LCN

LCN TRACKS 4010T-3038HB Hold Open Track with Bumper (HBMP) Non-handed With Hold Open clip and bumper assembly installed

LCN TRACKS 4010T-3038H Hold Open Track (H) Non handed With Hold Open clip installed Will accept bumper assembly

LCN TRACKS 4010T-3038B Track with Bumper (BUMP) Non-handed Non Hold Open With bumper assembly installed Will accept Hold Open clip Standard

LCN 4030-79LR Long Rod and Shoe 4030 Series Grade 1 Long Rod and Shoe

LCN 4030-77 Arm and Forearm 4030 Series Grade 1 Arm and Forearm

LCN TRACKS 4010T-3038 Standard Track (STDTRK) Non-handed Non Hold Open Will accept Hold Open clip and/or bumper assembly Standard

LCN 4030-79 Rod and Shoe 4030 Series Grade 1 Long Rod and Shoe

LCN 4010T-3077DE Double Egress Arm for 4010T Series Door Closers, Handed Handed For Double egress doors and frames Does not include track roller Maximum reveal is 3 5/16" (84mm)

LCN 4030-419 Parallel Arm Flush Shoe Required for parallel Arm mounting

LCN 4030-419 Parallel Arm Flush Panel Adapter Provides horizontal mounting surface for PA or CUSH shoe on single rabetted or flush frame

LCN 4010T-3077T Standard Track Arm for 4010T Series Door Closers, Handed Handed Roller not included with Arm

LCN 4011-3071 Cylinder Assembly for 4010 Series Door Closers, Handed 4011T(3)(4)-3071 Cast Iron Cylinder Assembly (CYL)  Handed  Standard

LCN 4010-3049FL Fusible Link Arm for 4010 Series Door Closers, Handed Handed Releases hold-open function when exposed to temperatures above 165° F; 1/8" (3 mm) maximum reveal

LCN 4010-3049 Hold Open Arm for 4010 Series Door Closers, Handed Handed Provides Hold Open function, adjustable at elbow

LCN 4030-62A Auxiliary Shoe Requires a top rail of 7" (178 mm) Replaces -62PA for parallel Arm mounting of Regular Arm with some overhead Holder/stop Optional

LCN 4030-61 BLADE STOP SPACER Lowers parallel Arm shoe to clear 1⁄2" (13 mm) blade stop

LCN 4030-30 Cush Shoe Support Provides anchorage for fifth screw used with CUSH Arms where reveal is less than 3 1⁄16" (78 mm)

LCN 4030-18PA Drop Plate Required for parallel Arm mounting where top rail is less than 5" (127 mm), measured from the stop Requires 1 3⁄4" (44 mm) minimum

LCN 4010-3077 Regular Arm for 4010 Series Door Closers Non-handed

LCN 4030-18TJ Drop Plate Required for top jamb mounting where head frame is less than 2 1⁄4" (57 mm) or flush ceiling condition exists Requires 1 1⁄2" (38 mm) minimum
