Kwikset KWI-200LRLSQT Ladera L...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$48.60
$31.43
Kwikset KWI-200LRLSQT Ladera Lever with Square Rose Passage Door Lock with 6AL Latch and RCS Strike

Kwikset KWI-200LRLSQT Ladera Lever with Square Rose Passage Door Lock with 6AL Latch and RCS Strike

(No reviews yet) Write a Review

Model: 200LRLSQT-15
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$48.60
$31.43
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Kwikset KWI-200LRLSQT Ladera Lever with Square Rose Passage Door Lock with 6AL Latch and RCS Strike

This latch comes with 2 interchangeable faceplates - round and square corner - and meets the requirements of the Americans with Disabilities Act and ANSI A117.1. It's also certified with an ANSI/BHMA grade 3 certification and has been tested for durability and performance. With an adjustable backset ranging from 2-3/8" to 2-3/4", this latch can fit all standard door preparations. Plus, the fully reversible lever can be installed on both right and left-handed doors. Installation is a breeze and can be done in just a few minutes with a screwdriver. You'll also receive a lifetime mechanical and finish warranty, so you can trust that this latch will last for years to come. This latch is also treated with Microban Antimicrobial product protection, which keeps door hardware 99.9% cleaner than unprotected surfaces.

PRODUCT FEATURES

  • For use on interior doors requiring no locking functionality, such as hallway or closet doors
  • Latch has 2 interchangeable faceplates
  • Round corner and square corner available
  • Meets ADA/ANSI A117.1 requirements
  • ANSI/BHMA grade 3 certified
  • Latch has adjustable backset 2-3/8" to 2-3/4" to fit all standard door preparations
  • Fully reversible lever, can be installed on both right handed and left handed doors
  • Easily installs in minutes with just a screwdriver
  • Lifetime mechanical and finish warranty
  • Microban Antimicrobial product protection keeps door hardware 99.9% cleaner than unprotected surfaces



RESOURCES & DOWNLOADS

Kwikset KWI-200LRLSQT Ladera Lever with Square Rose Passage Door Lock with 6AL Latch and RCS Strike

Manufacturer Resources

Product Specs

Product Group:
Mechanical Locks
Product Subgroup:
Leversets
Subcategory:
Levers
Commercial/Residential:
Residential
Handle Type:
Levers
Features:
Microban
Product Attribute:
Cylindrical Locks
Product Type:
Leversets
Product Category:
Mechanical Locks
Department:
Door Hardware

