1/2 x 4-1/2, that is a commercial size the RC1541 does not cover.
3) Can I get the Hager RC1541 with a non-removable pin for an outswing exterior door?
Yes. Pin type is an order option: removable pin or non removable pin. Non removable is the one to specify on an outswing door where the barrel is exposed on the outside, since it stops someone driving the pin out to lift the door off. On inswing interior doors the removable pin is easier to live with, because you can pull the door without unscrewing anything.
4) Is the Hager RC1541 heavy duty enough for a commercial building's doors?
The RC1541 is a medium duty, residential weight hinge certified to ANSI A5134, and it runs on a plain bearing rather than a ball or concealed bearing. That suits apartments, interior passage doors and single-family entries. For a high-traffic commercial opening or a door with a closer on it, step up to a ball or concealed bearing hinge such as the BEST 1900R or the Stanley Security CB1960R, or the heavy duty McKinney TCA3386 where the door is oversized.
5) Can the RC1541 be used where the door needs to swing fully clear of the opening for wheelchair access?
No. The RC1541 is a standard full mortise hinge, so the leaf and hinge stay in the opening when the door is open. A swing clear hinge is the different part: the BEST CB248 is a steel full mortise concealed bearing swing clear hinge for square edge doors, rated medium duty like the RC1541. Use the swing clear geometry where the clear opening width has to be recovered; the RC1541 is the right choice only where standard clearance is acceptable.
6) What is the closest equivalent to the Hager RC1541 residential hinge for a commercial opening?
The RC1541 is a plain bearing, medium duty, residential weight full mortise hinge with 1/4 inch radius round corners. For a commercial door, the bearing hinges are the peer group: the BEST 1900R steel full mortise concealed bearing standard weight hinge with removable pin is also medium duty, and the Stanley Security CB1960R full mortise concealed bearing standard weight hinge is medium duty as well. Both use a concealed bearing instead of the RC1541 plain bearing knuckle. Confirm corner style before ordering - the RC1541 is round corner, and the round versus square corner decision is set by the existing mortise in the door and frame.
7) The door mortise has square corners - what hinge should be used instead of the RC1541?
The RC1541 is cut with 1/4 inch radius round corners, so it will not sit correctly in a square corner mortise without rework. Square corner full mortise hinges in the same 5 knuckle format include the Don-Jo BB74545 in steel, the Don-Jo BB94545 in stainless steel, and the McKinney TCA2314 and TCA2317 at 4-1/2 by 4-1/2 inches, all standard duty. The BEST FBB212 ball bearing hinge is also built for square edge doors. Match the corner style to what is already routed in the door and frame - that is what decides this, not the material.
8) The RC1541 is rated residential - what carries a heavy weight door instead?
The RC1541 is a medium duty residential weight hinge. For a heavier leaf, the heavy weight options are the McKinney TCA3386 square corner 5 knuckle hinge at 4-1/2 by 4-1/2 inches, the Stanley Security CB199 full mortise concealed bearing heavy weight hinge, and the BEST CB223 stainless steel concealed bearing heavy weight pivot reinforced hinge for beveled edge doors. The CB223 is specific to beveled edge doors, so verify the door edge before specifying it.
9) The existing hinges are 4-1/2 by 4-1/2 inches - will the RC1541 drop in?
No. The RC1541 comes in 3-1/2 by 3-1/2 inch and 4 by 4 inch sizes, so it will not fill a 4-1/2 by 4-1/2 inch mortise. At that size the full mortise options are the Don-Jo BB74545 in steel, BB84545 in brass and BB94545 in stainless steel, the McKinney TCA2314 and TCA2317 at standard weight, the TCA3386 at heavy weight, and the ACSI 5BB1 where an electric through-wire hinge is needed. Measure the existing leaf height and width at the door before ordering, since a taller mortise cannot be filled by a shorter hinge.
10) Is the Hager RC1541 handed, or does one hinge work on both left and right hand doors?
Not handed. The RC1541 is reversible, so the same hinge works on a left hand or right hand door; you just flip the leaf and drop the pin in from the top. That means you can stock one part number for a whole building instead of splitting your order by handing.
11) Do I need to buy screws separately for the Hager RC1541 hinges?
