Kwikset KWI-740LSLSQT-S Lisbon...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$124.30
$84.78
Kwikset KWI-740LSLSQT-S Lisbon Lever with Square Rose Entry Door Lock SmartKey with 6AL Latch and RCS Strike

Kwikset KWI-740LSLSQT-S Lisbon Lever with Square Rose Entry Door Lock SmartKey with 6AL Latch and RCS Strike

(No reviews yet) Write a Review

Model: 740LSLSQT-15S
From the Lisbon Collection
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$124.30
$84.78
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Kwikset KWI-740LSLSQT-S Lisbon Lever with Square Rose Entry Door Lock SmartKey with 6AL Latch and RCS Strike

Featuring SmartKey Security™, this lock protects against advanced break-in techniques and allows you to re-key your lock yourself in just seconds. Compatible with Kwikset (KW1) keyway or (SC1) keyway options. This product is designed to fit both right-handed and left-handed doors, making it a universal solution for your home. Plus, with 3 interchangeable faceplates - round corner, square corner, and drive-in collar - you'll have the flexibility to choose the one that fits your door best. This product is ANSI/BHMA grade 2 certified, meaning it has been tested and certified for durability and performance.

PRODUCT FEATURES

  • Designer style and superior security with this Kwikset Signature Series™ product
  • For use on exterior doors where keyed entry and security is needed
  • Featuring SmartKey Security™, which protects against advanced break-in techniques and allows you to re-key your lock yourself in seconds.
  • SmartKey Security™ re-key technology is compatible with Kwikset (KW1) keyway or (SC1) keyway options
  • Comes with 2 keys
  • Latch has 3 interchangeable faceplates
  • round corner, square corner, and drive-in collar
  • Certified Highest Residential Security, Durability and Finish - ANSI/BHMA Grade AAA
  • Latch has adjustable backset 2-3/8"" to 2-3/4"" to fit all standard door preparations
  • Includes full lip round strike
  • Locking mechanism functions with turn piece on the interior of the lock
  • Fully reversible lever, can be installed on both right handed and left handed doors
  • Easily installs in minutes with just a screwdriver
  • Lifetime mechanical and finish warranty



RESOURCES & DOWNLOADS

Kwikset KWI-740LSLSQT-S Lisbon Lever with Square Rose Entry Door Lock SmartKey with 6AL Latch and RCS Strike

Manufacturer Resources

Product Specs

Product Group:
Mechanical Locks
Product Subgroup:
Leversets
Subcategory:
Levers
Commercial/Residential:
Residential
Product Features:
SmartKey
Product Attribute:
Cylindrical Locks
Product Type:
Leversets
Door Hand Direction:
Reversible
Product Category:
Mechanical Locks
Collection:
Lisbon
Department:
Door Hardware

