LCN LCN 8310-3818TWF 1-1/2" x 4-3/4" Stainless Steel Rectangle Flush Mount Wireless Actuator with Blue Handicap Symbol and Push To Open Text LCN-8310-3818TWF

LCN 8310-3818TWF Wireless Touchless Actuator 1-1/2" x 4-3/4" Stainless Steel with Handicap Symbol

(No reviews yet) Write a Review

Model: 8310-3818TWF

In Stock (leaves warehouse same day if ordered before 3pm ET)

$587.00
$444.17
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

LCN 8310 Series Wireless Touchless Actuator 1-1/2" x 4-3/4" Stainless Steel with Handicap Symbol

Professional Touchless Access Control Solution

The LCN 8310 Series wireless touchless actuator provides contactless door operation with a simple hand wave motion. This 1-1/2" x 4-3/4" rectangle flush-mount unit features stainless steel construction and includes the 8310-818T actuator, 8310-844J transmitter, and 8310-819F flush box. The wireless design eliminates the need for physical contact with door hardware, promoting health and well-being in high-traffic facilities with IP65-rated protection for reliable operation in various environments.

Professional Features & Benefits

  • Compact Dimensions: 1-1/2" x 4-3/4" rectangle design provides optimal mounting flexibility for jamb installations.
  • Complete Wireless Kit: Includes 8310-818T actuator, 8310-844J transmitter, and 8310-819F flush box for comprehensive installation solution.
  • Stainless Steel Construction: Heavy-duty stainless steel materials provide rugged performance and durability in demanding commercial environments.
  • IP65 Protection Rating: Electronic components are protected from water and cleaning liquids for reliable operation in various environments.
  • Touchless Operation: Motion sensing technology detects hand waves without requiring physical contact with actuator, door handle, or push bar.
  • Wireless Connectivity: Transmitter communicates with compatible 8310-865 receiver (sold separately) for flexible system integration.
  • Visual Identification: Blue handicap symbol and "Push To Open" text provide clear user guidance and ADA compliance indication.
  • Flush Mount Design: Aesthetically pleasing installation that is less susceptible to accidental damage compared to surface-mounted alternatives.

Technical Specifications

  • ADA Compliant: Yes
  • Application: Actuator
  • Box: 8310-819F
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Display Text: Push To Open
  • Electronic: Yes
  • Finish Type: Plated
  • Mounting Method: Flush Mount
  • Parts and Accessories Type: Installation Accessories
  • Product Attribute: Parts and Accessories
  • Product Category: Electronic Access Controls
  • Product Color: Blue
  • Product Dimension: 1-1/2 x 4-3/4"
  • Product Group: Electronic Access Controls
  • Product Model: 8310-3818TWF
  • Product Shape: Rectangle
  • Product Subgroup: Parts and Accessories
  • Product Substrate: Stainless Steel
  • Product Type: Door Actuators & Plates
  • Relay Action: Momentary (MOM)
  • Series: 8310 Series
  • Subcategory: Closer Parts and Accessories
  • Symbol: Handicap
  • Touchless Activation: No
  • Transmitter: 8310-844J
  • Weather Resistant: Yes
  • Wireless Communication: Yes

Professional Applications

  • Healthcare Facility Access Control
  • Commercial Building Touchless Entry
  • Educational Institution Safety Systems
  • Retail Establishment Accessibility
  • Government and Municipal Buildings
  • Industrial Facility Clean Environments
  • Multi-Tenant Residential Properties

Why Choose LCN Quality?

LCN 8310 Series touchless actuators deliver professional-grade reliability with stainless steel construction and IP65-rated protection for demanding commercial applications. The flush-mount design and wireless operation provide both aesthetic appeal and functional durability in high-use environments. Engineered as part of comprehensive auto operator solutions where dependable touchless performance is essential.

Product Specs

Series:
8310 Series
Box:
8310-819F
Display Text:
Push To Open
Relay Action:
Momentary (MOM)
Symbol:
Handicap
Transmitter:
8310-844J
Application:
Actuator
Touchless Activation:
No
Subcategory:
Closer Parts and Accessories
Product Group:
Electronic Access Controls
Product Subgroup:
Parts and Accessories
Product Type:
Door Actuators & Plates
Finish Type:
Plated
Weather Resistant:
Yes
Commercial/Residential:
Commercial
Electronic:
Yes
Wireless Communication:
Yes
ADA Compliant:
Yes
Parts and Accessories Type:
Installation Accessories
Product Attribute:
Parts and Accessories
Product Model:
8310-3818TWF
Product Color:
Blue
Product Dimension:
1-1/2 x 4-3/4"
Mounting Method:
Flush Mount
Product Shape:
Rectangle
Product Category:
Electronic Access Controls
Product Substrate:
Stainless Steel
Department:
Door Hardware

