Leviton L7506 Straight-Blade Male Plug, 1-1/4 Inch Anodized Aluminum Body

Leviton L7506 Straight-Blade Male Plug, 1-1/4 Inch Anodized Aluminum Body

(No reviews yet) Write a Review

Model: L7506

In Stock (leaves warehouse same day if ordered before 3pm ET)

$38.27
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Leviton L7506 Straight-Blade Male Plug, 1-1/4 Inch Anodized Aluminum Body

The Leviton L7506 is a straight, male plug body engineered for demanding commercial and industrial cordset applications. Built with a rugged 1-1/4 Inch anodized aluminum body, this device is designed to withstand harsh field conditions while providing dependable strain relief for cord diameters ranging from .940" to 1.250". The wide-range strain-relief clamp accommodates a broad span of cord jacket sizes, giving electricians and MRO teams flexibility when assembling or replacing cordsets without needing multiple SKUs on hand for slightly different cord diameters. As a male plug configuration, the L7506 is intended to terminate the line side of a cord assembly, mating with a corresponding female connector or receptacle to complete a portable power connection.

Key Features

  • Trade Size: 1-1/4 Inch body size suited for heavy-gauge cordset assemblies.
  • Durable Construction: Anodized aluminum body resists corrosion and physical abuse in industrial environments, extending service life versus standard plastic-bodied devices.
  • Wide-Range Strain-Relief: Accepts cord range from .940" to 1.250", reducing the number of part numbers needed to cover varying cord jacket diameters.
  • Straight, Male Configuration: Designed as the line-side straight male plug for cordset assemblies, providing a secure mechanical and electrical connection point.
  • Rugged Body Design: The anodized aluminum housing is built for repeated plugging/unplugging cycles and rough handling common in industrial power distribution.

Technical Specifications

  • Body Size: 1-1/4 Inch
  • Configuration: Straight, Male
  • Body Material: Anodized Aluminum
  • Strain-Relief Type: Wide-Range
  • Cord Range: .940" - 1.250"

Typical Applications

  • Industrial Power Cordset Assemblies
  • Portable Equipment and Machinery Power Connections
  • Heavy-Duty Extension Cord Manufacturing
  • MRO Replacement of Damaged Plug Bodies
  • Commercial and Industrial Electrical Installations

Why Leviton?

Leviton engineers the L7506 with a rugged anodized aluminum body and a wide-range strain-relief clamp to deliver a durable, field-ready male plug for industrial cordset assemblies. This construction helps ensure reliable, long-lasting performance for electricians and facility teams who depend on a secure cord connection in demanding work environments.

Manufacturer Resources

Product Specs

list_batch:
LEV-20260924
Product Type:
Straight Blade Plug
Configuration:
Straight, Male
Connection Type:
Wide-Range Strain-Relief
Department:
Electrical
Product Subgroup:
Plugs & Connectors
Product Material:
Anodized Aluminum
Product Size:
1-1/4 Inch
Product Group:
Wiring Devices

Leviton L7506 – Frequently Asked Questions

1) What cord diameter will the Leviton L7506 plug clamp onto?
The L7506 takes cord jackets from .940 inch to 1.250 inch outside diameter through its wide-range strain-relief clamp. Measure the jacket OD on your cord, not the conductor gauge. A cord under .940 inch will not be gripped properly by this clamp, and anything over 1.250 inch will not seat in the body.
2) Is the L7506 a male plug or a female connector?
It is the male plug, straight configuration. It terminates the line side of a cord assembly and mates with a female connector or a receptacle. If you need the other half of the cordset, you want a matching female connector body instead.
3) Can I use the Leviton L7506 to rebuild a damaged plug end on an existing industrial cord?
That is one of its intended uses. The L7506 is a replaceable plug body for MRO repair of damaged plug ends and for building extension cords and equipment cordsets. The cord stays, you re-terminate into the plug body, as long as the jacket OD falls in the .940 to 1.250 inch clamp range.
4) What does the 1-1/4 inch size on the Leviton L7506 refer to?
1-1/4 inch is the body trade size of the plug, sized for heavy-gauge cordset assemblies. It is not the cord range; cord acceptance is a separate spec at .940 to 1.250 inch jacket diameter.
5) Will an aluminum-bodied plug hold up better than a plastic one in a plant?
The L7506 body is anodized aluminum, which resists corrosion and physical abuse and is built for repeated plugging and unplugging in industrial power distribution. In a shop or plant where cords get dragged, run over, or yanked, that metal housing is the reason to pick it over a standard plastic-bodied plug.
6) Do I need to stock several plug bodies to cover different cord sizes?
Not across that .940 to 1.250 inch span. The wide-range clamp on the L7506 covers that whole band of jacket diameters, so one part number handles cords that would otherwise need separate SKUs. Useful if you keep a cord-repair kit on a service truck or in a facility crib.
7) What is the exact Leviton part number to order for this aluminum male plug?
Order Leviton L7506. That is the manufacturer part number for the straight male plug with the 1-1/4 inch anodized aluminum body and wide-range strain relief; there are no finish or size options under it.