Kwikset 740LSLSQT-15S – Frequently Asked Questions

1) Will the Kwikset 740 Lisbon lever fit a door already bored for a 2-3/8 inch backset, or do I need the 2-3/4?
Either one. The 6AL latch that ships with the Lisbon lever is adjustable from 2-3/8 to 2-3/4 inches, so it drops into both standard bore preps without ordering a separate latch. That covers essentially every residential door prep you'll run into, so you can stock one part number across a building instead of splitting orders by backset.
2) Is the Kwikset Lisbon lever handed? I need it for a left-hand entry door.
Handing isn't a factor. The Lisbon lever is fully reversible and installs on right-hand or left-hand doors out of the same box. Nothing to specify on the order, and nothing to swap in the field.
3) Can I key the Kwikset 740 Lisbon SmartKey lever to my existing Schlage keys?
SmartKey re-key technology on the 740 Lisbon accepts either the Kwikset KW1 keyway or the Schlage SC1 keyway, so if your building is already on SC1 you can bring this lock onto that key rather than carrying a second key. Re-keying is done at the door in seconds with the SmartKey tool, no cylinder removal and no locksmith visit. It ships with 2 keys.
4) I manage apartments and re-key between tenants. Does the Kwikset SmartKey lever save me the locksmith call?
That's the reason to buy it. SmartKey lets you re-key the lock yourself in seconds at the door, so a tenant turnover becomes a two-minute task per unit instead of a locksmith invoice. Because it re-keys to KW1 or SC1, you can standardize a whole property on one keyway and still re-key units individually. It's a residential-duty lock, ANSI/BHMA Grade 2 certified.
5) Does the Kwikset Lisbon keyed entry lever come with a latch faceplate that matches my door, or do I need to order one?
Three faceplate options come in the box: round corner, square corner, and a drive-in collar. So whether the existing mortise in the door edge is square-cut, radius-cut, or you're working a bored hole with no faceplate mortise at all, you use what's included. The full lip round strike for the jamb is in the box too.
6) Is the Kwikset 740 Lisbon lever rated for a commercial office or school door?
No, and this is the wrong part for that. The Lisbon 740 is a residential keyed entry lever, ANSI/BHMA Grade 2. For a commercial opening you want a Grade 1 cylindrical lock like the Corbin Russwin CL3100 Series or the Falcon K Series K101, both Grade 1 with a stated fire rating, or the Dexter C1000 Series if you need a specific commercial function such as classroom or storeroom.
7) What is the closest keyed entry lever to the Kwikset 740LSL Lisbon if I want a commercial-grade lockset instead of a residential one?
The Kwikset 740LSL Lisbon is a residential keyed entry leverset with SmartKey re-key technology and ANSI/BHMA Grade 2 certification. For a commercial-duty keyed lever in the same entry role, the Hager 2525 is a Grade 2 commercial cylindrical entry lock with a lever handle and a 1-3/8 inch to 2 inch door thickness range, and the Falcon B511CP6D is a Grade 2 medium duty cylindrical lever in entrance/office function. Both keep the entry function and Grade 2 rating, but neither carries SmartKey, so re-keying goes back to a locksmith or a pinning kit rather than being done at the door.
8) I need the same Lisbon lever look on an interior door that does not need a key. What do I order?
The 740LSL Lisbon is a keyed entry lock with a turn piece on the interior, which is more lock than a bedroom hallway or closet door needs. For non-keyed openings, the Falcon B101 is a Grade 2 medium duty cylindrical passage lever with a non-handed design, the Hager 2510 is a Grade 2 passage cylindrical lever in the Withnell design with a 1-3/8 inch to 2 inch door thickness range, and the Bravura Tampa is a Grade 2 passage leverset with square trim if you are trying to keep a square rose line running through the interior doors. A passage lever has no cylinder and no turn piece; it only latches.
9) The bathroom door needs a lever that locks from inside without a key. Is the Kwikset 740LSL Lisbon the right one?
No. The 740LSL Lisbon is a keyed entry lock built for exterior doors where keyed entry and security are needed, and it comes with two keys. A bath or bedroom door wants privacy function instead: the Hager 2540 is a Grade 2 privacy cylindrical lock with the Withnell lever and a 1-3/8 inch to 2 inch door thickness range, and the Baldwin Estate 5103 privacy lever with the 5048 rose covers the same function in a decorative line. Privacy locks push-button or turn from the inside and release from the outside with an emergency tool, not a key.
10) For an office suite where the door has to stay locked from outside but always open from inside, is a Lisbon entry lever the right function?