No, screws come in the box. Each RC1541 ships with flat head wood screws, so you can hang the door without a separate fastener order. Wood screws are what you want in a wood jamb; if you are going into a hollow metal frame you will need machine screws instead, which are not what is supplied here.
12) What finishes does the Hager RC1541 hinge come in, and can I match my existing satin nickel hardware?
Six finishes: 605 bright brass, 619 satin nickel, 625 bright chrome, 626 satin chrome, 630 satin stainless steel, and US10R dark bronze. Satin nickel (619) is there, so it will match satin nickel levers and deadbolts. Note that 626 satin chrome and 619 satin nickel read differently side by side, so pick the one that matches the lockset already on the door rather than going by the word satin.
13) How many knuckles does the Hager RC1541 have, and will it line up with the hinges already on my doors?
Five knuckles, which is the standard residential and light commercial pattern, so the barrel will look consistent alongside other 5-knuckle hinges on your other openings. What actually decides whether it drops in is the leaf size and the corner radius, not the knuckle count: match 3-1/2 x 3-1/2 or 4 x 4 to the existing pocket and confirm the pocket corners are rounded.
14) Is the Hager RC1541 available in stainless steel for a coastal or high-humidity opening?
Yes. The RC1541 is offered in solid brass with a brass pin or stainless steel with a stainless pin, and 630 satin stainless steel is one of the six finishes. Stainless in 630 is the usual pick for exterior and damp locations where a plated finish would eventually break down.
15) What is the difference between the plain bearing RC1541 and a ball bearing hinge like the Don-Jo BB74545?
The RC1541 uses a plain bearing 5 knuckle joint and is a medium duty residential weight hinge in 3-1/2 by 3-1/2 inch and 4 by 4 inch sizes with 1/4 inch radius round corners. The Don-Jo BB74545 is a full mortise ball bearing hinge, 4-1/2 by 4-1/2 inches, steel, square corner, 5 knuckle, standard duty - the bearing races sit between the knuckles to carry higher cycle counts and heavier leaves. Ball bearing versions in other materials at the same size include the BB84545 in brass and the BB94545 in stainless steel, plus the BB74540 at 4-1/2 by 4 inches in satin chrome. Size and corner style both change here, so the mortise has to match.
16) Is the ACSI 5BB1 a substitute for the RC1541 on an access control opening?
They are not interchangeable. The RC1541 is a plain bearing hinge with no wiring provision, offered in 3-1/2 by 3-1/2 inch and 4 by 4 inch sizes. The ACSI 5BB1 is a 5 knuckle ball bearing full mortise hinge at 4-1/2 by 4-1/2 inches with concealed electric through-wire, 4 wire at 28ga, to carry power to an electrified lock or monitored device in the door. If the opening needs transfer of power through the hinge, the electric through-wire hinge is the part to order; the RC1541 covers the remaining non-electrified hinge positions on the same door.
17) Are there other removable pin hinges besides the RC1541 for doors that need to come off the frame?
The RC1541 is offered in both removable pin and non removable pin versions, so the same model covers doors that get lifted off and openings where the pin should not be accessible from the secure side. Among the bearing hinges, the BEST 1900R is a steel full mortise concealed bearing standard weight hinge specified with a removable pin, at medium duty. On an out-swinging exterior door, choose the non removable pin configuration rather than a removable pin hinge of any make.
18) Can I buy Hager RC1541 hinges by the pair, or only one at a time?
Both. The RC1541 is sold as a single hinge or as a box of 2. Most residential doors take three hinges per leaf, so plan on a box of 2 plus a single, or three singles, per door.
19) Which hinge matches satin chrome hardware if the RC1541 does not fit the opening?
The RC1541 is offered in 605 bright brass, 619 satin nickel, 625 bright chrome, 626 satin chrome, 630 satin stainless steel, and US10R dark bronze. If the size or corner style rules it out, satin chrome peers at 4-1/2 by 4-1/2 inches include the Don-Jo BB84545 brass ball bearing hinge in satin chrome, and the Don-Jo BB74540 at 4-1/2 by 4 inches in satin chrome. Keep the finish consistent across every hinge on the same door leaf, since a single mismatched leaf is visible from across a corridor.
