Ives Dutch Door Bolt with Decorative Knob and Universal Strike Kit
Professional Dutch Door Hardware Solution
The Ives Dutch Door Bolt provides a practical and attractive solution for securing dutch doors and similar applications. This solid brass bolt features a chamfered rod end that draws door leaves tightly together with a decorative 1" diameter knob for easy operation. The unit includes Standard Strike (SS), Mortise Strike (MS), and Universal Strike (US) for versatile installation options.
Professional Features & Benefits
- Precision Dimensions: L: 4-1/4", W: 1-5/8" for standard dutch door applications with proper proportional aesthetics.
- Solid Brass Construction: Durable solid brass substrate provides long-lasting performance and corrosion resistance for commercial applications.
- Chamfered Rod Design: Specially designed rod end draws door leaves tightly together for secure closure and proper alignment.
- Decorative Operation: 1" diameter knob facilitates smooth bolt operation while providing attractive visual appeal.
- Universal Strike Kit: Includes Standard Strike (SS), Mortise Strike (MS), and Universal Strike (US) for flexible installation configurations.
- Tolerance Engineering: Strike opening provides sufficient tolerance to accommodate door leaf misalignment and prevent bolt binding.
- ANSI/BHMA Compliance: Meets ANSI/BHMA A156.16 standards for quality and performance assurance.
- Complete Hardware Package: Units packed with wood screws for immediate installation capability.
Technical Specifications
- ANSI/BHMA: ANSI/BHMA A156.16
- Commercial/Residential: Commercial
- Department: Door Hardware
- Product Category: Door Trim and Accessories
- Product Dimension: L: 4-1/4", W:1-5/8"
- Product Group: Door Trim and Accessories
- Product Model: 54
- Product Subgroup: Surface Bolts
- Product Substrate: Solid Brass
- Product Type: Dutch Door Bolts
- Subcategory: Latches, Catches and Bolts
Installation & Operation
- Review manufacturer specifications and verify door preparation requirements including door thickness, stile width, and handing as applicable to this product.
- Use manufacturer-provided templates to mark mounting hole locations accurately on door and/or frame surfaces.
- Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
- Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
- Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
- Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.
Professional Applications
- Dutch Door Installations
- Commercial Office Buildings
- Educational Facilities
- Healthcare Institutions
- Retail Establishments
- Multi-Tenant Residential Properties
- Government and Municipal Buildings
Why Choose Ives Quality?
Ives Dutch Door Bolt products deliver professional-grade reliability with solid brass construction and ANSI/BHMA A156.16 compliance for demanding commercial applications. The complete strike kit and precision engineering ensure proper door leaf alignment and smooth operation. Engineered for demanding commercial applications where dependable performance and attractive aesthetics are essential.
Manufacturer Resources
Ives Full Line Catalog
Product Specs
- Product Group:
- Door Trim and Accessories
- Subcategory:
- Latches, Catches and Bolts
- Product Subgroup:
- Surface Bolts
- Product Type:
- Dutch Door Bolts
- ANSI/BHMA:
- ANSI/BHMA A156.16
- Commercial/Residential:
- Commercial
- Product Model:
- 54
- Product Dimension:
- L: 4-1/4", W:1-5/8"
- Product Category:
- Door Trim and Accessories
- Product Substrate:
- Solid Brass
- Department:
- Door Hardware
Ives IVE-054-B26D – Frequently Asked Questions
1) Do I need to buy a strike separately for the Ives 054 dutch door bolt?
No extra strike to order. The Ives 054 ships with all three: Standard Strike (SS), Mortise Strike (MS), and Universal Strike (US), plus wood screws in the same pack. So one part number covers a surface-applied installation or a mortised one, and you can decide at the door instead of at the order form.
2) Can I use a dutch door bolt to hold one leaf of a pair of doors closed?
That is the wrong part for a pair of doors. The Ives 054 joins the upper and lower leaves of a dutch door to each other so the two halves swing as one unit; its chamfered rod end pulls the leaves together at the meeting rails. It does not throw into a head frame or a threshold, which is what an inactive leaf on a pair of doors needs. For that opening you want a flush bolt or a surface bolt that engages the frame above and the floor below.
3) My dutch door leaves don't sit perfectly flush - will the Ives 054 bolt still line up and throw?
Misalignment is designed into it. The strike opening carries enough tolerance to take up door leaf misalignment without the bolt binding, and the rod end is chamfered so it drags the two leaves into line as it throws rather than jamming against the strike edge. On an older wood dutch door that has settled, that combination is the difference between a bolt you can actually operate and one nobody uses.
