Certifications
- IEC Rated
- UL Recognized
Product Compliance
- CE Marked
- RoHS Compliant
Manufacturer Resources
Product Specs
- Amperage Rating:
- 63A RMS
- Application:
- DC common bus, DC drives, power converters/rectifiers
- Class:
- Class aR
- Clearing I2t :
- Clearing at 660V: 770
- Clearing Loss:
- 14
- Connection:
- Blade end X blade end
- Fuse Indicator:
- Non Indicating
- Height:
- 2.087 IN
- Interrupt Rating:
- 200 kAIC
- Length:
- 5.433 IN
- Mounting:
- Din 43 620 blade style
- Packaging Type:
- Standard
- Pre Arc I2t :
- Current pre-arc: 115
- Type:
- Square body -/110 visual for micro
- Voltage Rating:
- 700 Vac (UL), 690 Vac (IEC)
- Weight:
- 1.6456 LB
- Width:
- .315 IN
- Product Group:
- Electrical
