LCN LCN 8310-3857T 4-3/4" x 4-3/4" Square, Hard Wired Surface Mount Actuator Package with Handicap Symbol and Text LCN-8310-3857T

LCN 8310-3857T Touchless Actuator Package with Handicap Symbol 4-3/4" Square Hard Wired Surface Mount

(No reviews yet) Write a Review

Model: 8310-3857T

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,208.00
$938.76
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

LCN 8310 Series Touchless Actuator Package with Handicap Symbol 4-3/4" Square Hard Wired Surface Mount

Professional Touchless Access Control Solution

The LCN 8310 Series touchless actuator package provides hands-free door operation for enhanced hygiene and accessibility compliance. This complete hard-wired system features a 4-3/4" x 4-3/4" square design with handicap symbol and includes dual wall mount actuators (8310-853T) and surface mount boxes (8310-867S). The motion-sensing technology activates when pedestrians wave their hand in front of the wall plate, eliminating contact requirements with actuators, door handles, or push bars for professional commercial applications.

Professional Features & Benefits

  • Complete Package Solution: Includes 8310-853T wall mount actuators (2) and 8310-867S surface mount boxes (2) for comprehensive installation with all necessary components.
  • Touchless Motion Detection: Advanced motion-sensing technology activates when pedestrians wave their hand in front of the wall plate, eliminating physical contact requirements.
  • Standard Square Dimensions: 4-3/4" x 4-3/4" square format provides professional appearance and easy integration into commercial door systems.
  • ADA Compliance Design: Features handicap symbol and "Push To Open" text for accessibility compliance in commercial applications.
  • Hard-Wired Configuration: Reliable wired connection with momentary relay action ensures consistent performance in high-traffic environments.
  • Weather-Resistant Construction: Stainless steel substrate with weather-resistant design suitable for various environmental conditions.
  • Surface Mount Installation: Flush mount design provides aesthetically pleasing installation that is less susceptible to accidental damage.
  • Health and Safety Enhancement: Promotes hygiene by eliminating the need to touch door hardware or actuators in healthcare and commercial facilities.

Technical Specifications

  • ADA Compliant: Yes
  • Application: For use with power operators requiring Dry Contact, Round Actuator
  • Battery Operated: No
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Display Text: Push To Open
  • Electronic: Yes
  • Mounting Method: Surface Mount
  • Package: Yes
  • Package Qnty: 4
  • Parts and Accessories Type: Installation Accessories
  • Product Attribute: Parts and Accessories
  • Product Category: Electronic Access Controls
  • Product Color: Blue
  • Product Dimension: 4-3/4 x 4-3/4"
  • Product Group: Electronic Access Controls
  • Product Model: 8310-3857T
  • Product Shape: Square
  • Product Subgroup: Parts and Accessories
  • Product Substrate: Stainless Steel
  • Product Type: Door Actuators & Plates
  • Relay Action: Momentary (MOM)
  • Series: 8310 Series
  • Subcategory: Closer Parts and Accessories
  • Symbol: Handicap
  • Touchless Activation: No
  • Weather Resistant: Yes

Professional Applications

  • Healthcare Facility Access Control
  • Commercial Building Security Systems
  • Educational Institution Safety Systems
  • Retail Establishment Entry Points
  • Government and Municipal Buildings
  • Industrial Facility Monitoring
  • Emergency Exit Compliance

Why Choose LCN Quality?

LCN 8310 Series touchless actuators deliver professional-grade reliability with motion-sensing technology designed for demanding commercial applications. The complete package solution includes all necessary components for professional installation, ensuring consistent hands-free operation where hygiene and accessibility are essential. Engineered as part of comprehensive automatic operator solutions for dependable touchless access control in high-traffic commercial environments.

Product Specs

Series:
8310 Series
Display Text:
Push To Open
Relay Action:
Momentary (MOM)
Symbol:
Handicap
Application:
For use with power operators requiring Dry Contact, Round Actuator
Touchless Activation:
No
Subcategory:
Closer Parts and Accessories
Product Group:
Electronic Access Controls
Product Subgroup:
Parts and Accessories
Product Type:
Door Actuators & Plates
Weather Resistant:
Yes
Commercial/Residential:
Commercial
Electronic:
Yes
Battery Operated:
No
ADA Compliant:
Yes
Parts and Accessories Type:
Installation Accessories
Product Attribute:
Parts and Accessories
Package:
Yes
Package Qnty:
4
Product Model:
8310-3857T
Product Color:
Blue
Product Dimension:
4-3/4 x 4-3/4"
Mounting Method:
Surface Mount
Product Shape:
Square
Product Category:
Electronic Access Controls
Product Substrate:
Stainless Steel
Department:
Door Hardware

