Ives 299AB Offset Emergency Stop Assembly with Bi-Directional Door Swing for Healthcare Applications

Ives Offset Emergency Stop Assembly with Bi-Directional Door Swing for Healthcare Applications

Professional Rescue Hardware Solution for Emergency Door Access

The Ives Offset Emergency Stop Assembly is engineered specifically for healthcare environments where patient safety and emergency access are critical. This rescue hardware system works in conjunction with center hung pivots to enable bi-directional door swing in emergency situations, allowing doors to swing in the opposite direction when patients become trapped behind inward swinging doors. Designed for 1-3/4" door thickness with offset mounting configuration, this assembly fits 6-3/4" to 7-3/4" frames and includes 8-32 x 1/2" fasteners for hollow metal applications.

Professional Features & Benefits

• Emergency Bi-Directional Operation: Center tong depression mechanism allows door to swing in opposite direction during emergency situations without causing frame damage.
• Healthcare-Specific Design: Engineered to address blocked doorways caused by incapacitated patients, a critical safety concern in healthcare facilities.
• Offset Mounting Configuration: Designed for offset hung applications with precise frame compatibility for 6-3/4" to 7-3/4" frames.
• Door Thickness Compatibility: Fits standard 1-3/4" door thickness with custom sizes available through manufacturer consultation.
• Center Hung Pivot Integration: Must be used with compatible Ives center hung pivot models including 7253, 7255, 7255J, 7256, and 7259 for proper operation.
• Professional Installation Hardware: Includes 8-32 x 1/2" fasteners specifically designed for hollow metal door applications.
• ANSI/BHMA Compliance: Meets ANSI/BHMA A1882 standards for commercial rescue hardware applications.
• Stainless Steel Construction: Durable stainless steel substrate provides long-term reliability in demanding healthcare environments.

Technical Specifications

• ANSI/BHMA: ANSI/BHMA A1882
• Commercial/Residential: Commercial
• Department: Door Hardware
• Hang Type: Offset Hung
• Package Includes: 8-32 x 1/2" fasteners for hollow metal applications
• Product Category: Door Trim and Accessories
• Product Dimension: 6.75"-7.75" x 2.75"
• Product Group: Door Trim and Accessories
• Product Model: 299AB
• Product Subgroup: Rescue Hardware
• Product Substrate: Stainless Steel
• Product Type: Rescue Door Stops and Strikes
• Subcategory: Miscellaneous Hardware

Installation & Operation

1. Verify door thickness is 1-3/4" and frame dimensions are compatible with 6-3/4" to 7-3/4" frame requirements for offset mounting.
2. Ensure compatible Ives center hung pivot models (7253, 7255, 7255J, 7256, or 7259) are installed and properly functioning before rescue hardware installation.
3. Use manufacturer-provided templates to mark precise mounting locations for the emergency stop assembly on the door frame.
4. Prepare frame by drilling required holes according to template specifications and manufacturer installation guidelines.
5. Install the emergency stop assembly using provided 8-32 x 1/2" fasteners, ensuring proper alignment with center hung pivot mechanism.
6. Test emergency operation by depressing center tong to verify bi-directional door swing function and confirm door returns to normal operation when released.
7. Verify installation does not interfere with deadbolt applications or mortise locks with deadlocking auxiliary latches as these are incompatible with this rescue hardware system.

Professional Applications

• Hospital Patient Room Restrooms
• Healthcare Facility Utility Closets
• Institutional Small Spaces and Storage Areas
• Convalescent Home Patient Areas
• Medical Office Building Treatment Rooms
• Emergency Care Facility Access Points
• Long-Term Care Facility Patient Rooms

Emergency Access Design

This rescue hardware system addresses the critical safety challenge of blocked doorways in healthcare environments. When a patient becomes incapacitated behind an inward swinging door, the center tong depression mechanism enables immediate access by allowing the door to swing in the opposite direction without frame damage. This life-saving functionality is essential in patient restrooms, utility closets, and confined spaces where emergency access may be required.

Why Choose Ives Quality?

Ives rescue hardware delivers professional-grade reliability with stainless steel construction and ANSI/BHMA A1882 compliance for demanding healthcare applications. Engineered specifically for emergency access situations, this system provides the dependable performance healthcare professionals require when patient safety is at stake. The precision-manufactured components ensure consistent operation and long-term durability in critical care environments.
