INS WIRE JOINT 2.0-6.0MM2
Manufacturer Resources
Product Specs
- Country Of Origin:
- Sweden (SE)
- Insulation Material:
- Y
- Product Subgroup:
- Wire Joints
- Product Type:
- Nylon Insulated Wire Joint
- Department:
- Electrical
- Product Group:
- Wire Termination
- Product Color:
- White
- Product Material:
- Brass
Sta-Kon RCJ – Frequently Asked Questions
1) What wire size does the Sta-Kon RCJ wire joint accept?
The Sta-Kon RCJ is sized for conductors from 2.0 to 6.0 mm2 cross section. In AWG terms that range covers roughly 14 AWG through 10 AWG, so it suits branch circuit and control wiring in that band rather than fine instrumentation wire.
2) Can I use the Sta-Kon RCJ to splice two wires together in a junction box?
Yes, that is what it is for. The RCJ is a nylon insulated wire joint, meaning a crimped butt splice that joins conductor to conductor inside its own insulating sleeve, so you are not relying on tape or a separate boot. It is a crimp connector, so you need the matching crimp tool for 2.0-6.0 mm2 terminals, not pliers.
3) Will the RCJ work for 8 AWG or larger feeder conductors?
No. The RCJ tops out at 6.0 mm2, which is about 10 AWG, so an 8 AWG or heavier conductor will not seat in the barrel. For larger feeders you need a butt splice or compression connector rated for that conductor size.
4) Is the Sta-Kon RCJ barrel brass or steel?
Brass barrel with a nylon insulation sleeve over it. Brass crimps readily and carries current well, which is why it is the usual choice for an insulated butt-style joint on copper conductors.
5) What part number do I order for the Sta-Kon insulated wire joint, and where is it made?
Order it as Sta-Kon RCJ. That is the manufacturer part number for the 2.0-6.0 mm2 nylon insulated joint, and there is a single model with no finish or size options to specify. Country of origin is Sweden.
6) What color is the insulation on the RCJ wire joint, and does the color identify the wire size?
The RCJ sleeve is white. On nylon insulated terminals the sleeve color is the standard size code, and white falls outside the familiar red/blue/yellow run used for 22-16, 16-14 and 12-10 AWG, so identify this one by the RCJ part number and its 2.0-6.0 mm2 range rather than by color convention.
How fast can I get the Sta-Kon RCJ delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the
continental
U.S.
Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit,
reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Sta-Kon RCJ come with a warranty?
Absolutely. The Sta-Kon RCJ is backed by a manufacturer’s warranty.
For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Sta-Kon RCJ?
You can call, text, or email our expert support team for fast answers. We’re here to help with
product
selection,
installation tips, and troubleshooting. Contact Us