Kwikset 200LRLSQT-15 – Frequently Asked Questions

1) Will the Kwikset Ladera passage lever fit a door bored for a 2-3/4 inch backset, or only 2-3/8?
Both. The 6AL latch supplied with the Ladera passage set is an adjustable-backset latch covering 2-3/8 inch and 2-3/4 inch, so it drops into either of the two standard residential door preps without ordering a different latch. Adjust it at the latch, not by swapping parts.
2) Does the Kwikset Ladera lever need to be ordered left hand or right hand?
No handing to specify. The Ladera lever is fully reversible and installs on right handed and left handed doors alike, so one part number covers every opening in the building. That matters if you are buying a case of them for a hallway or closet run and do not want to count swings first.
3) Does the Kwikset Ladera passage lever lock, or is it always free turning?
Always free turning. Passage function means the lever retracts the latch from both sides at all times with no key and no thumbturn, which is what you want on hallway, closet and pantry doors. If you need to secure a bathroom or bedroom you need a privacy set instead, and for a keyed opening an entry set.
4) Is the Kwikset Ladera lever ADA compliant for a rental or multi-family unit?
Yes. The Ladera passage set meets ADA and ANSI A117.1 requirements, which is the operable-hardware clause that rules out round knobs, and it carries an ANSI/BHMA Grade 3 certification. Grade 3 is the residential duty tier, so it suits apartment interior doors rather than a commercial corridor.
5) This is going in an apartment turn, is the Kwikset Ladera lever heavy duty enough for a commercial corridor?
No. The Ladera is a residential Grade 3 leverset and is built for interior unit doors. For a commercial corridor or a school passage opening, step up to a Grade 1 cylindrical passage lock such as the Falcon K101 or the Corbin Russwin CL3110, both Grade 1 passage function and both listed with a fire rating. A middle option is a Grade 2 like the Hager 2510 or the Falcon B101.
6) What is the closest equivalent to the Kwikset Ladera 200LRL square rose passage lever from another brand?
For a like-for-like interior passage lever with square trim, the Bravura Tampa BVR-BV333702 is a Grade 2 passage leverset with square trim, which is the same non-locking hallway and closet function in the same squared-off styling. If the square rose is not essential, the Bravura Atlanta BVR-BV333002 and Bravura Orlando BVR-BV333602 are Grade 2 passage leversets with round trim. The Ladera 200LRL is a passage lever for interior doors requiring no locking functionality, carrying ANSI/BHMA Grade 3 certification.
7) What passage lever should I use on a commercial corridor instead of a residential Grade 3 lever?
Step up to a Grade 1 passage lever built for commercial traffic. The Falcon K101 is a Grade 1 heavy duty passage cylindrical lock with non-handed levers, fire rated, fitting doors 1-3/8 inch to 2-1/4 inch thick. The Falcon T101 is a Grade 1 heavy duty passage lever with pressure release technology, and the Corbin Russwin CL3110 is a Grade 1 vandal resistant passage/closet lever, fire rated, for doors 1-3/4 inch to 2 inch. The Kwikset Ladera 200LRL is a residential lever carrying ANSI/BHMA Grade 3 certification.
8) I need the same lever on a bedroom or bathroom door that locks - what do I order?
A passage lever like the Kwikset Ladera 200LRL has no locking functionality, so a bath or bedroom door needs a privacy function instead. The Hager 2540 is a Grade 2 cylindrical lock with the Withnell lever for doors 1-3/8 inch to 2 inch thick, and the Baldwin Estate 5103 privacy lever with 5048 rose is a privacy/bed/bath function in the same 5103 lever family as the Baldwin 5103 passage lever.
9) Is a dummy lever the same thing as a passage lever?
No. A dummy lever is fixed trim with no latch at all, used on a closet or French door that catches on a roller or ball catch. The Kwikset Ladera 200LRL is a passage function set that comes with a 6AL latch and RCS strike and actually retracts a latchbolt. If a dummy is what the opening needs, the Callan Bentley CLN-BN5051 is a Grade 2 dummy lever, the BEST 7KC Series 7KC-1DT is a Grade 2 single dummy trim cylindrical lever, and the Baldwin Estate 5103 half dummy is offered in left hand and right hand versions.
10) Will the square corner faceplate on the Kwikset Ladera latch match my existing door mortise?
Either shape works. The 6AL latch ships with two interchangeable faceplates, round corner and square corner, so you match whatever is already routed into the door edge without filling and re-cutting. Doors prepped by a router jig are usually radius corner; a hand-mortised or metal-frame prep is usually square.
11) Do I get a strike plate with the Kwikset Ladera passage lever or do I buy that separately?
The set includes the RCS strike along with the 6AL adjustable-backset latch, so the door-jamb side is covered. Tools are minimal: a screwdriver does the whole install. Nothing else is required unless the frame is unprepped and you still need to bore it.
12) I want the same lever look on my closet doors that do not need to latch, can I get a dummy Ladera?
The Ladera 200LRL with the square rose is a passage set with a working latch. For a surface-mounted pull on a closet or a false door leaf, use a dummy trim from another line: Baldwin's Estate 5103 half dummy comes handed left or right, Emtek offers Classic and Arts and Crafts dummy pairs, and the BEST 7KC and 9K single dummy trims cover Grade 2 and Grade 1 commercial jobs.
13) What else should I look at if I want a square rose passage lever but not Kwikset?