4) The upper and lower leaves do not line up perfectly and the frame is already mortised. Which dutch door bolt suits that opening?
The Ives 054 is the one built around that condition. It ships with three strikes in the box, a Standard Strike, a Mortise Strike, and a Universal Strike, so an already mortised leaf and a surface-applied condition are both covered without a second order, and the strike opening is sized with enough tolerance to take up door leaf misalignment so the bolt does not bind. The rod end is chamfered to draw the two leaves tightly together as it throws. The Emtek 8516 is the other dutch door bolt to look at for the same job, at 4 inches.
5) Which strike do I use on a dutch door - the surface one or the mortise one?
Both come with the Ives 054, so it comes down to how much prep you want to do. The Mortise Strike (MS) is let into a routed pocket so nothing stands proud of the leaf, which suits a finished job or a door where the leaves close tight against each other. The Standard Strike (SS) and Universal Strike (US) screw to the surface, which is the faster retrofit on an existing dutch door and avoids routing a door you do not want to cut. The Universal Strike is the one to reach for when you are not sure yet how the leaves will meet.
6) What finishes does the Ives 54 dutch door bolt come in? I need it to match the rest of the hardware in the building.
Seven finishes across the 054: 605 bright brass, 606 satin brass, 612 satin bronze, 613 satin bronze oil-rubbed, 619 satin nickel, 625 bright chrome, and 626 satin chrome. Those are standard BHMA finish numbers, so if your existing levers and hinges are specified as 626 or 613 you can order the bolt to the same number and it will read as a set. The finish is applied over a solid brass substrate.
7) Is the Ives 054 dutch door bolt suitable for a commercial building, or is it residential trim?
It is classified commercial and built to ANSI/BHMA A156.16, the standard covering auxiliary hardware of this kind. The body is solid brass rather than plated pot metal, which is what holds up in a corridor that gets used all day. That is why it turns up on dutch doors in schools, healthcare facilities, and municipal buildings where a residential-grade bolt would be replaced within a year.
8) What is the difference between the Ives 054 dutch door bolt and the Emtek 8516?
Both are dutch door bolts that join the upper and lower leaves. The Ives 054 is solid brass, measures 4-1/4 by 1-5/8 inches, meets ANSI/BHMA A156.16, and comes with the standard, mortise, and universal strikes in the box, so one order covers a surface or mortised install. The Emtek 8516 is a 4 inch dutch door bolt and is the one to look at if you are matching an Emtek trim package elsewhere in the house or unit. For a commercial corridor with an existing Ives hinge and trim spec, the 054 keeps the finish numbers and the manufacturer consistent.
9) The drawing calls out ANSI/BHMA A156.16 for the dutch door bolt on a commercial job. Which one matches?
The Ives 054 is the one that answers the callout: it meets ANSI/BHMA A156.16 and is a commercial-rated bolt with a solid brass substrate, in seven finishes including 605 bright brass, 606 satin brass, 612 satin bronze, 613 satin bronze oil-rubbed, 619 satin nickel, 625 bright chrome, and 626 satin chrome, so it can be matched to whatever the rest of the door hardware schedule specifies. The Emtek 8516 is the other dutch door bolt in the category, at 4 inches, if the submittal is open on the standard and the shorter face suits the rail better.
10) Are fasteners included with the Ives dutch door bolt, and will they work on a hollow metal door?
Wood screws are packed with the unit, so on a wood dutch door you have everything you need to hang it. Wood screws will not hold in hollow metal - on a steel leaf you would drill and tap or use appropriate machine screws, which you supply. Most dutch doors this bolt goes on are wood, which is why it is packed that way.
11) How is the Ives 054 dutch door bolt operated - is it keyed?
Operation is by hand, using the 1 inch diameter decorative knob on the bolt to throw and retract it. It is a bolt for holding the two halves of a dutch door together so they swing as a single door, not a locking device, and security on the opening comes from whatever lock is on the leaf. Anyone standing on the bolt side can throw it, which is exactly what you want on a nurse station or reception dutch door.
12) I need to order a dutch door bolt in 626 satin chrome - what is the part number?
The satin chrome version of the Ives 054 dutch door bolt is 054-B26D. Base model is 54, and the finish suffix follows the old US finish shorthand: B3 is 605 bright brass, B4 is 606 satin brass, B10 is 612 satin bronze, B10B is 613 oil-rubbed satin bronze, B15 is 619 satin nickel, B26 is 625 bright chrome, and B26D is 626 satin chrome. Every one of them ships with the same three-strike kit.