The 740LSL Lisbon locks by a turn piece on the interior side, so anyone inside can set or release it. Where the outside must stay locked at all times and staff key in, a storeroom function is the correct part: the Cal-Royal AG05 is a Grade 2 storeroom lever lockset with a deadlocking latchbolt on a 1-3/8 inch to 1-3/4 inch door, and the Hager 2580 is a Grade 2 storeroom cylindrical lock with the Withnell lever on a 1-3/8 inch to 2 inch door. Storeroom locks have no inside turn piece to leave the door unsecured.
11) What is the difference between the Kwikset 740LSL Lisbon and a Grade 1 lever like the Falcon K101 or Dexter C1000?
The 740LSL Lisbon is ANSI/BHMA Grade 2 certified and built for residential use. The Falcon K101 is a Grade 1 heavy duty cylindrical lock, fire rated, with non-handed levers and a 1-3/8 inch to 2-1/4 inch door thickness range, and the Dexter C1000 entry/office lever is Grade 1 with a clutching keyed design on a 1-3/8 inch to 1-3/4 inch door. Grade 1 is the higher ANSI cycle and strength tier and is what most institutional and multi-family specifications call for on high-traffic openings; the Kwikset trades that for SmartKey re-keying at the door.
12) I have a fire-rated door assembly. Can I use the Kwikset 740LSL Lisbon on it?
The 740LSL Lisbon is a residential keyed entry leverset and should not be assumed to satisfy a fire-rated opening. Where the door assembly is rated, specify a lock the set identifies as fire rated: the Falcon K101 is a Grade 1 heavy duty passage lock listed as fire rated with a 1-3/8 inch to 2-1/4 inch door thickness range, and the Corbin Russwin CL3110 is a Grade 1 vandal resistant passage/closet cylindrical lever, fire rated, for 1-3/4 inch to 2 inch doors. Both are non-keyed passage functions, so a keyed opening in a rated assembly needs the keyed model from those same series.
13) Our building is keyed on Schlage C keyway. Is the Kwikset Lisbon 740LSL still an option?
The 740LSL Lisbon SmartKey cylinder is compatible with the Kwikset KW1 keyway or the SC1 keyway, so it can be brought onto a Schlage-keyed building using SC1. If the master key system runs on Schlage C rather than SC1, the Cal-Royal AG00 entrance lever is a Grade 2 lock with a 6-pin Schlage C keyway keyed different and a 2-3/8 inch backset, the Cal-Royal AG03 classroom lever is the same series with a 2-3/4 inch backset, and the Arrow MK33-BD-CS is a Grade 2 asylum function lock with a conventional cylinder in Schlage C keyway. Confirm which keyway the existing system is cut to before ordering either way.
14) I want to stop issuing keys to tenants and contractors. What replaces a Kwikset 740LSL Lisbon with a code instead?
The 740LSL Lisbon is a keyed lock that ships with two keys and re-keys through SmartKey. To move an opening off keys entirely, the Delaney LP250 is a Grade 2 electronic keypad leverlock, the Lockey 1150 is a heavy duty mechanical keypad lever set with double combination in passage function for 1-1/8 inch to 2 inch doors, and the Lockey 2835 is a mechanical pushbutton keyless lever lock with passage function and ADA compliance for 1-3/16 inch to 2 inch doors. The mechanical Lockey units need no power or batteries; the Delaney is electronic.
15) How does the Kwikset Lisbon lever lock from the inside? Is there a key on both sides?
Key outside, turn piece inside. The interior side of the Lisbon lever has a thumbturn that throws the lock, so you never need a key to get out. That's the standard keyed entry arrangement for an exterior residential door, front, back, or garage-to-house.
16) What finishes does the Kwikset 740 Lisbon square rose lever come in?
Five: Satin Nickel, Satin Chrome, Bright Chrome, Venetian Bronze, and Matte Black. If you're matching existing hardware on other openings, Satin Nickel and Venetian Bronze are the two that pair with most builder-grade trim already in place, and Matte Black matches current black door hardware packages. All five carry the same square rose trim.
17) I need a keyed entry lever but not SmartKey. What else does ZenSupply carry?
For a conventional-cylinder keyed lever, the Master Lock BC Series RL01 is a Grade 3 keyed entry lever, and the Cal-Royal AG00 is a Grade 2 entrance lever with a 6-pin Schlage C keyway keyed different, 2-3/8 inch backset, for 1-3/8 to 1-3/4 inch doors. Cal-Royal AUS00 is a Grade 3 entrance/office lever with a solid brass forged body for the same door thickness range. You give up the DIY re-key with any of these, but you get a standard pinned cylinder your locksmith can key into an existing system.
18) Can I use the Kwikset Lisbon keyed lever on an interior bedroom or closet door?
You can, but you're paying for a cylinder you don't need. The 740 Lisbon is built for exterior doors where keyed entry matters. For interior openings, a passage lever like the Bravura Tampa (square trim, Grade 2) or the Hager 2510 Grade 2 passage lever for 1-3/8 to 2 inch doors is the right function, and for a bath or bedroom you want a privacy function such as the Hager 2540 or the Baldwin Estate 5103 privacy lever.
19) A Baldwin Estate 5103 lever looks similar to the Kwikset Lisbon. Will it work as a keyed entry replacement?
