Copy of Kwikset 405CSL RDT SMT Casey Lever Set Keyed Entry Door Lock with SmartKey

Kwikset 405CSLRDT-S.FD Casey Lever with Round Rose Entry Door Lock SmartKey with RCALFD Latch and RCS Strike

(No reviews yet) Write a Review

Model: 405CSLRDT-15S.FD
From the Casey Lever Collection
$81.90
$43.51
Selected Finish is
Selected FREE KEYING Options is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$81.90
$43.51
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Kwikset 405CSLRDT-S.FD Casey Lever with Round Rose Entry Door Lock SmartKey with RCALFD Latch and RCS Strike

405CSL Casey Lever Set with SmartKey for entryways, entrances or main doors. Both knobs locked or unlocked by key outside or turn button inside.

Looking for an easy and hassle-free solution for your interior doors? Look no further than this latch! It's perfect for entrance, entryways or securing main doors. Featuring SmartKey Security™, this lock protects against advanced break-in techniques and allows you to re-key your lock yourself in just seconds. Compatible with Kwikset (KW1) keyway or (SC1) keyway options. It's also certified with an ANSI/BHMA grade 3 certification and has been tested for durability and performance. With an adjustable backset ranging from 2-3/8" to 2-3/4", this latch can fit all standard door preparations. Plus, the fully reversible lever can be installed on both right and left-handed doors. Installation is a breeze and can be done in just a few minutes with a screwdriver. You'll also receive a lifetime mechanical and finish warranty, so you can trust that this latch will last for years to come. This latch is also treated with Microban Antimicrobial product protection, which keeps door hardware 99.9% cleaner than unprotected surfaces. This means you'll have peace of mind knowing that your latch is not only functional but also helps keep your home cleaner and safer.

Buy this Kwikset Casey Lever Set latch today for a hassle-free solution for your interior doors!

CASEY LEVER SET PRODUCT FEATURES

  • For use on exterior doors where keyed entry and security is needed
  • Featuring SmartKey Security™, which protects against advanced break-in techniques and allows you to re-key your lock yourself in seconds.
  • SmartKey Security™ re-key technology is compatible with Kwikset (KW1) keyway or (SC1) keyway options
  • Comes with 2 keys
  • ANSI/BHMA grade 3 certified
  • Locking mechanism functions with turn piece on the interior of the lock
  • Easily installs in minutes with just a screwdriver
  • Lifetime mechanical and finish warranty
  • Microban Antimicrobial product protection keeps door hardware 99.9% cleaner than unprotected surfaces

COLOR VARIATIONS

Kwikset 405CSL RDT SMT Casey Lever Set Keyed Entry Door Lock with SmartKey 15S (Satin Nickel)
Kwikset 405CSL RDT SMT Casey Lever Set Keyed Entry Door Lock with SmartKey 26S (Polished Chrome)
Kwikset 405CSL RDT SMT Casey Lever Set Keyed Entry Door Lock with SmartKey 514S (Matte Black)

Note: Some concept images shown with item are not included.

CASEY LEVER SET COLLECTION

Kwikset 200CSL RDT Casey Passage Lever Set Door Lock
Kwikset 300CSL RDT Casey Privacy Lever Set Door Lock
Kwikset 405CSL RDT SMT Casey Lever Set Keyed Entry Door Lock with SmartKey
Kwikset 488CSL RDT Casey Half Dummy Door Lever Non-Turning One-Sided Function
Kwikset 200CSL SQT Casey Passage Lever Set Door Lock
Kwikset 300CSL SQT Casey Privacy Lever Set Door Lock
Kwikset 405CSL SQT SMT Casey Lever Set Keyed Entry Door Lock with SmartKey
Kwikset 488CSL SQT Casey Half Dummy Door Lever Non-Turning One-Sided Function

RESOURCES & DOWNLOADS

405CSL RDT SMT Casey Lever Set Door Installation Guide
Smartkey Instructions

Manufacturer Resources

Product Specs

Collection:
Casey Lever
Grade:
Grade 3
Warranty:
Limited Lifetime Finish, Limited Lifetime Mechanical
Keyed Function:
Single Cylinder
Product Group:
Mechanical Locks
Product Subgroup:
Leversets
Subcategory:
Levers
Keyed:
Yes
Commercial/Residential:
Residential
Handle Type:
Lever
UL Listing Type:
Optional UL 1/3 Hour fire rating for all functions.
Lock Function:
Entry/Office
Cylinder and Keyways:
SmartKey Security
Features:
Microban, SmartKey
Product Attribute:
Cylindrical Locks
Product Function:
Entry
Product Type:
Leversets
Door Hand Direction:
Reversible
Door Thickness Range:
1-3/8” – 1-3/4”
Product Details:
Mechanical
Door Strike:
2-1/4" Full Lip Round Corner Strike
Product Style:
Contemporary
Product Category:
Mechanical Locks
Backset (Distance):
Adjustable 2-3/8" or 2-3/4"
Department:
Door Hardware

