INS NYLON PIN TERM 12-10 AWG YELLOW
Manufacturer Resources
Product Specs
- Country Of Origin:
- United States (US)
- Product Subgroup:
- General Terminals
- Product Type:
- Nylon Insulated Pin Terminal
- Standards:
- UL E9809
- Voltage Rating:
- 300 V
- Wire Size:
- 12-10 AWG
- Department:
- Electrical
- Product Group:
- Wire Termination
- Product Color:
- Yellow
- Product Material:
- Copper
Sta-Kon RC155PT – Frequently Asked Questions
1) What wire size does the Sta-Kon RC155PT pin terminal accept?
The RC155PT takes 12 to 10 AWG conductors. The yellow nylon insulation is the color code that tells you that at a glance on the job, so if you're pulling 14 or 16 AWG you need a smaller barrel (blue covers the 16-14 range), not this one. Crimping 14 AWG into a 12-10 barrel gives you a loose joint that can back out of the terminal block.
2) Can I use a nylon insulated pin terminal on a 277 volt control circuit?
No. The RC155PT is rated 300 V, which covers 120 and 277 V nominal circuits, but it is not a 600 V terminal. For motor feeders and panel work above 300 V you need a 600 V rated lug instead.
3) Is the Sta-Kon RC155PT UL listed?
Yes. It carries UL file E9809, which is what an institutional or MRO inspector will want to see on control panel and switchgear work. It's also made in the United States, so it will satisfy domestic-origin requirements on government and federally funded jobs.
4) Is a pin terminal or a fork terminal better for a terminal block with a clamping screw?
A pin terminal like the RC155PT is the one you want for clamp-type or cage-clamp terminal blocks, where the conductor drops down a hole and a screw bears on it. The solid pin stays put and won't fray the way bare stranded wire does. Fork (spade) and ring terminals are for terminals with a screw and washer you can land a tongue under, and a ring terminal is the choice wherever the connection can't be allowed to slip off if the screw loosens.
5) Are these pin terminals copper or aluminum?
The barrel is copper, so the RC155PT is for copper conductors only. Don't crimp it onto aluminum wire; that needs an AL/CU rated connector with the antioxidant compound. The nylon sleeve over the copper barrel gives you more abrasion and flex resistance than vinyl, which is why nylon is the usual pick for panel wiring that gets handled.
6) Do I need a special crimper for Sta-Kon 12-10 AWG insulated terminals?
Yes, these are a crimp-on connection, not solderless push-fit. Use an insulated-terminal crimp tool set to the yellow 12-10 AWG nest. The tool is sold separately. A generic pliers crimp on a nylon barrel will crack the sleeve or under-form the barrel, and the UL listing applies to a properly formed crimp.
7) Can I standardize on one terminal across a panel, or do I need several sizes?
You'll need more than the RC155PT. It only covers 12 and 10 AWG, so anything in the 16-14 or 22-18 range in the same panel takes a different size barrel. For a facility stocking program, pick the pin terminal in each color code band you actually run and keep the yellow RC155PT for your 12 and 10 AWG circuits.