No. The Baldwin Estate 5103 with the 5048 rose is offered in passage, privacy, and half dummy versions, including left hand and right hand half dummy trims. None of those is a keyed entry lock, so none of them replaces the 740LSL Lisbon on an exterior door where keyed entry and security are needed. The 5103 half dummy versions are also handed left or right, while the Lisbon lever is fully reversible for right and left handed doors.
20) What do I put on the inactive leaf of a pair of doors if the active leaf has a Kwikset 740LSL Lisbon?
The 740LSL Lisbon is a working keyed entry lock with a latch, so it is not the part for a leaf that never operates. A dummy lever gives the matching pull with no latch and no cylinder: the BEST 9K Series 1DT is a Grade 1 non-keyed heavy duty single dummy trim cylindrical lever, the BEST 7KC Series 1DT is the Grade 2 medium duty single dummy trim, and the Accentra 455LN Augusta is a Grade 1 heavy duty single dummy cylindrical lever in the 5400 Series. Single dummy trim mounts to one face only, so order one per side you need to cover.
21) Is there a lighter-duty keyed entry lever than the Kwikset 740LSL Lisbon for a low-traffic rental door?
The 740LSL Lisbon is ANSI/BHMA Grade 2 certified. Below that tier, the Master Lock BC Series RL01 is a Grade 3 return style lever keyed entry lockset, the Callan Artino is a Grade 3 entrance leverset, and the Cal-Royal AUS00 is a Grade 3 entrance/office lever with a solid brass forged body for 1-3/8 inch to 1-3/4 inch doors. Grade 3 is the lightest ANSI residential tier; the Kwikset stays a tier above it and adds SmartKey re-keying.
22) The entry door also needs a deadbolt. Does the Kwikset 740LSL Lisbon include one?
The 740LSL Lisbon is a keyed entry leverset with a 6AL latch, three interchangeable faceplates, and a full lip round strike; the locking is by the interior turn piece, not a separate deadbolt. If a single ordered item should cover both, the Callan Bennett is a Grade 3 entrance leverset supplied as a deadbolt combo. Otherwise the deadbolt is a separate order alongside the Lisbon lever.
23) Can I use the Kwikset 740LSL Lisbon on a classroom or a patient room door?
The 740LSL Lisbon is a residential keyed entry lever and does not offer institutional functions. Classroom and institutional openings call for the function by name: the Dexter C1000 classroom lever is Grade 1 clutching and keyed for 1-3/8 inch to 1-3/4 inch doors, the Dexter C1000 classroom security lever adds the second cylinder in the same Grade 1 range, and the Dexter C1000 asylum lock is Grade 1 asylum/institution/utility function for 1-3/8 inch to 2 inch doors. Those functions control the outside and inside levers independently in ways a residential entry lock does not.
24) My doors are 2 inches thick. Will a Kwikset 740LSL Lisbon fit, or do I need something else?
The 740LSL Lisbon latch has an adjustable backset of 2-3/8 inch to 2-3/4 inch to fit standard door preparations. For thick doors specifically, the Arrow GL01 Grade 2 passage lock and the Design Hardware X75 Grade 1 passage lever are built for the heavier range, with the GL01 covering 1-3/4 inch to 2 inch and the Corbin Russwin CL3110 Grade 1 covering 1-3/4 inch to 2 inch, while the Falcon K101 Grade 1 reaches 1-3/8 inch to 2-1/4 inch. Measure the door slab before ordering; backset and door thickness are two separate dimensions and both have to match.
25) Can a Kwikset 740LSL Lisbon be tied into an access control system?
The 740LSL Lisbon is a mechanical keyed entry lock operated by key outside and turn piece inside, with no electrical provision. An opening that has to unlock from a card reader or fire alarm signal needs an electrified lock: the Corbin Russwin CL33903 is a Grade 1 fail safe electrified cylindrical lever running on 12VAC/DC for 1-3/4 inch to 2 inch doors, offered with the NZ lever and D rose. Fail safe means the lever unlocks when power is removed, which is the opposite behavior from a mechanical lock left locked.
26) I want the Lisbon lever look on a door that doesn't need to lock. Is there a matching dummy or passage version?
The 740 Lisbon square rose set is the keyed entry function only. To carry a similar look onto a closet or French door leaf, the Bravura Tampa passage leverset uses square trim, and for a fixed pull with no latch the Baldwin Estate 5103 half dummy is offered in both left hand and right hand. Note that the Baldwin half dummies are handed, so specify the side.
27) The Lisbon has a square rose. What other levers keep a square or round trim look across the same set of doors?
The Kwikset Lisbon 740LSL pairs its lever with a square rose and comes in Satin Chrome, Venetian Bronze, Satin Nickel, Bright Chrome, and Matte Black. If the rose shape is what is driving the choice, the Bravura Tampa is a Grade 2 passage leverset with square trim, while the Bravura Atlanta, Orlando, and Miramar are Grade 2 passage leversets with round trim. Trim shape does not change the door prep, so a square rose and a round rose can share the same bore on adjacent doors.
