Kwikset CP690T Clear Pack Combo Keyed Entry Tylo Knob with Single Cylinder Deadbolt with RCAL Latch and RCS Strike

Kwikset CP690T Clear Pack Combo Keyed Entry Tylo Knob with Single Cylinder Deadbolt with RCAL Latch and RCS Strike

(No reviews yet) Write a Review

Model: CP690T-15
$58.00
$42.86
Selected Finish is
Selected FREE KEYING Options is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$58.00
$42.86
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Kwikset CP690T Clear Pack Combo Keyed Entry Tylo Knob with Single Cylinder Deadbolt with RCAL Latch and RCS Strike

This deadbolt is certified as the highest residential security, durability, and finish with ANSI/BHMA Grade 3 certification. The latch is adjustable to fit all standard door preparations from 2-3/8" to 2-3/4". The round deadbolt strike and 1-inch deadbolt throw provide an additional level of security. The locking mechanism functions with a turn piece on the interior of the lock.

PRODUCT FEATURES

  • For use on exterior doors where keyed entry and security is needed
  • Universal handing
  • fits both right handed and left handed doors
  • Comes with 2 keys
  • Latch has 2 interchangeable faceplates
  • round corner and square corner
  • ANSI/BHMA grade 3 certified
  • Latch has adjustable backset 2-3/8"" to 2-3/4"" to fit all standard door preparations
  • Includes both deadbolt and full lip square strikes
  • 1 in. deadbolt throw
  • Locking mechanism functions with turn piece on the interior of the lock
  • Easily installs in minutes with just a screwdriver
  • Lifetime mechanical and finish warranty

RESOURCES & DOWNLOADS

Kwikset KWI-690T Combo Keyed Entry Tylo Knob with Single Cylinder Deadbolt with RCAL Latch and RCS Strike

Manufacturer Resources

Product Specs

Product Group:
Mechanical Locks
Product Subgroup:
Knobsets
Subcategory:
Combo Packs
Commercial/Residential:
Residential
Product Features:
Microban
Product Attribute:
Cylindrical Locks
Product Type:
Knobsets
Product Category:
Mechanical Locks
Department:
Door Hardware

