Manufacturer Resources
Spec Sheet
Product Specs
- Actuator Color:
- White
- Bus Material:
- Glass
- Legend:
- Blank legend
- Product Category:
- Lens
- Series:
- 10250T
- Used With:
- Indicating light or master test pushbutton
- Department:
- Electrical
- Product Type:
- 30.5 mm, Heavy-Duty Watertight/Oiltight
- Product Length:
- 1.2 IN
- Product Details:
- 30.5 mm, Heavy-Duty Watertight/Oiltight
- Product Height:
- 1 IN
- Product Weight:
- .07 LB
- Product Width:
- 1.2 IN
Eaton 10250TC12N – Frequently Asked Questions
1) Does the Eaton 10250TC12N come with a legend or marking on the lens?
No marking. The 10250TC12N ships with a blank legend in white, so you label it yourself or use it where no text is needed. If your panel drawing calls for a legend such as RUN, STOP, or POWER ON, you need a pre-marked lens cap in that color instead of the blank one.
2) Can I use the 10250TC12N lens on a master test pushbutton, or only on a pilot light?
Both. Eaton lists the 10250TC12N for use with either a 10250T indicating light or a master test pushbutton, which is the push-to-test style unit that lets an operator confirm the lamp is good without energizing the circuit. The lens is the same cap for either body.
3) Does the Eaton 10250TC12N include the lamp, socket, or contact block?
No. The 10250TC12N is the lens only, a replacement or spare cap for a 10250T indicating light or master test pushbutton. The light unit, lamp, and any contact blocks are ordered separately. For a straight lens replacement on an existing panel device that is all you need.
4) Is the Eaton 10250TC12N lens glass or plastic?
Glass. The 10250TC12N uses a glass lens, which holds up better to heat from incandescent lamps and to solvent or oil wipe-downs than plastic caps. That matters on machine tool panels and wash-down areas where the heavy-duty watertight/oiltight 10250T devices are typically used.
5) What color is the Eaton 10250TC12N indicating light lens?
White. On a 10250T pilot light the lens color is what the operator reads, so white is the choice where the indication is not status-coded, or where the legend plate below the unit carries the meaning. Red, green, and amber caps are separate catalog numbers in the same series, so order by color rather than swapping later.
6) Will a glass 10250T lens keep my enclosure watertight?
The 10250TC12N belongs to Eaton's heavy-duty watertight/oiltight 30.5 mm line, so the lens is part of a sealed assembly rather than an open bezel. Seal integrity still depends on the light unit's own gasket being intact and the cap being seated tight against it, so inspect the gasket when you swap a cracked lens.
