LG14 LOCK GUARD - WITH ELECTRIC STRIKE
IVES LOCK GUARDS OVERVIEW
- Narrow design unit for use on rose or escutcheon 3-1/2" or less.
- For use with Von Duprin 6210 and 6211 electric strike.
- No exposed fasteners on face of unit.
- Unique design provides maximum security, virtually eliminating the opening between door and frame at latch point.
- Non-handed.
- 4 welded mounting studs. No exposed fasteners on face of unit.
IVES LOCK GUARDS OVERVIEW
Ives provides exterior hardware designed to handle any weather and has a solution for any application needs. They offer a line of lock guards, all designed to fit specific door stiles, lock types and trim types. The unique designs provide maximum security, virtually eliminating the opening between door and frame at latch point.
FEATURES & BENEFITS
DESIGNS & FINISHES
FEATURES & BENEFITS
- Available in 12 gauge steel or 13 gauge stainless steel
- Most models have no exposed fasteners on the unit face
- Unique designs provide maximum security
- Designed to guard various locks, roses and escutcheons
DESIGNS & FINISHES
Each lock guard is designed to fit specific door stiles, lock types and trim types. See below and the Ives Full Line Catalog for more detail on the specific designs available.
- Lock guard (LG1, LG7)
- Units are non-handed and incorporate a security frame pin to prevent door and frame separation; LG7 does not incorporate the security frame pin
- Unit covers the latch bolt area of the door and lock, providing added protection from burglars, vandals or normal abuse
- Ideal for use with mortise or cylindrical locks
- Thru-bolted with carriage bolts and nuts
- Lock guard (LG10)
- Ideally for use with rose or escutcheon 2-3/4" wide or smaller
- For use with type 86 mortise and type 161 cylindrical locks
- Lock guard (LG11)
- Designed for use on aluminum doors with latch-type locks or doors equipped with electric strikes
- Unit is handed; specify left or right hand when ordering
- Lock guard (LG12)
- Narrow design unit used on roses or escutcheons 3-1/2" or smaller
- For use with type 86 mortise and type 161 cylinder locks
- Lock guard (LG14)
- Narrow design unit used on roses or escutcheons 3-1/2" or smaller
- For use with Von Duprin 6210 and 6211 electric strike
Finishes
The lock guards are available in many finishes. Please refer to the Ives Full Line Catalog for specific product finish availability
RESOURCES & DOWNLOADS
Manufacturer Resources
Product Specs
- Category:
- Door Trim and Accessories
- Subcategory:
- Exterior Hardware
- Product Group:
- Door Trim and Accessories
- Substrate:
- Stainless Steel
- Package Includes:
- 4 welded mounting studs
- Dimensions:
- W: 2-9/16", H: 9-1/2"
- Handing:
- Non-Handed
- Product Subgroup:
- Door Trim and Latch Protection
- Product Type:
- Latch Protectors
- ANSI/BHMA:
- UL10C Listed (3 hour)
- Model:
- LG14
- Commercial/Residential:
- Commercial
- Electronic:
- Yes