Kwikset 405CSLRDT-15S.FD – Frequently Asked Questions

1) Will the Kwikset Casey 405CSL entry lever fit a 1-3/8 inch door, or only 1-3/4?
Both. The Casey 405CSL keyed entry lever covers a door thickness range of 1-3/8 inch to 1-3/4 inch, so it works on older interior-weight doors and standard commercial-thickness doors alike. The backset adjusts between 2-3/8 inch and 2-3/4 inch, which are the two standard bore locations, so it drops into existing prep without redrilling.
2) Do I have to order a left-hand or right-hand version of the Casey lever?
No handing to specify. The Casey lever is fully reversible and installs on either a left or right hand door, so one part number covers every opening in a building.
3) Can I key this Kwikset SmartKey lever to my existing Kwikset or Schlage keys?
SmartKey Security re-keying lets you set the cylinder to a key you already carry, and it accepts either the Kwikset KW1 keyway or the Schlage SC1 keyway. Two keys ship with the lock. Keying is selected at order time as either keyed different or keyed alike, and you can supply a key code if the lock needs to match an existing system.
4) Is a Grade 3 SmartKey entry lever enough for an apartment unit door, or do I need commercial grade?
The Casey 405CSL is an ANSI/BHMA Grade 3 residential-duty entry lockset, which suits single-family and light multi-family unit doors. For a high-traffic commercial opening, step up to a Grade 2 or Grade 1 cylindrical lever such as the Hager 2525 Grade 2 entry lock or a Dexter C1000 Series Grade 1 cylindrical lock.
5) What is the closest Grade 3 keyed entry lever to the Kwikset 405CSL Casey if I want a different brand?
Two Grade 3 keyed entry levers line up closely. The Master Lock BC Series RL01 is a Grade 3 return style lever keyed entry lockset, and the Callan Artino CLN-360201 is a Grade 3 entrance leverset. Both match the Casey's Grade 3 rating and entry/office function. The Casey's distinguishing feature is SmartKey Security, which lets you re-key the cylinder yourself and works with the KW1 or SC1 keyway.
6) I need a heavier duty entry lever than the Kwikset Casey for a commercial corridor. What should I look at?
The Casey 405CSL is a Grade 3 residential entry leverset. For commercial traffic, step up to a Grade 2 entry: the Hager 2525 is a Grade 2 commercial cylindrical entry lock with lever handle for doors 1-3/8 inch to 2 inch, and the Falcon B511CP6D is a Grade 2 medium duty cylindrical lever with entry/office function. The Cal-Royal AUS00 is a Grade 3 entrance/office lever with a solid brass forged body if you want to stay at Grade 3.
7) Is the Kwikset Casey 405CSL the right lock for a classroom or storeroom door?
No. The Casey 405CSL is an entry/office function, meaning it can be locked or unlocked by key outside or by the turn button inside. For a classroom door, the Cal-Royal AG03 is a classroom lever with a 6-pin Schlage C keyway and 2-3/4 inch backset, and the Dexter C1000 is offered in a Grade 1 classroom function. For a storeroom door that stays locked with no inside turn button, look at the Cal-Royal AG05 Grade 2 storeroom lever with deadlocking latchbolt or the Hager 2580 Grade 2 storeroom lock.
8) My door is 2 inches thick. Will the Kwikset Casey 405CSL work, or do I need something else?
The Casey 405CSL covers doors 1-3/8 inch to 1-3/4 inch, so a 2 inch door is outside its range. For thicker stiles, the Deltana 6201 Manchester and 6431 Linstead entry levers cover 1-3/8 inch to 2 inch, and the Dexter C1000 asylum function covers 1-3/8 inch to 2 inch. The Falcon K101 covers 1-3/8 inch to 2-1/4 inch in a passage function.
9) The opening is a fire-rated door. Is the Kwikset Casey 405CSL appropriate, or should I specify differently?
The Casey 405CSL carries an optional UL 1/3 hour fire rating across its functions and is a Grade 3 residential lock. For higher rated commercial fire openings, the Corbin Russwin CL3110 is a Grade 1 vandal resistant cylindrical lever with a fire rating for doors 1-3/4 inch to 2 inch, the Falcon K101 is a Grade 1 fire-rated passage lock, and the Arrow MK02-TA carries a fire rating in a privacy function.
10) What strike comes with the Kwikset Casey 405CSL, and will it match my existing frame cutout?
It ships with a 2-1/4 inch full lip round corner strike (RCS), paired with the RCALFD round corner latch face. If your frame is prepped for a square corner strike, the round corner plate will not sit flush in that mortise without filing the corners.
11) How does the Casey entry lever lock and unlock?
Entry/office function: a turn button on the inside rose locks and unlocks the lever, and the key cylinder on the outside does the same from the exterior. It is a single cylinder lock, so there is no key on the inside.
12) Can I use this lock on a fire rated door?