Bravura's Tampa passage leverset is the closest square-trim match, a Grade 2 passage set. If round trim is acceptable, Bravura also lists the Atlanta, Orlando and Miramar passage leversets in Grade 2, and Callan's Asheville is a Grade 3 passage set in satin nickel, the same duty tier as the Ladera.
14) I need a keyed or a bathroom lever to match the Ladera passage set on the other doors, what do I use?
The Ladera 200LRL is passage only, so a keyed or privacy opening needs a different function. Within the comparable brands, Callan's Artino and Bennett entrance leversets are Grade 3, the same tier, and the Bennett comes as an entry-plus-deadbolt combo. Baldwin's Estate 5103 is offered in passage, privacy and dummy, so a whole floor can be matched off one lever design if you are standardizing on look rather than on Kwikset.
15) Which passage lever matches the Kwikset Ladera if I need a keyed entry door in the same job?
The Kwikset Ladera 200LRL is a non-locking passage lever, so a keyed opening needs an entrance function. The Callan Artino CLN-360201 and the Callan Bennett CLN-BN3001R are Grade 3 entrance leversets, with the Bennett supplied as a leverset and deadbolt combo, and the Master Lock BC Series RL01 is a Grade 3 return style keyed entry lockset. On the commercial side the Hager 2525 is a Grade 2 entry lock with lever handle for doors 1-3/8 inch to 2 inch thick.
16) What is the difference between the Kwikset Ladera passage lever and a Grade 2 commercial passage lever like the Arrow GL01 or Hager 2510?
All three are non-keyed passage levers for hallway and closet doors. The Arrow GL01 is a Grade 2 passage cylindrical lock with the Sierra lever for doors 1-3/4 inch to 2 inch thick, and the Hager 2510 is a Grade 2 passage lever with the Withnell design for doors 1-3/8 inch to 2 inch. The Kwikset Ladera 200LRL is residential hardware certified to ANSI/BHMA Grade 3, with an adjustable 2-3/8 inch to 2-3/4 inch backset, a fully reversible lever, and Microban antimicrobial protection.
17) What passage lever holds up on a multi-family corridor but is lighter duty than a Grade 1?
The Accentra Augusta 5301LN is a Grade 2 cylindrical lever lock in passage/closet function from the 5300 Series, and the Accentra 4601LN is a Grade 2 passage cylindrical lever with Augusta trim from the 4600 Series. The Falcon B101 is a Grade 2 medium duty passage lever with a non-handed design, and the Design Hardware J75 is a Grade 2 passage lever lockset with a flat lever for 1-3/4 inch doors. The Kwikset Ladera 200LRL is ANSI/BHMA Grade 3 residential hardware with a fully reversible lever.
18) Can I get the same hallway lever without a key but with code access?
If the door needs controlled access without cutting keys, a mechanical keypad leverset in passage function covers it. The Lockey 2835 is a mechanical pushbutton keyless lever lock with passage function and ADA compliance for doors 1 3/16 inch to 2 inch, the Lockey 2835DC adds a double combination in the same passage function, and the Lockey 1150 is a heavy duty mechanical keypad lever set with passage function for doors 1-1/8 inch to 2 inch. The Kwikset Ladera 200LRL is a straight passage lever that meets ADA and ANSI A117.1 requirements and installs with just a screwdriver.
19) What do I use on a storeroom or utility door instead of a passage lever?
A passage lever never latches locked, so a storage or utility room needs a keyed function. The Cal-Royal AG05 is a Grade 2 storeroom lever lockset with a deadlocking latchbolt for doors 1-3/8 inch to 1-3/4 inch, and the Hager 2580 is a Grade 2 storeroom cylindrical lock with the Withnell lever for doors 1-3/8 inch to 2 inch. For a utility or institutional opening, the Dexter C1000 asylum function is Grade 1 for doors 1-3/8 inch to 2 inch. The Kwikset Ladera 200LRL is for interior doors requiring no locking functionality.
20) What is the heavy duty passage lever to standardize on across a facility?
For a single passage lever across many openings, the Design Hardware X75 is a Grade 1 passage lever lockset with a flat lever for 1-3/4 inch doors, and the Falcon T101 is a Grade 1 heavy duty passage lever from the T Series. The Corbin Russwin CL3110 from the CL3100 Series is a Grade 1 vandal resistant passage/closet lever for doors 1-3/4 inch to 2 inch. The Kwikset Ladera 200LRL is a residential Grade 3 lever with an adjustable 2-3/8 inch to 2-3/4 inch backset that fits standard door preparations.
21) What finishes does the Kwikset Ladera square rose passage lever come in?
Five: Satin Nickel, Venetian Bronze, Matte Black, Bright Chrome and Satin Chrome. Satin Nickel and Matte Black are the usual choices when you are standardizing interior doors across units; Venetian Bronze pairs with darker trim packages.
22) What is Microban on a door lever and does it wear off?
Microban antimicrobial protection is built into the Ladera lever's finish rather than applied as a coating you wipe on, and Kwikset states it keeps the hardware 99.9 percent cleaner than unprotected surfaces. It inhibits growth on the surface between cleanings; it is not a substitute for disinfecting. Worth specifying in senior housing, clinics and shared-corridor units where the same lever gets touched all day.
23) Is there a decorative passage lever alternative to the Kwikset Ladera for a higher-end interior?
The Baldwin Estate 5103 passage lever with 5048 rose is a passage/hall/closet function in a solid decorative lever family that also offers matching privacy and left and right hand half dummy trim, so a whole floor of doors can be finished consistently. The Bravura Miramar BV940-106 is a Grade 2 passage leverset with round trim in a US4 satin brass finish. The Kwikset Ladera 200LRL comes in Venetian Bronze, Satin Nickel, Bright Chrome, Satin Chrome and Matte Black.