Kwikset CP690T-15 – Frequently Asked Questions

1) Will the Kwikset CP690T combo pack fit a door bored for a 2-3/8 inch backset, or do I need to know the backset before ordering?
No need to measure first. The latches in the CP690T Tylo knob and deadbolt combo use an adjustable backset that covers both standard door preparations, 2-3/8 inch and 2-3/4 inch. That is the same reason it drops onto most existing residential entry doors without re-boring.
2) Do I have to order a handed version of the Kwikset CP690T entry knob, or does one part work on both left and right doors?
One part covers both. The CP690T knob is universal handing and installs on right hand or left hand doors, so a property manager buying for a mixed building only stocks one item.
3) What exactly comes in the Kwikset CP690T box, and do I need anything else to finish the install?
The pack is a keyed entry Tylo knob plus a single cylinder deadbolt, with the RCAL adjustable latch, the round corner deadbolt strike and a full lip square strike, two interchangeable latch faceplates (round corner and square corner), and 2 keys. Installation is done with a screwdriver, so no special tooling is needed.
4) Can I get several Kwikset CP690T sets keyed alike so one key opens all my doors?
Yes. Keying is selected at order time: keyed alike so a single key runs every lock, or keyed different if each unit needs its own key. There is also an optional key code field if you are matching an existing Kwikset key system.
5) The Kwikset CP690T is Grade 3 residential - what do I use on a commercial opening instead?
The CP690T carries ANSI/BHMA Grade 3 certification and is a residential set. For commercial traffic, the BEST 8K Series entrance function single cylinder knob lock is Grade 1 heavy duty, the Sargent 8XG04 is a Grade 1 storeroom knob lock with a 2-3/4 inch backset, and the Corbin Russwin CK4851 is a Grade 1 entrance/office cylindrical knob lock for doors 1-3/8 inch to 2 inch. The Sargent 6G04 is a Grade 2 storeroom knob lock if the opening does not require Grade 1.
6) What is the closest equivalent to the Kwikset CP690T combo pack from another brand?
The Schlage Residential F500 Plymouth with Georgian Knob is the nearest match: it is a combo pack pairing a deadbolt and a knob, with adjustable backsets and dual strikes, and fits doors 1-3/8 inch to 1-3/4 inch. The Kwikset CP690T pairs a keyed entry Tylo knob with a single cylinder deadbolt, an RCAL latch adjustable 2-3/8 inch to 2-3/4 inch, and includes both deadbolt and full lip square strikes.
7) I only need a keyed knob, not a deadbolt - what should I order instead of the Kwikset CP690T?
The Kwikset CP690T is sold as a keyed entry Tylo knob plus a single cylinder deadbolt. If the door only needs the keyed knob, the Cal-Royal BER00 is a Grade 3 entrance/office knob lock with a Kwikset keyway for doors 1-3/8 inch to 1-3/4 inch, and the Master Lock BC01 is a Grade 3 keyed entry biscuit knob. The Pamex FTF Baron in entrance/office function is another Grade 3 knob-only option for the same door thickness range.
8) My door is thicker than 1-3/4 inches - which keyed knob works where the Kwikset CP690T does not?
The Kwikset CP690T is a residential set with an adjustable 2-3/8 inch to 2-3/4 inch backset latch. For a thicker door, the Corbin Russwin CK4851 Grade 1 entrance/office knob lock covers 1-3/8 inch to 2 inch, the Deltana 3381 Egg Knob entry and 6171 Round Knob entry both cover 1-3/8 inch to 2 inch, and the Falcon X101 covers 1-3/8 inch to 2-1/4 inch, though the X101 is a passage function with no key.
9) I need a fire rated knob lock - does the Kwikset CP690T qualify?
The Kwikset CP690T is a residential Grade 3 keyed entry knob and deadbolt combination. Where a fire rating is required, the Falcon W101 Grade 2 cylindrical knob lock and the Falcon X101 Grade 1 heavy duty knobset are both listed as fire rated; both are passage/closet function rather than keyed entry, so match the function to the opening.
10) Will the deadbolt in the Kwikset CP690T pack latch into the strike I already have in the jamb?
The deadbolt throws 1 inch and ships with its own round corner strike, so if the existing strike pocket is shallow or the bore does not line up, swap in the supplied strike rather than reusing the old one. The knob latch also comes with two faceplates, round corner and square corner, to match the existing mortise in the door edge.
11) Does the interior side of the Kwikset CP690T deadbolt take a key or a thumbturn?
Thumbturn. It is a single cylinder deadbolt, keyed outside and operated by a turn piece on the inside. If the door has glass close to the lock and you want no inside thumbturn, this is not the set for that opening.
12) Can I use a passage or dummy knobset in place of the Kwikset CP690T?
No. The CP690T is a keyed entry set with a single cylinder deadbolt and comes with 2 keys, intended for exterior doors where keyed entry and security is needed. Passage sets such as the Dexter C2000 passage ball knob, the Arrow MK01, and the Pamex FTF Baron passage have no key and no lock, and dummy trim such as the Schlage A170 single dummy or the BEST 6K single dummy is a pull only with no latch action. Those are interior and closet products, not a replacement for a keyed exterior opening.
13) What matches the Kwikset CP690T for the interior bedroom and bath doors on the same house?
The CP690T is the keyed exterior set. For bed and bath doors, the Cal-Royal BER20 is a Grade 3 privacy knob lock for 1-3/8 inch to 1-3/4 inch doors, the Pamex FTF Baron privacy is Grade 3 for the same range, and the Dexter C2000 privacy ball knob is Grade 2. Closet and hall doors take a passage set such as the Bravura Albany or Lynchburg, both Grade 2 passage knobsets.
14) What should I use instead of the Kwikset CP690T if I want to avoid issuing keys?
The CP690T is keyed and ships with 2 keys. The Lockey 3830 is a mechanical keyless combination knob lock with an auto-locking passage function for doors 1 3/16 inch to 2 inch, so access is by code rather than key. It is a different function from the CP690T keyed entry knob and deadbolt combination, so confirm the opening does not require a deadbolt before substituting.
15) Which alternatives to the Kwikset CP690T match it on Grade 3 for a keyed entry door?
The Kwikset CP690T carries ANSI/BHMA Grade 3 certification. Other Grade 3 keyed entry knob options include the Callan Canova and Callan Santo entrance knobsets, the Delaney Belton, Galway and Olivia entrance knobsets, and the Master Lock BC01 biscuit knob keyed entry. The difference is that the CP690T is supplied as a knob and single cylinder deadbolt together, while those are knobsets on their own.
16) Is a knob set like the Sure-Loc Bergen 6-pack a substitute for the Kwikset CP690T on rental units?
They serve different doors. The Sure-Loc Bergen is a round knobset sold as a 6-pack with adjustable backset, useful for outfitting multiple interior doors at once. The Kwikset CP690T is a keyed entry Tylo knob with a single cylinder deadbolt for exterior doors where keyed entry and security is needed, and it can be ordered keyed alike across units so one key runs the fleet.
17) What finish does the Kwikset CP690T Tylo combo come in, and does it have any antimicrobial treatment?
Satin Nickel is the finish offered, and the hardware carries Microban protection on the surface. For a building standard, Satin Nickel matches most other residential sets specified in that finish.