An optional UL 1/3 hour fire rating is available for all Casey 405CSL functions, so the fire-rated configuration has to be specified rather than assumed on a standard order.
13) I need matching passage and privacy levers for the bedrooms and bathrooms on the same job. What matches the Casey keyed entry lever?
The Casey round rose family runs across functions: 200CSL RDT passage, 300CSL RDT privacy, 405CSL RDT SMT keyed entry, and 488CSL RDT half dummy. The same four functions exist with square rose trim (SQT) if you prefer square roses throughout.
14) I want a lever and deadbolt together instead of just the Kwikset Casey 405CSL entry lever. What is available?
The Casey 405CSL is a single cylinder keyed entry leverset on its own. If you want the deadbolt in the same package, the Callan Bennett CLN-BN3001R is a Grade 3 entrance leverset with deadbolt combo, matching the Casey's Grade 3 rating in a combination set.
15) The door does not need to lock. What is the non-keyed version to order instead of the Kwikset Casey 405CSL?
The Casey 405CSL is keyed with a single cylinder, so for a door that only needs latching, use a passage lever instead. Options include the Callan Asheville CLN-AH5011, a Grade 3 passage leverset in satin nickel, the Bravura Atlanta BV333002 Grade 2 round trim passage leverset, and the Hager 2510 Grade 2 passage lever for doors 1-3/8 inch to 2 inch. For a bed or bath door, the Baldwin Estate 5103 is offered in a privacy function.
16) I want keyless entry instead of the Kwikset Casey SmartKey lock. What are the alternatives?
The Casey 405CSL is a mechanical keyed lock using SmartKey Security with the KW1 or SC1 keyway. For code entry instead of keys, the Delaney LP250 is a Grade 2 electronic keypad leverlock, the Emtek Classic Keypad Leverset offers keypad entry in the Classic series, and the Lockey 2835 is a mechanical pushbutton keyless lever lock with passage function and ADA compliance for doors 1-3/16 inch to 2 inch.
17) Can I use a dummy lever like the Baldwin 5103 half dummy in place of the Kwikset Casey 405CSL?
No. The Casey 405CSL is a keyed entry lock with a latch and a 2-1/4 inch full lip round corner strike, so it latches and locks the door. The Baldwin Estate 5103 half dummy, the Accentra 455LN Augusta single dummy and the BEST 9K Series 1DT single dummy trim are non-latching surface-mounted trim only. Use a dummy on an inactive leaf or closet face, not on a door that needs to secure.
18) I need a Schlage C keyway entry lever rather than the Kwikset SmartKey. What are my options?
The Casey 405CSL uses SmartKey Security and is compatible with the Kwikset KW1 or SC1 keyway. If your building is keyed to Schlage C, the Cal-Royal AG00 is an entrance lever with a 6-pin Schlage C keyway keyed different and a 2-3/8 inch backset for doors 1-3/8 inch to 1-3/4 inch. The Arrow MK33-BD-CS uses a conventional cylinder in Schlage C keyway in an asylum function. Accentra also offers the 107S Schlage cylinder adapter kit for Yale hardware.
19) Is there a knob version of the same entry function as the Kwikset Casey 405CSL?
The Casey 405CSL is a lever handle. For the same turn-button entry behavior with a knob, the Arrow HK11-BB is a turn-pushbutton entrance cylindrical lock with a ball knob and conventional cylinder for doors 1-3/8 inch to 1-3/4 inch, the same door thickness range the Casey covers. Note that lever handles are generally specified where ADA operation is required.
20) Does the Kwikset Casey 405CSL work on an access control opening, or do I need an electrified lever?
The Casey 405CSL is a mechanical lock with SmartKey, operated by key outside and turn button inside, with no electrical provision. For access control, use an electrified lever such as the Corbin Russwin CL33903 Grade 1 fail safe lever, offered in a 12VAC/DC electrified cylindrical version for doors 1-3/4 inch to 2 inch.
21) What finishes does the Casey round rose lever come in?
Satin Nickel (15S), Polished Chrome (26S) and Matte Black (514S) are the Casey 405CSL RDT SmartKey color options.
22) Is there an antimicrobial lever option for a healthcare or senior living corridor?
The Casey lever hardware is treated with Microban antimicrobial product protection, which the manufacturer states keeps the hardware 99.9 percent cleaner than unprotected surfaces. Note it is a Grade 3 residential lockset, so for a healthcare corridor with institutional traffic a Grade 1 cylindrical lever such as the Falcon K101 or Corbin Russwin CL3110 is the heavier-duty route.
23) Do I need special tools to install the Casey lever set?
A screwdriver is all it takes on a door already bored for a cylindrical lockset. The backset adjusts on the latch between 2-3/8 and 2-3/4 inch, so no drilling is needed to match either standard prep.