LCN 8310-3857T – Frequently Asked Questions

1) What comes in the LCN 8310-3857T actuator package, and is it enough for two doors?
The 8310-3857T ships as a package of 4 pieces: two 8310-853T wall mount actuators and two 8310-867S surface mount boxes. That covers a single opening actuated from both sides (push side and pull side), or two separate doors with one actuator each. Each actuator needs its own box, so the count pairs one to one.
2) Will the LCN 8310-3857T actuator work with my automatic door operator?
It works with power operators that take a dry contact input and accept a round actuator. The relay action is momentary, so it closes the contact for the press and releases, which is what a low energy swing operator expects on its activation input. If your operator needs a maintained or latching signal rather than a dry contact momentary, this is the wrong actuator.
3) Should I use a square 4-3/4 inch actuator or a narrow jamb mount plate?
Square 4-3/4 inch plates like the 8310-3857T go on the wall beside the opening, where there's flat surface to take them. On an aluminum storefront jamb or a narrow pilaster there often isn't 4-3/4 inches of flat to work with, and a narrow rectangular plate is the answer instead: the Falcon 8310-819F is a 1-1/2 x 4-3/4 inch rectangle actuator mounting box for jamb and flush mount in the same 8310 Series. Decide by measuring the mounting surface before you order.
4) I need an actuator at a door opening where I cannot run wire to the plate. What do I use instead of the LCN 8310-3857T?
The LCN 8310-3857T is a hard wired surface mount package and is not battery operated, so it needs a wire run to each plate location. Where that run is not practical, the Camden CM-45 Series 4-1/2 inch square push plate switch is offered with a kinetic wireless transmitter as well as in a wired version. The tradeoff is that the CM-45 is a push plate rather than a wave-activated plate, so users contact the plate to open the door.
5) What is the difference between the LCN 8310-3857T actuator package and the Falcon 8310-819F mounting box?
They are not the same class of part. The LCN 8310-3857T is a complete actuator package with the 4-3/4 x 4-3/4 inch square stainless steel wall plates carrying the handicap symbol and Push To Open text, wired for momentary relay action. The Falcon 8310-819F is a rugged plastic actuator mounting box measuring 1-1/2 x 4-3/4 inches for jamb and flush mount, and holds no switch or plate of its own. Both are 8310 Series parts, so the Falcon box is what you order when you already have the actuator and need mounting, not when you need the activation device itself.
6) Is the Camden CM-45 push plate a substitute for the LCN 8310-3857T actuator?
The Camden CM-45 Series is a 4-1/2 inch square push plate switch offered wired or with a kinetic wireless transmitter. The LCN 8310-3857T is a 4-3/4 inch square hard wired package with stainless steel plates and momentary relay action. Two differences decide it: the CM-45 is a push plate, so the user makes contact with it, while the 8310-3857T is waved at, and the CM-45 square face is 4-1/2 inches against 4-3/4 inches, so an existing cutout or backbox sized to one will not land the other flush. The CM-45 wireless option matters where you cannot pull wire to the plate location.
7) What size is the LCN 8310-3857T push plate and what does it take to mount it?
The plate is 4-3/4 x 4-3/4 inches, square. It surface mounts, so you don't cut into the wall for a back box, the included 8310-867S boxes sit proud on the finished surface. That makes it workable on block, tile, or existing drywall where a flush cut-in isn't wanted. You do still need to get the wire to the box.
8) Can the LCN 8310 actuator be mounted outside or in a wash-down area?
It's built weather resistant on a stainless steel substrate, so exterior entrance jambs and covered vestibules are within its intended use. Stainless also holds up to the repeated cleaning common in healthcare and food service corridors.
9) Does the LCN 8310-3857T actuator have the wheelchair symbol and Push To Open text?
Both. The plate carries the handicap symbol and reads Push To Open, in blue. That's the marking most facility specs call for on a barrier free entrance actuator, and it matches the blue plates already on other openings in most commercial buildings, so a property manager replacing one won't end up with a mismatched entrance.
10) Which actuator holds up better outdoors, the LCN 8310-3857T or the Falcon 8310-819F box?
The LCN 8310-3857T uses a stainless steel substrate and is weather resistant, which is what suits it to exterior entrances. The Falcon 8310-819F is a rugged plastic mounting box rather than a plate, so it is a different material choice for a different job - it houses an actuator at a jamb or flush location in the same 8310 Series.
11) Is the LCN 8310-3857T rated for a commercial entrance or is it a residential part?
Commercial. It's an electronic access control actuator built for traffic in healthcare, education, retail, and government entrances, on a stainless substrate with a momentary dry contact output to an automatic operator. It isn't a residential doorbell style button.
12) For a fire rated corridor door, can I use the Camden CM-45 in place of the LCN 8310-3857T?
The Camden CM-45 Series push plate switch carries a fire rating of No. Where the opening documents call for a fire rated activation device, neither that plate nor a substitution decision should be made from the actuator alone - the rating belongs to the door, frame and operator assembly, and the activation plate is specified to suit it. The LCN 8310-3857T is a hard wired commercial actuator package with momentary relay action intended for use with power operators requiring dry contact.