LCN 8310-3818TWF – Frequently Asked Questions

1) What comes in the box with the LCN 8310-3818TWF wireless actuator, and what else do I need to buy?
The 8310-3818TWF kit ships as three pieces: the 8310-818T actuator plate, the 8310-844J wireless transmitter, and the 8310-819F flush mounting box. What it does not include is the receiver. The transmitter pairs with the 8310-865 receiver, which is ordered separately, and you still need a low energy automatic operator on the door for the actuator to signal.
2) Is the LCN 8310 wireless actuator hard wired or does it run on a radio signal?
Radio. The 8310-844J transmitter in the kit sends the signal to a receiver rather than running a switch leg back to the operator, so you do not have to fish conduit from the jamb to the header. That is the main reason people pick this over a wired push plate on a retrofit where the wall or jamb is already closed up.
3) Do you have to touch this plate, or does it activate on a hand wave?
The 8310-3818TWF is a touchless unit. It reads a hand wave in front of the plate, so nobody contacts the plate, the lever, or the push bar to trigger the operator. It sends a momentary signal, meaning the contact closes for the activation and then releases, letting the operator run its own cycle and close timing rather than holding the door open.
4) What is the difference between the LCN 8310-3818TWF and the Falcon 8310-819F when ordering an actuator?
They are not alternatives to each other - one contains the other. The LCN 8310-3818TWF is a complete wireless touchless actuator kit that ships with the 8310-818T actuator, the 8310-844J transmitter, and the 8310-819F flush box. The Falcon 8310-819F is only the rugged plastic actuator mounting box, sized 1-1/2 inch by 4-3/4 inch for jamb and flush mount. Order the 819F by itself when you already have an actuator in hand and need a replacement or an additional box; order the 3818TWF when you need the switch, the transmitter, and the box together.
5) I need a wireless door switch but the jamb is too narrow for a square plate - how does the LCN 8310-3818TWF compare to the Camden CM-45?
Size and activation are the two decisions. The LCN 8310-3818TWF is a 1-1/2 inch by 4-3/4 inch rectangle, which is the narrow-jamb shape, and it is a touchless hand-wave unit in stainless steel with a blue handicap symbol and Push To Open text. The Camden CM-45 series is a 4-1/2 inch square push plate switch offered wired or with a kinetic wireless transmitter, so it needs a wider mounting surface and is pressed rather than waved at. On a narrow aluminum jamb the rectangle profile is the one that fits; on a wide wall or bollard either shape works.
6) Can this actuator be washed down or used where the wall gets sprayed with disinfectant?
Yes. The electronics carry an IP65 rating against water and cleaning liquids, and the plate itself is stainless steel, so repeated disinfectant wipe-downs at a hospital or lab entry will not kill it. It is also listed as weather resistant, which matters on a covered exterior entrance.
7) Does this plate have the blue wheelchair symbol and Push To Open wording for an accessible entrance?
It does. The face carries the blue handicap symbol along with Push To Open text, and the unit is listed as ADA compliant. For a facility standardizing accessible entries, that means one plate covers both the marking and the activation without adding a separate signage plate beside it.
8) What is the difference between this LCN touchless actuator and a Camden CM-45 push plate switch?
Two different activation methods. The 8310-3818TWF is a touchless hand-wave unit on a narrow 1-1/2 by 4-3/4 inch rectangle plate, flush mounted, with the transmitter in the kit. The Camden CM-45 Series is a 4-1/2 inch square push plate switch, offered wired or with a kinetic wireless transmitter, and it requires a physical press. Pick the LCN where infection control or glove-free operation drives the spec, and the Camden square where you need a larger target plate or a wired switch leg.
9) If the mounting box cracks during installation, can I just buy the box instead of another whole LCN 8310 actuator?
Yes. The box supplied with the LCN 8310-3818TWF is the 8310-819F, and that same 1-1/2 inch by 4-3/4 inch rectangle jamb and flush mount box is stocked on its own as the Falcon 8310-819F rugged plastic actuator mounting box. Reusing the existing actuator and transmitter and replacing only the box keeps the rough opening and the flush mount detail unchanged.
10) Can I use a Camden CM-45 with the LCN 8310-865 receiver instead of the LCN actuator?
Treat them as separate systems. The LCN 8310-3818TWF pairs with the 8310-844J transmitter it ships with, which communicates with the compatible 8310-865 receiver sold separately. The Camden CM-45 series uses its own kinetic wireless transmitter option. Keep the transmitter and receiver within one manufacturer's wireless pairing rather than mixing a Camden switch into an LCN 8310 receiver.
11) My facility wants a touchless wave switch rather than a push plate - which of these two does that?
The LCN 8310-3818TWF is the wave unit. It senses a hand motion so the user does not contact the actuator, door handle or push bar, and its IP65-rated electronics tolerate water and cleaning liquids, which suits healthcare and clean-environment corridors. The Camden CM-45 series is a push plate switch that is physically pressed. If infection control is driving the project, the rectangle touchless unit is the one that meets the intent.
12) Is the LCN 8310-3818TWF suitable for a residential entry door?
It is built and catalogued for commercial work: stainless steel plate, flush mount into a recessed box, and it only does anything when it is paired with a low energy automatic operator and an 8310-865 receiver. In a house with a plain manual door there is nothing for it to signal. Use it on healthcare, school, retail, government, and multi-tenant openings that already have a power operator.
13) For a fire-rated corridor door, is the LCN 8310-3818TWF or the Camden CM-45 the right actuator?
The Camden CM-45 series push plate switches carry a fire rating of No. Actuators and push plates mount to the jamb or adjacent wall rather than to the fire door leaf itself, so the rating question normally lands on the door, frame, closer and operator rather than on the switch. If your specification calls for a listed component at the actuator, confirm the requirement with the authority having jurisdiction before selecting either part.
