INSTALL DIE FOR 13642M SIZE RD 8 ML
Manufacturer Resources
Product Specs
- Country Of Origin:
- United States (US)
- Product Subgroup:
- Crimping Dies
- Product Type:
- Die
- Standards:
- Military Listed
- Department:
- Electrical
- Product Group:
- Tools & Accessories
- Product Size:
- Terminal Size RD Tubular, Wire Size 8
Sta-Kon 21707M – Frequently Asked Questions
1) What crimping tool and terminal is the Sta-Kon 21707M die made for?
The Sta-Kon 21707M is an installing die for the 13642M, set up for RD tubular terminals in wire size 8. It is a die only, so you need the matching crimp tool body it seats into plus the RD-series 8 AWG terminals or lugs you intend to crimp.
2) Can I use the 21707M die to crimp other wire gauges besides 8 AWG?
No. The 21707M nest is cut for RD tubular terminals in wire size 8 only. Crimping a 10 or 6 AWG barrel in it gives you an out-of-spec crimp, so for other gauges you need the die sized for that gauge in the same series.
3) I ordered part 21707M, is that a complete crimper or just the die?
Just the die. The 21707M is the installing die component that goes into the 13642M tool; the tool frame is a separate order. Shops standardizing an MRO bench usually keep one tool body and a set of these dies by terminal size and gauge.
4) Does this Sta-Kon die meet military requirements for electrical terminations?
The 21707M installing die is Military Listed per its published standards. If your spec calls for a military-listed crimp on 8 AWG RD tubular terminals, this is the die that matches that callout. It is also made in the United States.
5) Will the 21707M work on ring or fork terminals, or only tubular lugs?
It is cut for RD tubular terminal barrels at 8 AWG. Insulated ring and fork Sta-Kon terminals use a different barrel profile and need their own die nest, so match the die to the terminal series printed on the part you are crimping, not just the wire gauge.
